1. Introduction
This manual provides detailed instructions for the assembly, operation, maintenance, and troubleshooting of your Novilla King Bed Frame, Model B-F12007B-K-WH. Please read all instructions carefully before assembly and use to ensure proper setup and safe operation.
Image 1.1: Novilla King Bed Frame, White Velvet.
2. Safety Information
Please observe the following safety guidelines:
- Do not exceed the maximum weight capacity of 1000 lbs.
- Exercise caution when adjusting the headboard height to prevent injury.
- Always use the provided tools carefully during assembly.
- Ensure all screws and fasteners are securely tightened before use and periodically check for tightness.
- Keep small parts away from children during assembly.
3. Package Contents
Verify that all components are present before beginning assembly. If any parts are missing or defective, please contact customer support.
- Headboard
- Side Rails (Left and Right)
- Footboard
- Wooden Slats (10 evenly spaced)
- Support Legs (14 total)
- Hardware Pack (screws, washers, Allen wrench)
- Installation Manual (this document)
Image 3.1: Detailed dimensions and component layout of the King Bed Frame.
4. Setup (Assembly Instructions)
Assembly typically requires two individuals and can be completed in approximately 20 minutes. Follow the step-by-step instructions provided in the included installation manual.
Key Assembly Steps:
- Unpack Components: Carefully remove all parts from the packaging and lay them out on a clean, soft surface to prevent scratches.
- Attach Legs: Fix the support legs to the frame sections (headboard, footboard, side rails) using the provided screws and tighten them with the included tools.
- Connect Frame Sections: Assemble the headboard, footboard, and side rails to form the main bed frame structure. Ensure all connections are secure.
- Install Slats: Position the wooden slats evenly across the frame. The slats are designed with Velcro for easy placement and are reinforced with screws to prevent movement and noise.
- Final Tightening: Double-check all screws and fasteners to ensure they are fully tightened for stability.
Image 4.1: Illustration of the 14 solid leg support design for enhanced stability.
Image 4.2: Detail of the wooden slat system, showing Velcro and screw reinforcement for mattress support.
5. Operating Instructions
5.1 Adjustable Headboard
The headboard features an adjustable height mechanism, allowing it to be set between 35.6 inches and 49.5 inches. This adjustability accommodates mattresses with a thickness ranging from 8 to 14 inches, ensuring a proper fit and aesthetic.
Image 5.1: Headboard height adjustment range.
Image 5.2: Recommended mattress thickness for optimal fit.
5.2 Mattress Support
This bed frame is designed to be used without a box spring. The hardwood frame, high-density foam edge padding, and 10 wooden slats provide robust support for your mattress.
5.3 Under-Bed Clearance
The frame offers approximately 6.3 inches of clearance beneath, providing ample space for under-bed storage solutions.
6. Maintenance
Proper maintenance ensures the longevity and appearance of your bed frame.
- Cleaning: For the velvet upholstered surfaces, gently vacuum with a soft brush attachment to remove dust. For spills, blot immediately with a clean, dry cloth. Avoid harsh chemicals or abrasive cleaners.
- Fastener Check: Periodically (e.g., every 3-6 months), inspect all screws and bolts and tighten them as necessary to maintain structural integrity and prevent squeaking.
- Frame Inspection: Regularly check the wooden slats and support legs for any signs of wear or damage.
Image 6.1: Detail of the premium velvet headboard, highlighting material for care.
Image 6.2: Example of thick and solid wood components used in the frame construction.
7. Troubleshooting
Refer to this section for common issues and their solutions.
- Squeaking/Noise:
Solution: Ensure all assembly screws and bolts are securely tightened. The Velcro-secured slats are designed to minimize noise; verify they are properly seated and not damaged. - Wobbling Frame:
Solution: Check that all connections between the headboard, footboard, and side rails are firm. Confirm that all support legs are making even contact with the floor. - Missing or Defective Parts:
Solution: If you discover any missing or defective components upon unboxing, please contact Novilla customer support immediately for assistance. Refer to the contact information provided in this manual or on the product packaging.
8. Specifications
| Feature | Detail |
|---|---|
| Model Number | B-F12007B-K-WH |
| Size | King |
| Product Dimensions (L x W x H) | 81.9" x 77.2" x 43.5" |
| Adjustable Headboard Height | 35.6" to 49.5" |
| Recommended Mattress Thickness | 8" - 14" |
| Color | White Velvet |
| Weight Capacity | 1000 lbs |
| Assembly Required | Yes |
| Included Components | Headboard, Installation Manual |
| Item Weight | 65.6 pounds |
| GTIN | 00840509809878 |
9. Warranty Information
Specific warranty details for the Novilla King Bed Frame are typically provided with the product packaging or can be found on the official Novilla website. Please refer to these sources for comprehensive warranty terms and conditions.
10. Customer Support
For any questions, assistance with assembly, or to report missing/defective parts, please contact Novilla customer support. Contact information is usually available on the product packaging, the cover of the installation instructions, or the official Novilla website.
