LENCENT Universal Travel Plug Adapter - Mini-2AC Instruction Manual

1. Introduction

The LENCENT Mini-2AC Universal Travel Plug Adapter is designed to provide convenient power access for your electronic devices across various countries. This compact and lightweight adapter features dual AC outlets, including a universal socket and an extra 2-prong US outlet, allowing you to charge two devices simultaneously. It incorporates enhanced safety features to protect your devices during use.

Important Note: This adapter does NOT convert voltage from 110V to 220V or vice versa. Always check your device and destination voltage compatibility before use. A separate voltage converter may be required for single-voltage devices like hair dryers or styling irons.

2. Product Features

• Worldwide Compatibility: Covers over 200 countries with Type C (Europe), Type G (UK), Type I (Australia), and Type A (USA/Japan) plugs.
• Compact & Portable Design: Measures 2.1 x 2.1 x 1.9 inches and weighs 0.2 lbs (3.3 oz), making it easy to carry in any bag.
• Dual AC Outlets: Features a universal socket for global compatibility and an additional 2-prong US outlet for simultaneous charging.
• Enhanced Safety: Equipped with double 10A fuses for overload protection, safety shutters, and a plug lock system to prevent accidental shocks.

3. Setup and Usage

3.1 Deploying the Correct Plug Type

The LENCENT Mini-2AC adapter features retractable pins for various international plug types. To deploy the correct plug:

1. For Europe (Type C): Slide the 'EU' button forward to extend the two round pins.
2. For UK (Type G): Slide the 'UK' button forward to extend the three rectangular pins.
3. For USA/Australia (Type A/I): Slide the 'USA/AUS' button forward. The two flat pins for Type A (USA) will extend. To use Type I (Australia) plugs, rotate the flat pins 90 degrees.

After use, push the button on the side to retract the pins back into the adapter for compact storage.

Image: LENCENT Mini-2AC adapter with EU plug deployed. The adapter is shown with its two round European-style pins extended, ready for use.

Image: LENCENT Mini-2AC adapter with UK plug deployed. The adapter is shown with its three rectangular UK-style pins extended.

Image: LENCENT Mini-2AC adapter with USA/Australia plug deployed. The adapter is shown with its two flat pins extended, which can be rotated for Australian outlets.

3.2 Using the AC Outlets

The adapter features two AC outlets:

• Universal AC Socket: Located on the front face, this socket accepts various plug types from over 200 countries.
• 2-Prong US Outlet: Located on the side, this outlet is suitable for 2-prong US plugs.

Plug your device's power cord into the appropriate AC outlet. You can use both outlets simultaneously.

Image: LENCENT Mini-2AC adapter showing its universal AC outlet on the front, designed to accept various international plug types.

Image: LENCENT Mini-2AC adapter demonstrating compatibility with various electronic devices such as phones, tablets, and laptops.

4. Safety Information

• NO Voltage Conversion: This adapter does not convert voltage. Ensure your devices are dual-voltage compatible (100-250V) or use a separate voltage converter if needed. Failure to do so may damage your device or the adapter.
• Overload Protection: The adapter is equipped with double 10A fuses to protect against overloads. If the fuse blows, replace it with a new 10A fuse.
• Safety Shutters: Integrated safety shutters prevent foreign objects from being inserted into the outlets, enhancing user safety.
• Plug Lock System: The plug lock system ensures that the deployed pins remain securely in place during use.
• Indoor Use Only: This product is designed for indoor use only.
• Keep Away from Children: Store the adapter out of reach of children.

Image: LENCENT Mini-2AC adapter highlighting its dual 10A fuses, which provide overload protection for connected devices.

Image: LENCENT Mini-2AC adapter displaying its wide voltage range (100-250V) and a crucial warning that it is not a voltage converter.

5. Maintenance

5.1 Cleaning

To clean the adapter, ensure it is unplugged from the wall outlet and all devices are disconnected. Wipe the surface with a dry, soft cloth. Do not use liquid cleaners or immerse the adapter in water.

5.2 Fuse Replacement

If the adapter stops working, the internal 10A fuse may have blown due to an overload. To replace the fuse:

1. Locate the fuse compartment, usually marked 'FUSE', on the side of the adapter.
2. Carefully open the compartment using a small flat-head screwdriver or similar tool.
3. Remove the old fuse and insert a new 10A fuse.
4. Close the fuse compartment securely.

6. Troubleshooting

• No Power Output: Check if the adapter is securely plugged into the wall outlet. Ensure the correct country-specific pins are fully extended and locked. Verify that the device you are trying to charge is properly connected to the adapter. Check the fuse (see Maintenance section).
• Device Not Charging: Confirm that your device is compatible with the voltage of the country you are in. Some devices may require a voltage converter, which this adapter does not provide. Ensure your device's charging cable is functional.
• Overheating: If the adapter feels excessively hot, immediately unplug it from the wall and disconnect all devices. Allow it to cool down. Avoid overloading the adapter with high-power devices.

7. Specifications

8. Official Product Videos

9. Warranty and Support

For warranty information or technical support, please refer to the product packaging or contact LENCENT customer service directly. Contact details can typically be found on the manufacturer's official website or through your purchase platform.
