Control iD iDFace Max Support Kit

Specifications

• Product Name: iDFace and iDFace Max Support Kit
• Manufacturer: Control iD
• Components: Various bolts, nuts, washers, mounting pieces, support subsets, flanges, adhesive hole covers, and facial protection pieces

FAQs

• Q: Can I use different-sized drill bits for installation?
  • A: It is recommended to use the specified drill bit sizes for accurate installation.
• Q: Are cables provided with the kit?
  • A: No, communication and ETH cables are not supplied with the kit.

Tools needed

To install the iDFace Kit in the turnstile, the following items will be needed: drill, bits (diameter of 3mm, 6mm and 10mm), hole saw (diameter of 35mm), rasp, 2mm and 2.5mm hex key, Phillips screwdriver, 8mm thin spanner (items not provided by Control iD).

iDFace Kit

Organize the parts and check if all parts needed are present and according to the quantity listed below:

• DIN7991 M3x10mm bolt (4x)
• DIN934 M5 nut (3x)
• DIN 125 Cut Washer Dia. 5mm (3x)
• DIN 127 Lock Washer Dia. 5mm (3x
  • Drilling template:
  • Support Subset (1x):
  • Support Flange (1x)
  • Facial Identification Access Controller Mounting Piece Subset (1x):
  • Facial Identification Access Controller Mounting Piece Subset (1x):
  • Mounting Piece Support (1x):
  • Adhesive Hole Cover(4x):
  • Facial Left Protection (1x):
  • Facial Right Protection (1x):

Installation

• Mount the devices and mark the positions of the holes according to the figure below:
• Execute the drillings:

If you have acquired iDBlock Bridge-Type with iDFace Max, it is not necessary to drill the cover, since the product is already drilled.

• Assemble the Support Subset:
• Mount the Support Flange:
• Bolt the Mounting Piece Support:
• Cable Passage:

Cables not supplied by Control iD.

• Mount Protections and Facial Identification Access Controller Fixing:
• Mount Support of the Facial Identification Access Controller Fixing:
• Mount the Facial Identification Access Controller Fixing:

MORE INFO

• Thank you for acquiring the support kit for the facial identification access controller.
• For detailed information on the use of your new support kit, access: https://www.controlid.com.br/userguide/idface-support-kit-en.pdf
• By using Control iD’s products, you are accepting the Terms and Conditions of Use and the Information on Personal Data Protection available on: www.controlid.com.br/legal/acessoeponto.pdf
