LEDYi Lighting R7-1 Ultrathin Touch Wheel RF Remote Controller
Features
- Apply to dual-color LED controller.
- Ultra sensitive color adjustment touch wheel.
- Each remote can match one or more receivers.
- CR2032 battery powered.
- Operate with LED indicator light.
Technical Parameters
| Input and Output | |
| Output signal | RF(2.4GHz) |
| Working voltage | 3VDC(CR2032) |
| Working current | ＜5mA |
| Standby current | ＜10μA |
| Standby time | 1 year |
| Remote distance | 30m(Barrier-free space) |
| Safety and EMC | |
| EMC standard (EMC) | ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-17 V3.2.4 |
| Safety standard(LVD) | EN 62368-1:2020+A11:2020 |
| Radio Equipment(RED) | ETSI EN 300 328 V2.2.2 |
| Certification | CE,EMC,LVD,RED |
| Safety and EMC | |
| EMC standard (EMC) | ETSI EN 301 489-1 V2.2.3
ETSI EN 301 489-17 V3.2.4 |
| Safety standard(LVD) | EN 62368-1:2020+A11:2020 |
| Radio Equipment(RED) | ETSI EN 300 328 V2.2.2 |
| Certification | CE,EMC,LVD,RED |
Mechanical Structures and Installations
To fix the remote, two options are offered for selection:
- Option 1:
fix the remote’ back holder on the wall with two screws. - Option 2:
adhere the remote’ back holder to the wall with paster.
Note: If the LED indicator is not on when pressing the key, it is due to a dead battery or bad contact caused by multiple plugging, please replace the battery, or raise the battery shrapnel with a screwdriver.
Operation
- When the light is on, touch the color wheel, the indicator will display red.
- To extend battery life, no touch or press key operation after a few seconds, the touch wheel will enter the sleep state, you need to press any key to make the touch wheel quit sleep state.
Match Remote Control (two-match ways)
End-user can choose the suitable match/delete ways. Two options are offered for selection:
Use the controller’s Match key
- Match:
Short press the match key, immediately press the on/off key (single-zone remote) or zone key (multiple zones remote) on the remote.
The LED indicator fast flash a few times means the match is successful. - Delete:
Press and hold the match key for 5s to delete all match, The LED indicator fast flash a few times means all matched remotes were deleted.
Use Power Restart
- Match:
Switch off the power, then switch on the power, and repeat again. An immediately short press on/off key (single-zone remote) or zone key (multiple zones remote) 3 times on the remote. The light blinks 3 times means the match is successful. - .Delete:
Switch off the power, then switch on power, repeat again. An immediately short press on/off key (single-zone remote) or zone key (multiple zones remote) 5 times on the remote. The light blinks 5 times means all matched remotes were deleted.
Key function
- Color WW/CW value
- Warm white WW100% CW0%
- Neutral white WW50% CW50%
- Cool white CW50% CW100%
On/Off: Short press turn on/off all zone lights.
- 1,2,3,4 zone: Short press select and turn on zone light, long press 2s turn off zone light. Short press multiple zone key fastly, will synchronous select multiple zones synchronously. Color wheel: Touch to change current zone color temperature.
- Bright+/-: Adjust the brightness for the currently selected zone, short press 10 levels, long press 1-6s for continuous 256 levels adjustment.
- 3 Scene: Short press recall the scene, long press 2s save the current color into the scene. the LED indicator will light up longer when saving OK. 4 zone recall or save synchronously.
- R7-1 1 zone CCT remote
- On/Off: Turn on/off light.
- Color wheel: Touch to change color temperature.
- Bright+/-: Adjust brightness, short press 10 levels, long press 1-6s for continuous 256 levels adjustment.
- 100%,50%: Get 100% or 50% brightness directly.
- WW: Get warm white directly.
- NW: Get cool white directly.
- 3 Scene: Short press recall the scene, long press 2s save the current color into the scene. the LED indicator will light up longer when save OK.
Safety information
- Read all instructions carefully before you begin. this installation.
- When installing the battery, pay attention to the battery’s positive and negative polarity. A long time without the remote control, remove the battery. When remote distance becomes smaller and insensitive, replace the battery.
- If no response from the receiver, please re-match the remote.
- Gently handle the remote, beware of falling.
- For indoor and dry location use only.
