ARPHA D289H WiFi Smart Lock with Camera - Instruction Manual

Model: D289H | Brand: ARPHA

Setup

What's in the Box

The ARPHA D289H Smart Lock package includes all necessary components for installation and operation:

  • Exterior Assembly (Smart Lock with Keypad and Camera)
  • Interior Assembly (Battery Compartment and Thumb Turn)
  • Latch
  • Strike Plate
  • Mounting Plate
  • Installation Screws (various sizes)
  • Keys (x2)
  • Dingdong Machine (Doorbell Chime)
  • 4x AA Batteries (not included, alkaline recommended)
Components of the ARPHA D289H Smart Lock including exterior and interior units, latch, strike plate, mounting plate, screws, keys, and doorbell chime.
Figure 1: All components included in the ARPHA D289H Smart Lock package.

Pre-Installation Steps

Before beginning installation, ensure your door meets the required specifications. Measure the backset (distance from door edge to center of bore hole) and door thickness. The lock supports backsets of 60mm or 70mm and is suitable for 2-1/8" (54mm) door holes.

Diagram showing door dimensions and lock measurements for backset, door thickness, and handle dimensions.
Figure 2: Door and lock dimensions for proper fit and installation.

Installation

Follow these steps to install your ARPHA D289H Smart Lock. Ensure the deadbolt is correctly oriented with the 'UP' marking facing upwards. The lock is compatible with both left and right-handed doors.

Video 1: Detailed installation tutorial for the ARPHA D289H Smart Lock, covering all physical setup steps.
Image showing a person installing the smart lock with a screwdriver, highlighting latch hole and door compatibility.
Figure 3: Visual guide for easy installation, including door compatibility.
Image illustrating the smart lock's compatibility with both left and right-handed doors.
Figure 4: The smart lock is designed to be compatible with both left and right-swinging doors.

Initialization Setup

After physical installation, perform the initialization setup to ensure the lock functions correctly and calibrates to your door's orientation.

Video 2: Guide on how to perform the initial setup and calibration of the smart lock.

App Connection Settings

Connect your smart lock to the Tuya app for remote control, monitoring, and advanced features. Ensure your router supports a 2.4GHz Wi-Fi band as 5GHz is not compatible.

Video 3: Instructions for connecting the smart lock to the Tuya app via Wi-Fi.
Image showing the smart lock connected directly to a Wi-Fi router for instant access.
Figure 5: The smart lock supports direct Wi-Fi connectivity for remote access.

Operating Instructions

Unlocking Methods

The ARPHA D289H Smart Lock offers multiple convenient ways to unlock your door:

  • Fingerprint: Use your registered fingerprint for quick access.
  • Keypad PIN: Enter your personalized PIN code on the touchscreen keypad.
  • App Control: Unlock remotely via the Tuya app on your smartphone.
  • Backup Keys: Use traditional physical keys as a failsafe.
Four panels showing different unlocking methods: fingerprint, password, app control, and physical key.
Figure 6: Various methods available to unlock the smart lock.
A hand pressing a finger on the fingerprint scanner of the smart lock, with statistics on fingerprint capacity, identification speed, accuracy, and unlock time.
Figure 7: Fingerprint unlocking feature with performance metrics.

Auto-Lock Setting

Configure the auto-lock feature to automatically secure your door after a set period (10 seconds to 30 minutes) for enhanced security.

Video 4: Instructions for setting up the automatic locking function.

Remote Unlock

When a visitor presses the doorbell, you receive a notification on your smartphone. You can then view live video, communicate via two-way audio, and unlock the door remotely through the Tuya app.

Video 5: Demonstrates how to remotely unlock the door using the app after a doorbell press.
Image showing a person receiving a doorbell notification on their phone and viewing a live video feed of a delivery person at the door.
Figure 8: Real-time doorbell notifications and live video feed via the app.
Image depicting two-way audio communication between a person at the door and a person using the app indoors.
Figure 9: Two-way audio feature for communication with visitors.

Volume Setting

Adjust the volume of the lock's voice prompts and doorbell chime to your preferred level.

Video 6: Guide on how to adjust the volume settings of the smart lock.

Doorbell Settings

Customize your doorbell settings, including ringtones and notification preferences, through the lock's interface or the app.

Video 7: Instructions for configuring the doorbell settings.

Constant Open Setting

Activate the constant open mode when you need the door to remain unlocked for an extended period, such as during a party or moving furniture.

Video 8: How to enable and disable the constant open setting for the smart lock.

Adding Users

Add new users with unique passwords or fingerprints to grant access to family members or trusted individuals.

Video 9: Step-by-step guide on adding new users to the smart lock system.

Password Settings

Manage and configure various password types, including temporary and one-time passwords, for flexible access control.

Video 10: Instructions for setting and managing passwords on the smart lock.

Fingerprint Settings

Enroll and manage fingerprints for quick and secure biometric access.

Video 11: Guide on how to add and manage fingerprints for the smart lock.

Maintenance

Low Battery Alert

The smart lock will provide a low battery alert when power is running low. Replace the 4x AA alkaline batteries promptly. Note that the emergency power supply port is for temporary power only and cannot charge the batteries or transfer data.

Image showing a smartphone app displaying a low battery alert for the smart lock, with a USB cable connected for emergency power.
Figure 12: Low battery alert notification and emergency power port usage.

Durable Design

The ARPHA D289H Smart Lock features a durable, weatherproof design (IP65 rated) capable of withstanding extreme temperatures from -31°F to 158°F, ensuring reliable operation in various weather conditions.

Image of the smart lock partially covered in snow, illustrating its durable and weatherproof design.
Figure 13: The smart lock's durable and weatherproof construction.

Troubleshooting

If you encounter any issues with your ARPHA D289H Smart Lock, please refer to the troubleshooting section within the Tuya app or contact customer support for assistance. Common issues often relate to Wi-Fi connectivity (ensure 2.4GHz band) or battery levels.

Product Specifications

FeatureSpecification
BrandARPHA
Model NumberD289H
Lock TypeBiometric, WIFI
Special FeaturesApp Unlock, Camera, Fingerprint, WiFi
Connectivity ProtocolBLE, Wi-Fi (2.4GHz only)
Control MethodApp
MaterialZinc
ColorBlack
Item Dimensions (L x W x H)5.8 x 2.3 x 1.57 inches
Item Weight3 Pounds
Recommended UsesHome
Included ComponentsMounting screws, Front and rear lock mechanism, Handle set (interior/exterior), Installation guide

Warranty and Support

The ARPHA D289H Smart Lock comes with an 18-month warranty. For any product inquiries, technical support, or warranty claims, please refer to the contact information provided in your product packaging or visit the official ARPHA website.
