Feonase Metal Twin Over Twin Bunk Bed Instruction Manual

1. Important Safety Information

Please read and understand all instructions before assembling and using this bunk bed. Keep this manual for future reference.

• Always supervise children when they are using the upper bunk.
• Never allow children to jump or climb on the guardrail.
• Always assemble the bunk bed according to the provided instructions to ensure stability and prevent collapse.
• Ensure all connections are securely tightened before use and check periodically.
• The top bunk is not suitable for children under six years of age.
• Use only mattresses that are 4-6 inches thick and fit the bed dimensions (75"L x 39"W for Twin).

2. Product Overview

The Feonase Metal Twin Over Twin Bunk Bed is designed for durability and space efficiency. It features a robust metal frame with heavy-duty slats, providing stable support for two twin mattresses without the need for a box spring.

Key Features:

• Safety Guardrail: An 11.2-inch high guardrail with rounded corners ensures security on the upper bunk.
• Sturdy Construction: Tightly spaced metal slats provide strong support and enhance bed stability.
• Noise-Free Design: Mute buckles secure the bed frame steels, minimizing noise.
• Under-bed Storage: 12.2 inches of clearance beneath the lower bunk offers convenient storage space.
• Integrated Ladder: A 3-step square ladder provides easy access to the upper bunk.

Figure 2.1: Feonase Metal Twin Over Twin Bunk Bed (White). This image shows the fully assembled bunk bed with mattresses on both levels, highlighting its compact design.

Figure 2.2: Product Dimensions and Capacity. This diagram illustrates the overall dimensions of the bunk bed (77.5"L x 41"W x 63"H) and the weight capacity for the upper (600 lbs) and lower (800 lbs) bunks. It also indicates the material as wood & heavy-duty metal.

3. Components List

Before assembly, ensure all parts are present and undamaged. If any parts are missing or damaged, contact customer support.

• Bunk Bed Frame x 1 (various metal sections)
• Guardrails (pre-attached or separate sections)
• Robust Slats x 22
• Ladder components
• Hardware pack (screws, bolts, Allen wrench)
• Installation Manual (this document)

4. Setup and Assembly Instructions

Assembly is designed to be straightforward. It is recommended that two adults assemble the bunk bed. All parts are clearly labeled, and the instructions are provided in a step-by-step format. All necessary tools are included.

1. Unpack Components: Carefully remove all parts from the packaging. Lay them out on a clean, soft surface to prevent scratches. Verify all components against the parts list.
2. Assemble Base Frames: Begin by connecting the main frame sections for both the upper and lower bunks using the provided hardware. Ensure all bolts are finger-tightened initially.
3. Install Slats: Insert the 22 robust metal slats into the designated slots on both bed frames. Secure them using the mute buckles to minimize noise and enhance stability.
4. Attach Guardrails: Secure the guardrails to the upper bunk frame. The 11.2-inch high guardrail with rounded corners should be positioned for safe entry and exit.


   Figure 4.1: Thoughtful Safety Guardrail. This image highlights the 11.2-inch high guardrail, rounded guard corners, and open entrance for easier access to the upper bunk.

5. Connect Bunk Sections: Carefully stack the upper bunk frame onto the lower bunk frame, aligning the connection points. Secure them with the appropriate bolts.
6. Install Ladder: Attach the 3-step square ladder to the designated side of the bunk bed. Ensure it is firmly secured for safe climbing.
7. Tighten All Hardware: Once the entire structure is assembled, systematically tighten all Allen head bolts and screws using the provided wrench. Do not overtighten.
8. Attach Anti-Tipping Device: For added safety, secure the anti-tipping device to the bunk bed frame and the wall as instructed.


   Figure 4.2: Anti-Tipping Device and Assembly Features. This image shows the anti-tipping device for wall attachment, the 12-inch under-bed storage space, and a detail of the easy assembly mechanism.

9. Final Check: Confirm that the bed is stable, all parts are securely fastened, and there are no loose components.

5. Operating Instructions

This bunk bed is designed for sleeping and resting. Adhere to the following guidelines for safe operation:

• Mattress Placement: Place a twin-sized mattress (75"L x 39"W) with a thickness of 4-6 inches on both the upper and lower bunks.


  Figure 5.1: Mattress Recommendation. This image specifies the recommended mattress size (75"L x 39"W) and thickness (4-6 inches) for the bunk bed. It also illustrates the open entrance and 3-step ladder for conversion between bunks.

• Weight Capacity: The upper bunk has a maximum weight recommendation of 600 pounds. The lower bunk has a maximum weight recommendation of 800 pounds. Do not exceed these limits.
• Ladder Use: Always use the ladder for accessing the upper bunk. Do not climb on the frame directly.
• Guardrail Function: The guardrails are essential for safety on the upper bunk. Ensure they are always in place and undamaged.
• Under-bed Storage: Utilize the 12.2 inches of under-bed space for organizing items. Avoid overloading or obstructing the bed frame.

6. Maintenance

Regular maintenance will prolong the life and ensure the safety of your Feonase bunk bed.

• Cleaning: For general cleaning, wipe the metal frame with a dry cloth. For deeper cleaning, use a damp cloth with mild soap and water, then dry thoroughly. Avoid harsh chemicals or abrasive cleaners.
• Fastener Check: Periodically check all bolts and screws to ensure they remain tight. Retighten as necessary to maintain structural integrity.
• Slats Inspection: Inspect the metal slats regularly for any signs of damage or bending. Ensure they are properly seated within the frame's mute buckles.


  Figure 6.1: Reinforced Structure. This close-up shows the mute buckles that securely fasten the metal slats, reducing noise and providing stable support.

• Guardrail Integrity: Ensure guardrails are always secure and free from damage.
• Powder Coated Finish: The powder-coated finish provides rust and corrosion resistance. Avoid scratching the surface to maintain this protection.

7. Troubleshooting

If you encounter any issues with your bunk bed, refer to the following common solutions:

• Bed Wobbles or Shakes:
  • Ensure all assembly bolts and screws are fully tightened. A loose connection can cause instability.
  • Verify that the anti-tipping device is correctly installed and secured to the wall.
  • Check that the bed is placed on a level surface.
• Squeaking Noises:
  • Tighten all bolts and connections.
  • Ensure all metal slats are properly seated and secured by their mute buckles.
  • Apply a small amount of lubricant (e.g., silicone spray) to metal-on-metal contact points if tightening does not resolve the issue.
• Difficulty Assembling:
  • Re-read the assembly instructions carefully, paying attention to diagrams.
  • Ensure you are using the correct hardware for each step.
  • It is often easier to assemble with two people.

8. Specifications

9. Warranty and Support

Feonase is committed to providing high-quality products.

Warranty:

This product is typically covered by a standard return policy. For specific warranty details, please refer to your purchase documentation or the retailer's policy. Extended protection plans may be available for purchase separately.

Customer Support:

If you have any questions, require assistance with assembly, or need to report missing/damaged parts, please contact Feonase customer service.

• Online Support: Visit the official Feonase store on Amazon for FAQs and contact options.
• Email: Refer to your purchase invoice for direct customer service email.
