1. Important Safety Information
Please read all instructions before assembly and use of the BEKA Bassinet Bedside Sleeper. Keep this manual for future reference. Failure to follow these warnings and instructions could result in serious injury or death.
- Suffocation Hazard: Infants can suffocate in gaps between an extra mattress and the side of the bassinet/bedside sleeper, or on soft bedding. Use ONLY the mattress provided by the manufacturer. NEVER add a pillow, comforter, or another mattress for padding.
- Fall Hazard: To prevent falls, do not use this product once the infant begins to push up on hands and knees, or has reached the maximum weight of 15 pounds (6.8 kg), whichever comes first.
- Ensure the bassinet is always placed on a firm, horizontal surface.
- When used in bedside sleeper mode, ensure the bassinet is securely attached to the adult bed using the provided straps, and there are no gaps between the bassinet and the adult mattress.
- Keep small parts away from children during assembly.
- Regularly check all fasteners and connections to ensure they are tight and secure.
2. Package Contents
Verify that all components are present before beginning assembly:
- 1 x Bassinet Frame (with attached fabric)
- 1 x Integrated Supporting Board
- 1 x Cotton Mattress
- 4 x Dual-Function Feet
- 2 x Support Tubes
- 1 x Storage Bag
- 4 x Straps
3. Setup and Assembly
The BEKA Bassinet Bedside Sleeper is designed for tool-free quick setup. Follow these steps for assembly:
- Unfold the Frame: Carefully remove the bassinet frame from the storage bag. Unfold the frame until it locks into place.
- Attach Support Tubes: Insert the two support tubes into the designated slots on the bassinet frame. Ensure they click securely into position.
- Install Dual-Function Feet: Attach each of the four dual-function feet to the bottom of the support tubes. Ensure they are firmly attached.
- Insert Supporting Board: Place the integrated supporting board at the bottom of the bassinet.
- Place Mattress: Lay the cotton mattress on top of the supporting board. Ensure it fits snugly within the bassinet.
Image: Visual guide for the 4-step tool-free quick setup process, showing the bassinet folded, partially unfolded, legs attached, and fully assembled.
4. Operating Instructions
4.1. 2-in-1 Convertible Mode (Bassinet & Bedside Sleeper)
The BEKA Bassinet offers two modes for versatile use:
- Standalone Bassinet Mode: For independent use, ensure both mesh sides are zipped up and secured. This provides a safe and enclosed sleeping space.
- Bedside Sleeper Mode: To use as a bedside sleeper, unzip and lower one side panel. This allows for easy access to your baby for feeding, comforting, and diaper changes. Ensure the second layer is reinforced with its zipper-secured structure for stability.
Image: The BEKA Bassinet in its standalone configuration, showing both mesh sides fully raised.
Image: The BEKA Bassinet positioned next to an adult bed, with one side panel lowered for bedside sleeper functionality. The image highlights the interior gap-free seal and exterior full-wrap for anti-side tilting defense.
4.2. Height Adjustment
The bassinet offers 4 adjustable height positions, ranging from 28 to 31 inches, with 1-inch spacing between each level. This allows it to fit various adult bed heights.
- To adjust the height, locate the adjustment buttons on each leg.
- Press the buttons and simultaneously slide the legs up or down to the desired height.
- Ensure both sides are adjusted to the same height and click securely into place before placing your baby in the bassinet.
Image: A visual representation of the bassinet's adjustable height, showing minimum (28 inches) and maximum (31 inches) settings, suitable for various bed types like platform, standard, box-spring, and pillow-top.
4.3. Moving and Locking
The bassinet features auto-lock wheels for safe and smooth movement.
- To Move: Slightly lift one side of the bassinet. The supporting feet will convert into wheels, allowing for easy transport.
- To Lock: Once all four legs are placed firmly on the floor, the wheels automatically retract into the feet, providing a strong grip and improved stability. This eliminates the need for manual wheel locks.
Image: A split image showing a user lifting the bassinet to engage the hidden gravity casters for movement, and dropping it to lock the wiggle-proof grip for stability.
4.4. Securing to Adult Bed (Bedside Sleeper Mode)
When using the bedside sleeper mode, it is crucial to secure the bassinet to the adult bed using the provided straps to prevent gaps and ensure stability.
- Position the bassinet next to the adult bed with the lowered side facing the bed.
- Thread the four high-tensile safety straps under the adult mattress.
- Securely fasten the straps to the bassinet frame, ensuring a rigid, zero-gap lock between the bassinet and the adult bed.
- Verify that there are no gaps between the bassinet and the adult mattress that could pose a suffocation hazard.
Image: A parent interacting with a baby in the bassinet, which is securely attached to the adult bed using four safety straps, demonstrating the zero-gap heavy-duty locking mechanism.
5. Maintenance and Care
Proper maintenance ensures the longevity and hygiene of your BEKA Bassinet.
- Mattress Cover: The cotton mattress cover is removable and machine washable. Use a gentle cycle with cold water and mild detergent. Air dry or tumble dry on low heat.
- Bassinet Fabric (Attached): Spot clean the attached bassinet fabric with a damp cloth and mild soap. Do not machine wash the entire frame with fabric attached.
- Frame: Wipe the carbon steel and plastic frame components with a damp cloth. Avoid abrasive cleaners.
- Storage: When not in use, disassemble the bassinet and store it in the provided storage bag in a cool, dry place.
Image: A composite image illustrating the washable fabric cover being removed, the 360-degree breathable mesh sides, and the compact size of the bassinet in a living space.
Image: A person carrying the lightweight, folded bassinet in its storage bag, demonstrating its easy storage and travel-friendly design.
6. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Bassinet feels unstable or wobbly. | Legs not fully extended or locked. | Ensure all four dual-function feet are fully extended and clicked into their locked position on a flat surface. Check that height adjustments are even on both sides. |
| Difficulty moving the bassinet. | Not lifted correctly to engage wheels. | Slightly lift one side of the bassinet to engage the auto-lock wheels. Do not drag the bassinet without lifting. |
| Gaps between bassinet and adult bed in bedside mode. | Straps not securely fastened or bassinet not positioned correctly. | Re-position the bassinet flush against the adult bed. Ensure the safety straps are tightly secured under the adult mattress and to the bassinet frame. Adjust bassinet height to match the adult mattress height. |
| Side panel does not lower smoothly. | Zipper obstruction or fabric misalignment. | Check for any fabric caught in the zipper. Ensure the zipper is fully unzipped before attempting to lower the panel. |
7. Specifications
| Model Number | QX-831 |
| Product Dimensions (L x W x H) | 31" x 24" x 38" |
| Adjustable Height Range | 28" to 31" (4 levels) |
| Item Weight | 18 Pounds (8.16 kg) |
| Maximum Weight Recommendation | 15 Pounds (6.8 kg) |
| Material | 100% Polyester (fabric), Carbon Steel, Plastic |
| Color | Beige |
| Assembly Required | Yes (Tool-free) |
| Special Features | 2-in-1 Functions (bedside sleeper, bassinet), Portable (18lbs lightweight), Easy to Clean, Removable & Washable Cotton Mattress, Dual-function Wheels/Feet, 360° Breathable Mesh for Airflow |
8. Warranty and Support
The BEKA Bassinet Bedside Sleeper comes with a 2-year warranty from the date of purchase.
For warranty claims, technical support, or any questions regarding your product, please contact BEKA customer service through the retailer where the product was purchased or visit the official BEKA brand store online.
Online Brand Store: BEKA Store on Amazon
