DS Track Series Forest Design
FOREST DESIGN Series
The DS-XL® Series is designed to create visual impact and provides superior functionality and ease of use to
the end-user. Available as manual, corded or motorised operated curtain track system.
FOREST DS®
FOREST DS-XL®
FOREST DS-XL® Motorised
FOREST DS-XL® LED
FOREST DS-XL® LED Motorised
THE WORLD
BEHIND
YOUR
CURTAINS
FOREST DS® – DESIGN SYSTEM
The DS® curtain track system is for fans of a sleek
curtain track. This manually operated curtain
track system fits into any stylish interior with an
eye for design.
The DS® system has the same core dimension as the Klick
System (KS®). This makes it possible to use all KS® assembly
components (except the end caps).
The height of the track is 11 mm, and the curved elevation
of the profile has an ergonomically designed extension to
it so that the brackets can be mounted out of sight. Giving
you a clean almost recess finish to your system when being
utilised in a ceiling fix scenario.
FOR USE IN
Residential and/or contract market or at any location
where an elegant high quality design curtain track is
required.
PRODUCT INFORMATION
- Elegant and aesthetically pleasing hand drawn track system.
- For all types of medium weight draperies (max.curtain weight
8kg per meter). - Colours available: matt white, white, grey, anthracite,
matt black, black. - Available lengths in white: 4, 5, 6 & 7 meter (anthracite,
matt white, matt black in 6 meter). - Bendable, designer curtain track can be bent and reverse bent to
a tight 10cm radius, or continuously curved using a 50cm radius. - Matching assembly components for white, grey and black.
- Invisible ceiling brackets to fix track flush to ceiling available.
- Quick installation with “Smart Klick” brackets for wall and
ceiling applications. - Same brackets as used with Klick System.
- Heavy duty clickable carriers – UV protected – for smooth and
easy traversing. - Especially designed for use in combination with Forest Easyfold
System for wave pleat application. - Track finish: chromated powder coating with a factory applied
patented dry lubricant. - Warranty: 10 years.
1 DS Track
2 DS Carrier
3 DS Stop carrier
4 DS Twist end stop
5 DS End cap
MOUNTING
Smart Klick Aluminium wall bracket single
A) 7,5 cm B) 6,3 cm
A) 10 cm B) 8,8 cm
Smart Klick Aluminium wall bracket double
A) 15 cm B) 9,2 cm C) 4,5 cm
A) 20 cm B) 9,2 cm C) 9,5 cm
SPECIFICATIONS
• Shown actual size 1:1
• Weight:170 gr/meter
• Aluminium Extrusion
• Size: 12 x 24 mm
• Colours: white, matt-white, grey,
anthracite, black, matt-black
BENDING / CURVING
The track can be bent and reverse bent using a 10cm radius.
Continuous curving is available by special order from the
factory only.
APPLICATIONS
Smart Klick Aluminium wall bracket triple
A) 25 cm B) 9,3 cm C) 5 cm
FOREST DS-XL
With the DS-XL® Series, Forest offers curtain
tracks that optimally combines design and
functionality. The Design System XL gives every
interior an extra visual appearance.
Stylish curtains deserve an elegant and fashionable
curtain track. The DS-XL® Series provide a sleek finish
and contribute to a unique design look at home or in any
hotelroom.
Thanks to a symmetrical profile, the system can be mounted
“blind” to the ceiling. This provides an extra sleek finish. The
track is easy to mount by means of swivel supports or click
supports.
The DS-XL® track system has been especially designed for
use with our wave system, Forest Easyfold System. But it
is also suitable with regular pleated curtain headings
FOR USE IN
Hotels, offices, residences, boats, campers, planes or
anywhere an efficient and elegant track system is required
for curtains and drapes.
PRODUCT INFORMATION
- Elegant and aesthetical hand drawn and corded curtain
track system. - For all types of medium weight draperies.
- Quick and easy installation.
- Ceiling brackets and wall brackets available.
- Invisible ceiling brackets to fix track flush to ceiling
available. - Heavy duty carriers – uv protected – for smooth and easy
traversing. - Colours available: white, grey or anthracite with
matching assembly components. - Available length: standard stock size 6 meter (19.8”).
- Especially designed for use in combination with our wave
pleat system ‘Forest Easyfold System’ . - Warranty: 10 years.
PROFILE
- Shown actual size 1:1
- Weight: 480 gr/meter
- Aluminium extrusion
- Size: 60 x 15 mm
- Colours: white, grey, anthracite
FOREST EASYFOLD SYSTEM
The forest wave series are an Additional feature of the
drapery Hardware systems of forest group. It complies
fully with the Contemporary demand for Round and fluent
shapes in Decorative interiors.
It offers new possibilities for Applications in large and
High spaces, such as lobbies, entrees, reception areas,
conference rooms, auditoriums, meeting rooms, Food and
beverage outlets etc.
The system can be installed onto all forest manual, corded
(except cks) and Motorised tracks and curtain rod systems
and gives a modern and special folding design to the
curtain.
Such a modern curtain heading system Combined with
a suitable fabric is Guaranteed to be a real eye-catcher
In every room.
