Important Safety Instructions
Please read and understand all instructions before assembly and use. Keep this manual for future reference.
- Weight Limits: Do not exceed the total static load capacity of 45 kg (99 lbs) for the cabinet. Each drawer has a maximum static load capacity of 5 kg (11 lbs). Overloading can cause instability and damage.
- Stability: Ensure the cabinet is placed on a flat, stable surface. Always lock the front casters when the cabinet is in its desired position to prevent accidental movement.
- Children Safety: Keep small parts away from children during assembly. Do not allow children to climb on or play with the cabinet.
- Assembly: Follow the assembly steps precisely. Do not force parts together. If any parts are missing or damaged, contact customer support immediately.
- Maintenance: Regularly check all connections and fasteners to ensure they remain tight.
Setup and Assembly
The VASAGLE OFC081W01 cabinet features a simplified assembly process with tool-free sliding rails, significantly reducing assembly time.
Package Contents
Verify that all components listed in the included accessory kit and instruction manual are present before beginning assembly.
Image: Exploded view of cabinet components and assembly manual.
Assembly Steps
- Unpack and Identify: Carefully unpack all parts and identify them using the provided parts list in the manual.
- Attach Casters: Secure the 5 universal casters to the base of the cabinet. Ensure the two front casters, which are lockable, are positioned correctly.
- Assemble Frame: Follow the numbered steps in the instruction manual to assemble the main frame of the cabinet.
- Install Drawer Rails: The drawer rails are designed for tool-free installation. Simply align and click them into place on the cabinet sides. You will hear a distinct click when they are securely fastened.
Image: Illustration of the tool-free drawer slide click mechanism.
- Assemble Drawers: Construct the 5 drawers according to the manual. Attach the handles securely.
- Insert Drawers: Carefully slide the assembled drawers onto their respective rails.
Image: Visual comparison of simplified assembly with click-in slides versus traditional screw-based assembly.
Operating Instructions
Drawer Usage
The cabinet features 5 smooth-gliding drawers designed for organizing various office supplies, documents, and small items. The handles allow for effortless opening and closing.
Image: Cabinet with drawers open, demonstrating storage capacity for various items.
Mobility and Stability
The 5 universal casters allow for easy movement of the cabinet. To secure the cabinet in place, engage the locks on the two front casters.
Image: Cabinet casters, highlighting the lockable front wheels and the additional support caster.
Printer Stand Functionality
The robust top surface of the cabinet can support an office printer, provided its weight does not exceed the total static load capacity of 45 kg.
Care and Maintenance
- Cleaning: Wipe the cabinet surfaces with a soft, damp cloth. Avoid using harsh chemicals or abrasive cleaners, as they may damage the finish.
- Inspection: Periodically check all screws and connections to ensure they are tight. Re-tighten if necessary to maintain stability and structural integrity.
- Drawer Functionality: The drawers are designed for long-term smooth operation, having passed 12,500 open and close tests. If a drawer becomes stiff, ensure it is not overloaded and check for any obstructions on the rails.
Image: Drawer durability testing, showing the product's quality assurance.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Cabinet is unstable or wobbly. | Casters are not locked; uneven surface; loose connections. | Ensure front casters are locked. Move cabinet to a level surface. Check and tighten all screws and fasteners. |
| Drawers do not slide smoothly. | Drawer overloaded; obstruction on rails; incorrect rail installation. | Reduce weight in the drawer. Check rails for debris. Ensure rails are correctly clicked into place and drawers are assembled properly. |
| Missing or damaged parts. | Manufacturing defect or shipping damage. | Do not attempt to assemble with missing or damaged parts. Contact VASAGLE customer support for replacement parts. |
Specifications
- Model Number: OFC081W01
- Brand: VASAGLE
- Color: Cloud White
- Material: Particleboard, Plastic
- Overall Dimensions (L x W x H): 40 x 42 x 65.7 cm (15.7 x 16.5 x 25.9 inches)
- Item Weight: 16.7 kg (36.8 lbs)
- Number of Drawers: 5
- Total Static Load Capacity: 45 kg (99 lbs)
- Static Load Capacity per Drawer: 5 kg (11 lbs)
- Special Features: Lockable casters, Printer stand capability, Tool-free sliding rails
Image: Detailed dimensions and weight capacities of the cabinet and its drawers.
Image: Close-up of the cabinet's thick and robust panels (1.5 cm).
Warranty and Support
For any questions, concerns, or to report missing/damaged parts, please contact VASAGLE customer support. Refer to your purchase documentation for specific warranty details and contact information.
Typically, support can be reached through the retailer where the product was purchased or directly via the manufacturer's official website.
