anyfree ML01 Wireless Doorbell Camera with Chime

Introduction

This manual provides detailed instructions for the setup, operation, and maintenance of your anyfree ML01 Wireless Doorbell Camera. Please read this manual thoroughly before installation and use to ensure optimal performance and safety.

Product Overview

The anyfree ML01 is a smart wireless video doorbell designed to enhance home security. It features HDR video quality, PIR motion detection with AI human recognition, dual-band Wi-Fi connectivity (2.4 GHz/5 GHz), and a solar-assisted battery for extended life. The device includes two-way audio, night vision, and local/cloud storage options.

Image: The anyfree ML01 Wireless Doorbell Camera and its accompanying chime unit.

What's Included

The package contains the following components:

• 1x Video Doorbell with Chime (main unit)
• 1x Signal Station with Chime (indoor unit)
• 1x USB cable (for charging)
• 1x Double-sided tape (for adhesive mounting)
• 2x Mounting brackets
• 1x Security Screw
• 2x Anchor screws
• 2x KA3*30 screws
• 2x KA3*10 screws
• Instruction Manual

Setup and Installation

The anyfree ML01 doorbell offers two primary installation methods: screw-in or adhesive mounting.

1. Prepare the Doorbell

• Before mounting, ensure the doorbell is fully charged using the provided USB cable.
• Activate the doorbell by removing the protective sticker from the battery compartment.

2. Choose Mounting Method

Screw-in Installation:

• Position the mounting bracket on your desired wall surface.
• Mark the screw holes.
• Drill pilot holes and insert the anchor screws if necessary.
• Secure the mounting bracket with the provided screws.

Adhesive Installation:

• Ensure the mounting surface is clean, dry, and smooth.
• Attach the double-sided tape to the back of the mounting bracket.
• Firmly press the bracket onto the desired location for a few seconds to ensure secure adhesion.

Image: Illustration of the two installation methods: screw-in and adhesive mounting for the doorbell.

3. Attach Doorbell to Bracket

• Slide the doorbell unit onto the mounted bracket until it clicks securely into place.

4. App Pairing and Wi-Fi Connection

• Download the companion mobile application (refer to the user manual for specific app name and QR code).
• Follow the in-app instructions to pair your doorbell camera with your smartphone.
• Connect the doorbell to your home Wi-Fi network. The device supports both 2.4 GHz and 5 GHz dual-band Wi-Fi for stable connectivity.
• Plug the indoor chime unit into a power outlet within range of the doorbell.

Operating Instructions

Live View and Two-Way Audio

• Access the live video feed from your doorbell camera through the mobile app.
• Use the two-way audio feature to communicate with visitors at your door from anywhere.

Image: A user interacting with a visitor via the two-way audio feature on the mobile app.

Motion Detection and AI Recognition

• The doorbell features PIR motion detection and AI human recognition to identify family members, couriers, and other individuals.
• Receive real-time notifications on your mobile device when motion is detected, with events categorized by visitor type.
• Adjust motion detection sensitivity and customize push notification times within the app.

Image: Visual representation of the AI recognition feature, identifying individuals and sending detailed notifications.

Night Vision

• The doorbell provides clear HDR night vision, allowing you to see visitors and packages clearly in low-light conditions.

Image: Comparison of daytime HDR video and infrared night vision from the doorbell camera.

Customizable Ringtones

• Select from various customizable ringtones for your indoor chime unit.

Storage Options

Local Storage

• The doorbell supports local storage via an SD card (up to 128GB, not included) for motion detection recordings without monthly fees.

Cloud Storage

• Unlimited cloud storage is available with a 90-day free trial. Recordings are categorized based on visitor type and event nature.

Image: Overview of local SD card storage and cloud storage options for recorded video clips.

Battery Management

The doorbell camera features a solar-assisted built-in battery (5800mAh). The solar panel extends battery life but does not fully replace USB charging. Regular USB charging may still be required.

Image: Diagram illustrating the solar-assisted battery charging mechanism and long standby time.

Security Features

Destruction Alarm and Privacy Protection

• If someone attempts to disassemble the doorbell, a disassembly alarm will trigger, and you will receive a phone notification.

Device Sharing

• The doorbell can be shared with up to 4 family members, allowing multiple users to monitor and receive notifications.

Image: Illustration of how the video doorbell can be shared with up to four family members for collective security.

Specifications

Troubleshooting

• Connectivity Issues: Ensure your Wi-Fi network (2.4 GHz or 5 GHz) is stable and within range. Try restarting your router and the doorbell.
• Battery Not Charging: While solar-assisted, the battery may require direct USB charging periodically. Ensure the USB cable is properly connected to a power source.
• False Motion Alerts: Adjust the motion detection sensitivity settings within the mobile app to reduce unwanted notifications.
• No Chime Sound: Verify the indoor chime unit is plugged into a working outlet and properly paired with the doorbell.

Warranty and Support

anyfree provides lifetime technical support for your product. For assistance, please contact:

• Live Chat: Open the 'Hello Doorbell' App > ABOUT/FAMILY > Talk to us
• After-Sales Email: info@anyfree.com
• Brand Web: anyfree.com > Contact Us