EASYFLEX/EASYWAVE TOOL
With this tool you will be able to easily calculate your
requirements of Easyflex carriers and Easyflex tape
to obtain a beautiful folding curtain. Please scan
the QR-code.
COLOUR OPTIONS
DS-XL® is available in three colours: white, grey and
anthracite.
FOREST DS-XL® LED / Motorised
This unique drapery system combines a stylish
design with a unique way of lighting. Many
designers will work with a lighting plan with three
levels: High, especially if the ceiling is vaulted
or has been finished with a special material;
medium, which includes wall sconces; and low,
which means floor lamps and other small lights.
Our DS-XL® LED is the solution for a lighting plan
on a higher level, integrating our track to create
an overall glow on the ceiling.
The DS-XL® LED is an elegant system for all types of
medium weight draperies. Available length up to 6 meter in
2 colours: timeless white and in a stylish anthracite finish,
making it suitable to fit in every design.
Create privacy
It also offers the possibility to illuminate the backside and/or
the curtain track itself enabling a higher level of privacy.
SUSTAINABLE LIGHTING
Traditional ways of lighting are very wasteful. Most of the
power is wasted in the form of heat. This is why there has
been a big push to change the environmental impact of
lighting. Another benefit of LED lighting is sustainability and
eco-friendliness. The system doesn’t use toxic chemicals
and it can last for years. It has a life span of approximately
30.000 hours.
PRODUCT INFORMATION
- Hand drawn or motorised curtain track system
- Designer track for lighting and curtain track combined.
- Colours available: white and anthracite.
- Especially designed for Forest Wave application.
- Simple electrical installation by means of clickable connectors.
- Ceiling brackets and wall brackets available.
- Supplied with 1 LED strip.
- LED Colour temperature: warm white 3000.
- Low energy consuming LED strip, eco friendly.
- Dimmable LED strips (120 LED’s per meter).
- LED lifespan of 30.000 hours.
- No soldering, clickable components for easy installation
without the need for an electrician. - Power: 10 watt/mtr.
- Energy label A+.
- The DS-XL® LED Motorised system can be integrated into
any building automation system. - The DS-XL® LED motorised track system can only be used
with a Forest Shuttle® S motor. - Warranty: 10 years (LED-lighting 2 years).
SPECIFICATIONS
- Shown actual size 1:1
- Size LED 61 x 20 mm
Size LED Motorised 61 x 25 mm - Weight LED 580 gr/meter
Weight LED Motorised 675 gr/meter - Aluminium extrusion
- Colours available: white or anthracite
DS-XL® LED MOTORISED
The DS-XL® LED Motorised track system is designed to
create visual impact and provides superior functionality
and ease of use to the end-user. Controlling the curtains
and integrated LED-lighting by remote control or building
automation system guarantees a unique experience of
atmosphere and comfort in any room.
RED DOT AWARD
The DS-XL® LED Motorised track system has been
awarded for the Red Dot Award 2021 for its outstanding
product design. The Red Dot Award is one of the most
internationally known and sought-after awards in the design
industry.
FOREST DS-XL® LED Control Options
Our wide range of controls make finding a fit for
your home even easier; controlling the curtains by
hand, remote or even by building automation system.
With the remote you can control the curtains in any
position you like. Controlling the motorised curtain
system by your smartphone or tablet, you can create
and schedule customised room scenes that allow your
curtains to operate on their own throughout the day.
FOREST DIAMOND SENSE REMOTE
15 or 2 Channel Remote control. Control
up to 15 systems individually and in
group by integrated timer function or
manual. Auto-On mode, when holding
hand above it, the integrated LED light
will automatically come on. Radio control,
range up to 30 meters. Including magnetic
wall support.
APP CONTROL VIA FOREST WIFI-DONGLE
With the Shuttle® Wi-Fi dongle, you can
control your motorised curtains with your
mobile device by the Forest Connect app
or even by voice command with the easy
integration in for example Google Home
or Amazon Echo without the need for an
additional hub or gateway.
APP CONTROL VIA FOREST WIRELESS CONNECTOR
The Forest Wireless Connector provides an
easy solution to make Forest motorised roman
blinds ‘smart.’ When combined with a smart
plug, you can effortlessly control the roman
blinds through a mobile app. Controlling the
motorised blind system by your smartphone
or tablet, you can create and schedule
customized room scenes that allow your
blinds to operate on their own throughout
the day.
If you prefer to use the Forest Connect
App, you can opt for Forest’s smart plug. If
you wish to operate your blinds with Apple
HomeKit, Amazon Alexa, or Google Assistant,
you will need a compatible third-party smart
plug that works with these smart home
apps. This RF device can also be seamlessly
integrated into the most common building
management systems, including systems with
dry contacts..
BUILDING AUTOMATION / HOTEL CONTROL
The DS-XL® System can be connected to any
Building Automation system, by relay control.
SMART DEVICE CONNECTIVITY
1) In combination with a smart plug
2) Only with FIBARO Roller Shutter 3 / Walli Roller Shutter
3) In combination with an AC Control Set
WORKS WITH
* Only works with actor.
Forest DS-XL® (LED) is compatible with many other Building
Automation systems, thanks to its modular construction.
A competitive advantage over other motorised drapery
systems in the world!
