Kensington H1000 USB-C Headset – On Ear

Getting Started

1. Connecting Your Headset

To connect the headset to your device, plug the headset cable into any available USB-C port on your computer or other compatible device.

2. Adjusting for Comfort and Performance

Adjust the headset for optimal comfort and performance. Extend the headband on both sides so the earpads rest comfortably on your ears. Position the adjustable microphone boom so it is directly in front of your mouth. The microphone can be worn on either the right or left side.

Using the In-Line Controls

3. Volume Control

Locate the buttons on the side of the in-line control unit attached to the headset cable. Press the '+' button to increase the volume. Press the '-' button to decrease the volume.

4. Busy Light Feature

The busy light feature helps indicate when your microphone is active. The busy light will automatically illuminate when the microphone is activated. You can also manually control the busy light:

• Pressing the button once will manually turn the busy light on, showing a solid red LED.
• Pressing and holding the button for 2 seconds will cause the red LED light to pulse or blink.
• Pressing the button again in either the solid or pulsing state will manually turn the busy light off.

5. Microphone Mute and Playback Control

Press the dedicated mute button on the in-line controls to mute your microphone. The button will illuminate red when the microphone is muted. Press the button again to unmute your microphone.

Use the play/pause button on the in-line controls to control your music or podcasts between calls.

Support and Compliance

For further assistance and product information, visit the Kensington support website at kensington.com/support.

Kensington and the ACCO name and design are registered trademarks of ACCO Brands. Mac and the Mac logo are trademarks of Apple Computer, Inc., registered in the U.S. and other countries. Windows is a registered trademark of Microsoft Corporation in the U.S. and/or other countries. All other registered and unregistered trademarks are the property of their respective owners.

© 2022 Kensington Computer Products Group, a division of ACCO Brands.

Compliance Information (Japanese): This device is a Class B device. It is intended for use in a residential environment, but may cause radio or television interference when used near radio or television receivers. Please follow the instructions in the manual for proper handling.

This product complies with relevant regulatory standards, indicated by marks such as FC, CE, VCCI, UKCA, and others.

Model Number: K83450

Part Number: 901-5500-01
