1. Product Overview
The jeeber 816pro is a 1080P WiFi Baby Monitor designed to provide continuous monitoring of your baby. It features a camera with pan-tilt-zoom capabilities, a 4-inch IPS display, HD night vision, and various detection functions including motion and cry detection. The system supports dual control via the dedicated monitor unit and a mobile application, offering flexibility for monitoring both at home and remotely.
Image 1.1: The jeeber 816pro Baby Monitor system, showing the camera unit, the 4-inch IPS display monitor, and a smartphone screen displaying the app interface.
1.1 Key Features
- Dual Control: Monitor via the 4-inch IPS display or a smartphone application simultaneously.
- Wide Coverage: 340° pan and 70° tilt with 3x zoom for a 360° view of the nursery.
- HD Night Vision: 5M Auto-IR night vision for clear visibility in low light conditions.
- Real-Time Alerts: VOX cry detection and motion detection send instant notifications.
- Two-Way Talk: Built-in microphone and speaker for remote communication with your baby.
- Lullabies: Pre-set lullabies can be played remotely to soothe your baby.
- Temperature Sensor: Monitors nursery temperature to ensure a comfortable environment.
- Long Battery Life: Up to 14 hours of continuous screen use on the monitor unit.
- Secure Transmission: AES encrypted signal and FHSS technology for privacy and stable connection.
1.2 Package Contents
- Baby Camera Unit
- Baby Monitor Unit (with 4-inch IPS Screen)
- Charging Cable (for both units)
- User Manual (this document)
2. Safety Information
Please read and understand all safety instructions before using the jeeber 816pro Baby Monitor. Failure to follow these instructions may result in injury or damage to the product.
- Strangulation Hazard: Keep all cables and cords out of reach of children (at least 3 feet / 1 meter away). Never place the camera or cords within the crib or playpen.
- Choking Hazard: This product contains small parts. Keep all components and packaging materials away from children.
- Overheating: Do not cover the monitor or camera with clothing, blankets, or any other material. Ensure proper ventilation.
- Water and Moisture: Do not expose the product to water or moisture. Do not use near bathtubs, sinks, laundry tubs, swimming pools, or wet basements.
- Power Sources: Use only the provided charging cables and power adapters. Using unauthorized chargers may damage the product and void the warranty.
- Placement: Place the camera on a stable, flat surface or securely mount it to a wall. Ensure it is positioned to provide a clear view of the baby without being directly above the crib.
- Interference: Keep the monitor and camera away from other electronic devices that may cause interference, such as microwaves or Wi-Fi routers.
- Temperature: Operate the device within the recommended temperature range (typically 0°C to 40°C / 32°F to 104°F).
- Adult Supervision: This product is intended to assist in monitoring your baby and should not replace proper adult supervision.
3. Setup Guide
3.1 Charging the Monitor Unit
Before first use, fully charge the monitor unit. Connect the provided charging cable to the monitor unit and a power adapter (not always included, but typically a standard USB power adapter). The battery indicator on the screen will show charging status. A full charge provides up to 14 hours of continuous use.
3.2 Positioning the Camera
Place the camera unit on a flat, stable surface in the nursery, ensuring it has a clear, unobstructed view of your baby's crib or play area. Keep the camera and its power cord at least 3 feet (1 meter) away from the crib to prevent strangulation hazards. The camera can also be wall-mounted (mounting hardware not included).
Image 3.1: Proper placement of the camera unit on a surface near the crib, ensuring a clear view.
3.3 Pairing Camera and Monitor
The camera and monitor units are typically pre-paired at the factory. Simply power on both units, and they should automatically connect. If they do not connect, or if you are adding an additional camera (sold separately), follow these steps:
- Turn on the monitor unit.
- Access the monitor's menu and navigate to the "Camera" or "Pairing" option.
- Select "Add Camera" or "Pair".
- Within 10 seconds, press and hold the pairing button on the back of the camera unit until the monitor indicates successful pairing.
3.4 Connecting to Mobile App (Optional)
For remote viewing and additional features, you can connect the camera to your home 2.4GHz Wi-Fi network and use the companion mobile application.
- Download the "FeelBaby" app (or specified app name) from your smartphone's app store.
- Create an account and log in.
- Follow the in-app instructions to add a new device. This typically involves scanning a QR code on the camera or monitor, or manually entering device details.
- Ensure your smartphone is connected to a 2.4GHz Wi-Fi network during the setup process.
Image 3.2: Illustration of dual control, allowing monitoring via the dedicated screen at home or the mobile app when outdoors (requires 2.4GHz WiFi for app viewing).
4. Operating Instructions
4.1 Monitor Unit Controls
The monitor unit features a 4-inch IPS screen and several buttons for control:
- Power Button: Press and hold to turn on/off. Short press to turn screen on/off.
- Menu Button: Access the main menu for settings.
- Navigation Buttons (Up/Down/Left/Right): Navigate through menus and control camera pan/tilt.
- OK Button: Confirm selections.
- Zoom Button: Magnify the video feed (up to 3x).
- Volume Buttons: Adjust the audio volume.
- Talk Button: Press and hold to activate two-way talk.
- Lullaby Button: Play pre-set lullabies.
4.2 Camera Controls (Pan/Tilt/Zoom)
From the monitor unit, use the navigation buttons to remotely adjust the camera's viewing angle. Press the Up/Down buttons to tilt the camera (70° range) and Left/Right buttons to pan (340° range). Use the Zoom button to digitally zoom in on the image (up to 3x).
