1. Product Overview
The MOVE SPEED 145W Laptop Power Bank is a high-capacity portable charging solution designed for a wide range of electronic devices, including laptops, smartphones, and tablets. Featuring PD 3.1 fast charging technology and a 25,000mAh capacity, it ensures your devices remain powered during travel, work, or outdoor activities. The integrated digital display provides real-time charging insights, enhancing user convenience.
Figure 1.1: MOVE SPEED 145W Laptop Power Bank and 240W Type-C Cable.
2. Safety Information
Important Safety Precautions:
- Do not expose the power bank to extreme temperatures, direct sunlight, or fire.
- Avoid dropping, disassembling, or attempting to repair the device yourself.
- Keep away from water and high humidity.
- Ensure proper ventilation during use and charging.
- This power bank is flight-approved (25000mAh/92.5Wh) and meets FAA and TSA carry-on regulations.
- The device incorporates 9-layer protection against overcharging, overheating, and short circuits.
Figure 2.1: The power bank is designed to be air-travel friendly.
Figure 2.2: Built-in NTC Temperature Sensor and comprehensive protection features.
3. Package Contents
Verify that all items are present in the package:
- MOVE SPEED 145W Laptop Power Bank x 1
- 240W 3.28Ft Type-C Cable x 1
- User Manual x 1
Figure 3.1: Items included in the product package.
4. Product Features
- 140W Ultra-Fast Single-Port Charging: Supports PD 3.1, capable of charging a 16-inch MacBook Pro to 56% in approximately 30 minutes.
- 65W Ultra-Fast Recharging: Fully recharges the power bank in about 2 hours using a compatible high-wattage charger.
- Massive 25,000mAh Capacity: Provides multiple charges for various devices (e.g., 4 full charges for iPhone 16, 3 for Galaxy S24, 2 for iPad 11).
- Triple-Port Output:
- USB-C1 (IN/OUT): Up to 140W output, 65W input.
- USB-C2 (OUT): Up to 45W output.
- USB-A (OUT): Up to 22.5W output.
Figure 4.1: Single port output capabilities.
Figure 4.2: Two-port simultaneous output capabilities.
Figure 4.3: Three-port simultaneous output capabilities.
- Smart Dynamic Charging: Optimizes power distribution up to 145W combined output when multiple USB-C ports are active.
- Smart LED Display: Shows precise battery percentage, charging status (INPUT/OUTPUT), and real-time voltage and current for each active port.
- Pass-Through Charging: Allows simultaneous charging of devices while the power bank itself is being recharged.
Figure 4.4: Key features of the MOVE SPEED 145W Power Bank.
Figure 4.5: Fast charging capability for laptops.
Figure 4.6: Extended power supply for multiple devices.
Figure 4.7: Simultaneous charging of up to three devices.
Figure 4.8: Rapid recharging of the power bank.
Figure 4.9: The smart LED display provides comprehensive charging information.
Figure 4.10: Pass-through charging capability for convenience.
5. Setup
Before first use, it is recommended to fully charge the power bank.
- Connect the included 240W Type-C cable to the USB-C1 port (IN/OUT) on the power bank.
- Connect the other end of the cable to a compatible USB-C wall charger (65W or higher recommended for optimal charging speed).
- The digital display will show "IN" and the battery percentage increasing, indicating that the power bank is charging.
- Once the display shows 100%, the power bank is fully charged and ready for use.
6. Operating Instructions
6.1 Charging Devices
To charge your electronic devices:
- Connect your device's charging cable to the appropriate output port on the power bank (USB-C1, USB-C2, or USB-A).
- Connect the other end of the cable to your device.
- The digital display will show "OUT" and the real-time voltage and current, indicating that your device is charging.
- The power bank will automatically detect the connected device and deliver the optimal charging speed.
Video 6.1: Demonstration of the MOVE SPEED power bank charging a laptop. This video highlights the product's ability to provide power to larger devices.
Video 6.2: Overview of the MOVE SPEED laptop power bank's features and usage. This video provides a general demonstration of the product.
Video 6.3: Demonstration of the MOVESPEED portable laptop charger and its 145W power bank capabilities. This video showcases the power bank in action with various devices.
6.2 Recharging the Power Bank
To recharge the power bank:
- Connect the included 240W Type-C cable to the USB-C1 port (IN/OUT) on the power bank.
- Connect the other end of the cable to a power source, such as a wall adapter or a computer's USB-C port.
- The digital display will indicate "IN" and the charging progress.
Note: For optimal recharging speed, use a power adapter that supports 65W Power Delivery (PD) or higher.
7. Specifications
| Feature | Detail |
|---|---|
| Model Number | YSPB-M25pro-US |
| Battery Capacity | 25,000mAh / 92.5Wh |
| USB-C1 Input | 65W Max |
| USB-C1 Output | 140W Max (PD 3.1) |
| USB-C2 Output | 45W Max |
| USB-A Output | 22.5W Max |
| Total Output | 145W Max (Dynamic Distribution) |
| Dimensions | 8.19 x 4.49 x 1.56 inches |
| Weight | 1.41 pounds |
| Included Cable | 240W 3.28Ft Type-C Cable |
| Safety Features | 9-layer protection (overcharging, overheating, short circuits, etc.), UN38.3 certified |
| Flight Approved | Yes (under 100Wh limit) |
8. Maintenance
- Clean the power bank with a soft, dry cloth. Do not use harsh chemicals or abrasive materials.
- Store the power bank in a cool, dry place away from direct sunlight and extreme temperatures.
- If storing for an extended period, recharge the power bank every 3-6 months to maintain battery health.
- Avoid exposing the ports to dust or debris.
9. Troubleshooting
Common Issues and Solutions:
- Power bank not charging:
- Ensure the charging cable is securely connected to both the power bank (USB-C1 port) and the power adapter.
- Verify that the wall adapter is functioning correctly and provides sufficient power (65W recommended).
- Try a different charging cable or power adapter.
- Device not charging from power bank:
- Check if the power bank has sufficient charge.
- Ensure the charging cable is securely connected to both the power bank and your device.
- Try a different output port on the power bank.
- Verify that your device's charging cable is not damaged.
- Slow charging:
- Ensure you are using the included 240W Type-C cable or another high-quality cable that supports fast charging.
- For recharging the power bank, use a 65W or higher PD-compatible wall adapter.
- When charging multiple devices, the total output power is dynamically distributed, which may result in slower charging for individual devices compared to single-port charging.
- Digital display not working:
- Ensure the power bank is sufficiently charged.
- If the issue persists, contact customer support.
10. Warranty and Support
MOVE SPEED offers a 36-month protection plan for this product. If you encounter any issues or have questions regarding your MOVE SPEED 145W Laptop Power Bank, please contact our customer support team for assistance.
For further support, visit the official MOVE SPEED store on Amazon: MOVE SPEED Store
