AKIRES 8980CFM Evaporative Air Cooler (55-inch) Instruction Manual

Important Safety Instructions

Please read and understand all safety instructions before operating this appliance. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• Always unplug the unit from the power outlet before cleaning, servicing, or moving.
• Do not operate the unit with a damaged cord or plug. If the cord or plug is damaged, contact qualified service personnel for repair.
• Do not run power cord under carpeting or cover with throw rugs, runners, or similar coverings. Arrange cord away from traffic areas where it will not be tripped over.
• Do not use the unit in areas where gasoline, paint, or other flammable liquids or vapors are stored.
• Do not insert fingers or foreign objects into the air inlet or outlet.
• Ensure the unit is placed on a stable, level surface to prevent tipping.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Use only clean water in the water tank.
• Do not immerse the unit in water or other liquids.

Product Overview

The AKIRES 8980CFM Evaporative Air Cooler is designed to provide efficient cooling for large areas up to 1800 sq ft. It functions as a fan, water cooler, and ice cooler, offering versatile cooling options. Its robust galvanized iron construction ensures durability for various environments.

Key Features:

• High Air Volume: Delivers 8980 CFM (Cubic Feet per Minute) of airflow, suitable for spaces up to 1800 sq ft.
• Wide Oscillation: Features 120° oscillation for broad air distribution.
• 3-in-1 Functionality: Operates as a fan, water cooling unit, and ice cooling unit.
• Triple Air Intake Panels: Enhances evaporation for faster and stronger cooling.
• Large Water Tank: Equipped with a 36-gallon water tank for extended operation.
• 4-in-1 Composite Ice Curtain: Improves cooling efficiency and filters impurities.
• Dual Water Fill Options: Supports both manual and continuous water filling via a garden hose.
• Portability: Includes four 360° swivel wheels (two with locks) for easy movement.
• Durable Construction: Made with a galvanized iron body for enhanced longevity.

Included Components:

• AKIRES Evaporative Air Cooler (1 unit)
• 360° Swivel Wheels (4 units)
• User Manual (1 unit)
• Ice Packs (3 units)

Image: The AKIRES 8980CFM Evaporative Air Cooler, 55-inch model, showcasing its design and size.

Image: A diagram illustrating the 3-in-1 functionality of the evaporative cooler, highlighting its ability to cool air, add humidity, and increase airflow.

Image: A close-up view of the evaporative cooler, detailing the three air intake panels designed for efficient cooling.

Setup

1. Caster Wheel Installation

The unit comes with four 360° swivel casters for easy mobility. Two of these casters include brakes for securing the unit in place.

1. Carefully tilt the unit to access the bottom.
2. Insert each caster stem into the designated holes on the bottom of the cooler.
3. Ensure the casters with brakes are installed on the front side of the unit for easy access.
4. Press firmly until each caster is securely in place.

Image: The evaporative cooler with its handles and 360° swivel casters, demonstrating its portability and overall dimensions.

2. Initial Water Fill

The unit offers two methods for filling the 36-gallon water tank: manual top fill and continuous garden hose fill.

Manual Top Fill:

1. Open the top lid of the cooler.
2. Pour clean water directly into the top water tank until the desired level is reached. Do not overfill.
3. Alternatively, for smaller additions, use the lower tank fill port.

Continuous Fill (Garden Hose):

1. Locate the continuous fill port on the side of the unit.
2. Attach a standard garden hose to the adapter (adapter is included).
3. Connect the garden hose to the continuous fill port.
4. Turn on the water supply. The built-in float will automatically control the water level.

Image: Visual guide demonstrating the various water filling methods for the 36-gallon tank, including top fill, lower tank fill, and continuous garden hose connection.

Operation

1. Powering On and Basic Fan Function

1. Ensure the unit is plugged into a grounded 120V power outlet.
2. Press the POWER button on the control panel to turn the unit on.
3. Use the SPEED buttons (1, 2, 3) to select your desired fan speed.

2. Water Cooling Function

For evaporative cooling, ensure the water tank is filled.

1. Verify the water tank has sufficient water. The visual water level indicator will show the current level.
2. Press the COOL button on the control panel to activate the water pump and start evaporative cooling.
3. To turn off water cooling, press the COOL button again.

3. Ice Cooling Function

For enhanced cooling, use the provided ice packs.

1. Place the ice packs in a freezer for 3-5 hours until completely frozen.
2. Open the top lid of the cooler.
3. Place the frozen ice packs into the designated slots within the filled water tank.
4. Activate the water cooling function by pressing the COOL button.

4. Oscillation Function

The unit features 120° oscillation to distribute cool air evenly.

1. Press the SWING button on the control panel to activate the automatic oscillation of the vertical louvers.
2. To stop oscillation, press the SWING button again.
3. The horizontal louvers can be adjusted manually to direct airflow vertically.

Maintenance

Regular maintenance ensures optimal performance and longevity of your evaporative air cooler.

1. Cleaning the Water Tank

1. Unplug the unit from the power outlet.
2. Locate the bottom drain plug and remove it to empty the water tank completely.
3. Clean the inside of the water tank with a soft cloth and mild detergent. Rinse thoroughly.
4. Replace the drain plug securely.

2. Cleaning the Cooling Pads (Ice Curtain)

The 4-in-1 composite ice curtain should be cleaned periodically to maintain efficiency.

1. Unplug the unit.
2. Carefully remove the air intake panels and then the cooling pads.
3. Rinse the cooling pads under running water to remove dust and mineral deposits. Do not use harsh chemicals.
4. Allow the pads to air dry completely before re-installing.

3. Exterior Cleaning

Wipe the exterior of the unit with a soft, damp cloth. Do not use abrasive cleaners or solvents.

4. Storage

When not in use for an extended period:

• Drain and clean the water tank and cooling pads thoroughly.
• Ensure all components are dry.
• Store the unit in a cool, dry place, away from direct sunlight and extreme temperatures.

Troubleshooting

If the problem persists after attempting these solutions, please contact customer support.

Specifications

Warranty and Support

For warranty information, product support, or service inquiries, please refer to the warranty card included with your product or visit the official AKIRES website. Keep your purchase receipt as proof of purchase.

Customer Support: For assistance, please contact AKIRES customer service through the contact information provided in your product packaging or on the official brand website.