Image 4.1: The camera unit demonstrating its 340° pan and 70° tilt capabilities for comprehensive room coverage.
4.3 Night Vision
The camera is equipped with 5M Auto-IR night vision. This feature automatically activates in low-light conditions, providing a clear black-and-white image of your baby without disturbing them with visible light. The invisible 940nm infrared light ensures eye-safe operation.
Image 4.2: The camera unit with invisible infrared light, enabling clear night vision for monitoring a sleeping baby.
4.4 Two-Way Talk
To speak to your baby, press and hold the "Talk" button on the monitor unit. Release the button to listen. This feature allows you to comfort your baby remotely.
4.5 Lullabies
The monitor unit has a dedicated button to play pre-set lullabies through the camera's speaker. Press the "Lullaby" button to cycle through available melodies or turn them off. Adjust the volume of the lullabies via the monitor's menu.
4.6 Temperature Monitoring
The camera unit includes a temperature sensor that displays the nursery's ambient temperature on the monitor screen. You can set temperature alerts in the monitor's menu to be notified if the room temperature goes above or below a comfortable range.
4.7 VOX (Voice Operated Exchange) Mode
VOX mode conserves battery life by turning off the monitor screen when no sound is detected from the baby's room. The screen will automatically activate when the camera detects sound (e.g., crying). You can adjust the VOX sensitivity level in the monitor's settings.
Image 4.3: The monitor unit displaying its auto-wake feature via VOX sound detection, activating the screen when the baby needs attention.
4.8 Motion and Cry Detection
The monitor can detect both motion and crying sounds. When enabled, these features will trigger alerts on the monitor unit and, if connected, send notifications to your mobile application. Sensitivity levels for both detections can be adjusted in the settings.
Image 4.4: A smartphone screen displaying an instant alert notification for baby motion detection from the FeelBaby app.
4.9 Feeding Reminder
Set up feeding reminders through the monitor's menu. This feature allows you to program alerts at specific intervals to help maintain a feeding schedule.
5. Maintenance
Proper maintenance ensures the longevity and optimal performance of your jeeber 816pro Baby Monitor.
- Cleaning: Wipe the camera and monitor units with a soft, dry, lint-free cloth. Do not use cleaning agents, solvents, or abrasive materials.
- Storage: If storing the device for an extended period, ensure both units are fully charged, then power them off. Store in a cool, dry place away from direct sunlight.
- Battery Care: To maximize battery life, avoid fully discharging the monitor unit frequently. Charge it regularly. Do not expose the battery to extreme temperatures.
- Lens Care: Gently clean the camera lens with a lens cleaning cloth if smudges affect image clarity.
6. Troubleshooting
Refer to the table below for common issues and their solutions.
| Problem | Possible Cause | Solution |
|---|---|---|
| No image on monitor screen | Camera or monitor is off; out of range; low battery. | Ensure both units are powered on and charged. Move monitor closer to camera. Re-pair units if necessary. |
| No sound or poor sound quality | Volume too low; interference; microphone blocked. | Increase monitor volume. Move units away from other electronics. Ensure camera microphone is clear. |
| Monitor loses connection frequently | Out of range; interference; weak Wi-Fi signal (for app). | Reduce distance between camera and monitor. Avoid obstacles. Ensure strong 2.4GHz Wi-Fi for app connection. |
| Night vision not clear | Camera lens dirty; insufficient ambient light for IR activation. | Clean the camera lens gently. Ensure the room is dark enough for automatic IR activation. |
| App connection issues | Incorrect Wi-Fi password; 5GHz Wi-Fi network; app not updated. | Verify Wi-Fi password. Ensure connection to a 2.4GHz Wi-Fi network. Update the mobile app to the latest version. |
7. Specifications
| Feature | Detail |
|---|---|
| Model Name | VB816 PRO |
| Video Capture Resolution | 1080p (supports 720P feed, up to 1080P display) |
| Monitor Screen Size | 4-inch IPS |
| Pan Angle | 340° |
| Tilt Angle | 70° |
| Zoom | 3x Digital Zoom |
| Night Vision | 5M Auto-IR (940nm Invisible Light) |
| Connectivity Technology | Wireless (FHSS for monitor, Wi-Fi for app) |
| Wi-Fi Frequency | 2.4GHz (for app connection) |
| Battery Life (Monitor) | Up to 14 hours (continuous screen use) |
| Special Features | 2-Way Audio, Cry Detection, Motion Detection, Temperature Sensor, Lullabies, Feeding Reminder |
| Material | Acrylonitrile Butadiene Styrene (ABS) |
| Item Dimensions (LxWxH) | 14 x 10.9 x 6.9 Centimeters |
| Item Weight | 621 g |
| Country of Origin | China |
8. Warranty and Support
The jeeber 816pro Baby Monitor comes with a manufacturer's warranty. Please refer to the warranty card included in your package or visit the official jeeber website for detailed warranty terms and conditions. Registering your product may extend your warranty period.
For technical support, troubleshooting assistance, or any inquiries regarding your product, please contact jeeber customer service. Contact information can typically be found on the product packaging, the official website, or within the mobile application.
When contacting support, please have your product model number (VB816PRO) and purchase details readily available.
