HDWR HD3900 2D Code Reader User Manual

Basic Configuration Codes:
To configure the basic settings of the 2D Code Reader HD3900, follow these steps: – Access the settings menu on the device. – Navigate to the desired configuration option. – Use the designated buttons to adjust the settings as needed.

Factory Reset:
If you need to reset the device to its factory settings, locate the factory reset option in the settings menu and confirm the reset action.

Battery Status:
To check the battery status of the device, access the battery status section in the settings menu. The device will display the remaining battery percentage.

Frequently Asked Questions (FAQ)

Q: How do I pair the device with a receiver in wireless mode?
A: To pair the device with a receiver, follow these steps: – Enable wireless mode on both the device and the receiver. – Access the pairing option on the device and select the receiver from the available devices list. – Follow the on-screen instructions to complete the pairing process.

User Manual

2D Code Reader HD3900

Specifications:

Sensor: 640*480 CMOS
Scanning method: manual (on the button) / automatically (after bringing the code closer)

Scan acknowledgment: sound and light signal
Scan Angle: Swivel ±360°, Horizontal ±60°, Slant ±70°

Internal memory capacity: store up to 120K scanned codes
Operating time on a single charge: 15 hours

Full charge time: 4 hours
Interface: USB

Compatible with operating system: Linux, Android, Windows XP, 7, 8, 10, MacOS
Device dimensions: 16.5 x 8.6 x 6.6 cm

Package dimensions: 18.5 x 11 x 8.3 cm
Device weight: 173 g
Package weight: 312 g
Operating temperature: 10 to 45°C
Storage temperature: -20 to 40°C
Operating Humidity: 5 to 95%
Storage Humidity: 5 to 95%
Readable 1D codes: Airline 2 of 5,Codabar, Codablock
A,Code 128,Code 11, Code 32,Code 39,Code 93,
EAN/UPC,EAN-8, EAN-13, Full ASCII Code 39,GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, HongKong 2 of 5（China post),Interleaved 2 of 5、RSS-14, RSS-LIMITED, RSS-EXPANDED, Straight 2 of 5 Industrial,Telepen, Trioptic Code,UPC-A, UPC-
E,MSI,Pharmacode,Matrix 2 of 5, Codablock F
Readable 2D codes: Data Matrix Code, HANXIN,Maxicode, MicroPDF417,QR Code,Aztec Code, Composite, DOT_CODE

Set contents:

Code reader,
USB cable,
USB micro receiver,
Manual.

Features:

Scanning: manual (push-on) / automatic (when the code is brought closer)
Available interfaces: USB
Types of barcodes scanned: 1D and 2D barcodes, including QR and Aztec from paper labels and phone screens
Internal memory capacity: store up to 120K scanned codes
