JOYRACER 24V 2 Seater Electric Dump Truck User Manual

1. Introduction

The JOYRACER 24V 2 Seater Electric Dump Truck is designed to provide an engaging and fun driving experience for children. This electric construction vehicle features powerful motors, a durable battery, and an automatic lifting dump bed with an included shovel, allowing for interactive play. It offers both manual and parental remote control modes for versatile operation.

2. Safety Information

• Always supervise children while using this ride-on car.
• Ensure the safety belt is fastened and doors are locked before operation.
• Use the vehicle only on flat, stable surfaces, away from roads, pools, or steep inclines.
• Regularly check the vehicle for any damage, loose parts, or worn components. Discontinue use if any issues are found and contact customer support.
• Do not allow children to stand in the vehicle or climb on it while it is in motion.
• Keep hands, hair, and clothing away from moving parts.
• Only use the provided charger and battery. Do not modify the electrical system.

3. What's in the Box

Your JOYRACER 24V 2 Seater Electric Dump Truck package includes the following components:

• Main Car Body
• 24V 7AH Battery & Charger
• 2x200W Motors
• 2.4G Remote Control
• Shovel & Red Gift Pull Bow
• Other Accessories (wheels, steering wheel, mirrors, etc.)

4. Assembly Instructions

Please follow these steps carefully to assemble your JOYRACER 24V 2 Seater Electric Dump Truck. For a visual guide, refer to the assembly video below.

1. Unboxing and Initial Setup: Carefully open the packaging and remove all components. Locate the battery compartment, typically under the seat, and connect the battery terminals if they are disconnected for shipping.
2. Install Front Bumper Guards: Attach the blue bumper guards to the front of the truck using the provided screws and screwdriver. Ensure they are securely fastened.
3. Attach Rear Axle Support: Secure the metal support bracket for the rear axle using screws and pliers as shown in the video.
4. Install Rear Wheels: Slide the rear wheels onto the axle. Secure each wheel with a washer and nut, then cover with the blue hubcap. Repeat for both sides.
5. Connect Motors: Connect the motor wires to the corresponding ports on the vehicle's underside. Ensure a secure connection.
6. Install Dump Bed: Position the dump bed onto the rear of the truck. Secure it by inserting the pivot pins and then fastening them with the provided screws. Attach the blue side supports to the dump bed.
7. Install Steering Wheel: Connect the steering wheel's electrical connector to the dashboard port. Carefully slide the steering wheel onto the steering column until it clicks into place.
8. Attach Side Mirrors and Shovel Holder: Insert the side mirrors into their designated slots. Attach the shovel holder to the side of the dump bed.
9. Secure Seat: Place the seat back into position and secure it with screws. Ensure the safety belts are accessible.
10. Final Checks: Verify all connections are secure and all screws are tightened. Ensure the battery is fully charged before first use.

5. Operating Instructions

Familiarize yourself with the controls and features of your JOYRACER dump truck.

5.1 Powering On and Driving Modes

• Start/Stop Button: Press the 'Start/Stop' button on the dashboard to power on the vehicle. You will hear an engine sound.
• Manual Mode: Children can drive the truck using the steering wheel and foot pedal. The vehicle offers two speeds for independent control.
• Remote Control Mode: Parents can override manual control using the 2.4G remote control. The remote allows for three adjustable speeds and full directional control (forward, backward, left, right) with an emergency brake function.

Figure 1: Two Driving Modes. The truck can be operated by the child or controlled by a parent using the remote.

5.2 Automatic Lifting & Dumping Bed

The dump bed can be automatically lifted and lowered using the dedicated switch on the dashboard. This feature allows children to transport and dump materials like sand or leaves, enhancing imaginative play.

Figure 2: Electric Tipping Bucket. The dump bed can be raised and lowered with a switch.

5.3 Multimedia Features

The truck is equipped with music, Bluetooth connectivity, and USB/MP3 input for entertainment during playtime. Use the controls on the dashboard to manage audio playback.

Figure 3: Drive With Music. Enjoy built-in music or connect your own devices via Bluetooth or USB/MP3.

5.4 Charging the Battery

Locate the charging port, typically near the battery compartment or under the seat. Connect the provided charger to the port and plug it into a standard wall outlet. The indicator light on the charger will show the charging status. Do not overcharge the battery.

6. Product Features

• Powerful 24V System: Equipped with a 24V 7AH battery and two 200W motors, providing ample power for various terrains and a maximum speed of 4.9 MPH.
• Two-Seater Design: Features a spacious 20-inch seat with safety belts, accommodating two children or one larger child up to 110 lbs.
• Electric Dump Bed with Shovel: The automatic lifting dump bed and included shovel allow for realistic construction play.
• Versatile Driving Modes: Offers both child-controlled manual driving with two speeds and parental remote control with three adjustable speeds and emergency brake.
• Enhanced Safety: Includes a soft start system for smooth acceleration, a one-key start-up, safety belts, lockable doors, and spring suspensions for a secure ride.
• All-Terrain Wheels: Four large, wear-resistant wheels are designed for stability and traction on surfaces like grass, asphalt, cement, and rubber floors.
• Multimedia Entertainment: Integrated music, Bluetooth connectivity, and USB/MP3 input provide entertainment options.

Figure 4: Powerful Engine. The truck is powered by two 200W motors and a 24V 7Ah battery.

Figure 5: Wide Dump Bed with Shovel. Perfect for hauling sand or other materials.

Figure 6: Wear-Resistant Tires. Designed for various terrains including grass, cement, asphalt, and rubber floors.

7. Specifications

Figure 7: Product Dimensions and Capacity. This diagram provides key measurements and usage guidelines.

8. Maintenance

• Cleaning: Wipe the vehicle with a soft, damp cloth. Avoid using harsh chemicals or abrasive cleaners. Do not spray water directly onto electrical components.
• Battery Care: Charge the battery fully after each use. If storing for an extended period, charge the battery at least once a month to prolong its lifespan. Do not store the battery in extreme temperatures.
• Storage: Store the vehicle in a dry, cool place away from direct sunlight and moisture.
• Regular Inspection: Periodically check all screws, nuts, and connections to ensure they are tight. Inspect tires for wear and tear.

9. Troubleshooting

• Vehicle Not Starting: Check if the battery is connected and fully charged. Ensure the power button is pressed. Verify all electrical connections are secure.
• Low Power/Slow Speed: The battery may need charging. Check for any obstructions around the wheels or motors.
• Remote Control Not Working: Ensure the remote control has fresh batteries and is properly paired with the vehicle. Check for any interference.
• Unusual Noises: Stop using the vehicle immediately and inspect for loose parts, debris in the wheels, or motor issues.

10. Warranty and Support

JOYRACER is committed to customer satisfaction. If you have any questions regarding the assembly, operation, or maintenance of your product, please do not hesitate to contact us.

Contact Information:

• Login to your Amazon account.
• Go to "Your Orders".
• Find the order ID for your JOYRACER Dump Truck.
• Click "Contact Seller" (Seller: Stormwave).

We offer 24-hour online support to assist you.
