AMPAI WiFi Wall Touch Smart Switch User Manual

1. Introduction

Thank you for choosing the AMPAI WiFi Wall Touch Smart Switch. This smart switch is designed to upgrade your home lighting control with advanced features and convenience. It offers multiple control methods including touch panel, RF433 remote, and voice control via Alexa and Google Home. This manual provides detailed instructions for installation, operation, and troubleshooting to ensure optimal performance and safety.

Figure 1: AMPAI WiFi Wall Touch Smart Switch (4 Gang) and included RF433 Remote.

2. Important Safety Information

• Electrical Safety: Installation should be performed by a qualified electrician or a person with a thorough understanding of electrical systems. Always turn off power at the circuit breaker before installation or maintenance.
• Compatibility: This switch is designed for standard on/off control only. It is NOT compatible with dimmable bulbs or fixtures. Attempting to use it with dimmable bulbs may cause damage to the bulbs or the switch.
• WiFi Network: The smart switch operates on a 2.4GHz Wi-Fi network only. It is not compatible with 5GHz Wi-Fi networks. Ensure your router supports 2.4GHz.
• Wiring: This switch supports both neutral wire and no neutral wire (single fire) installations. Refer to the wiring diagrams carefully.
• Not a Traditional 3-Way Switch: While it offers 3-way control via multi-control methods (app, remote, voice), it does not function as a traditional mechanical 3-way switch requiring traveler wires between two switches.

Figure 2: Key attention points regarding 2.4GHz WiFi, wiring, and non-compatibility with traditional 3-way or dimmable setups.

3. Package Contents

Please check the package contents upon opening to ensure all items are present and undamaged:

• AMPAI WiFi Wall Touch Smart Switch (4 Gang)
• Mounting Hardware (Screws)
• RF433 Remote Control (if included in your specific package)
• User Manual (this document)

4. Setup and Installation

4.1 Wiring Instructions

WARNING: Ensure power is OFF at the circuit breaker before beginning any wiring.

This smart switch supports two wiring methods: with a neutral wire or without a neutral wire (single fire). Identify your home's wiring configuration before proceeding.

Figure 3: Wiring diagrams for Neutral and Fire Line (left) and Single Fire (right) installations. A capacitor is required for single fire wiring.

1. Turn off power: Locate the circuit breaker controlling the light switch and turn it OFF. Verify power is off using a voltage tester.
2. Remove old switch: Carefully remove the existing wall plate and unscrew the old switch from the wall box. Disconnect the wires.
3. Identify wires: Identify the Live (Line), Load, and Neutral wires (if present). For single fire wiring, you will only have Live and Load.
4. Wire the Smart Switch:
   • Neutral and Fire Line Wiring: Connect the Live wire to the 'L' terminal, the Neutral wire to the 'N' terminal, and the Load wires to the 'L1', 'L2', 'L3', 'L4' terminals corresponding to your light circuits.
   • Single Fire Wiring: Connect the Live wire to the 'L' terminal and the Load wires to the 'L1', 'L2', 'L3', 'L4' terminals. A capacitor must be connected across the Live and Load wires of the light fixture for stable operation.
5. Mount the switch: Secure the smart switch into the wall box using the provided screws. Attach the glass panel.
6. Restore power: Turn the power back ON at the circuit breaker.

4.2 App Installation and Pairing (Tuya Smart Life)

1. Download App: Download the "Smart Life" or "Tuya Smart" app from the App Store (iOS) or Google Play Store (Android).
2. Register/Login: Open the app and register a new account or log in if you already have one.
3. Add Device:
   • Ensure your phone is connected to a 2.4GHz Wi-Fi network.
   • In the app, tap the "+" icon in the top right corner to add a device.
   • Select "Electrical Switch" or "Wall Switch" from the device list.
   • Follow the on-screen instructions to put the switch into pairing mode (usually by pressing and holding a button on the switch until an indicator light blinks rapidly).
   • Confirm the indicator light is blinking rapidly in the app and enter your Wi-Fi password.
   • The app will connect to the switch. Once connected, you can rename the switch and assign it to a room.

4.3 RF433 Remote Pairing

The included RF433 remote can be paired directly with the switch for local control without Wi-Fi.

1. Enter Pairing Mode: On the smart switch, press and hold the touch button you wish to pair for approximately 5-7 seconds until you hear a "beep" sound or see a small indicator light flash.
2. Press Remote Button: Within 3 seconds, press the corresponding button (A, B, or C) on the RF433 remote.
3. Confirmation: The switch will "beep" again or the light will stop flashing, indicating successful pairing.

5. Operating the Smart Switch

5.1 Touch Control

Simply touch the corresponding icon on the glass panel to turn the connected light ON or OFF.

Figure 4: The smart switch supports multiple control methods for convenience.

5.2 Smart Life / Tuya App Control

Open the Smart Life or Tuya Smart app on your smartphone. From the device list, tap on your smart switch to access its control interface. You can turn lights ON/OFF, set schedules, and create scenes from anywhere with an internet connection.

5.3 Voice Control (Alexa & Google Home)

The AMPAI Smart Switch is compatible with Amazon Alexa and Google Home for convenient voice control.

1. Link Account: In the Alexa or Google Home app, enable the "Smart Life" or "Tuya Smart" skill/action and link your Smart Life/Tuya account.
2. Discover Devices: Ask Alexa or Google Home to "Discover devices" or manually add them through the app.
3. Voice Commands: Once discovered, you can use commands like:
   • "Alexa, turn on [Light Name]"
   • "Hey Google, turn off [Light Name]"
   • "Alexa, set [Light Name] to 50%" (Note: This switch does not support dimming, so dimming commands will not work.)

Figure 5: Enjoy hands-free control with Amazon Alexa and Google Assistant.

5.4 RF433 Remote Control

Use the paired RF433 remote to control the switch from a distance. Each button (A, B, C) on the remote can be paired to control a specific gang or group of gangs on the switch.

Figure 6: The RF433 remote provides an additional convenient control method.

5.5 Timer and Scene Functions

Utilize the Smart Life/Tuya app to set schedules and create custom scenes for your lighting. For example, you can set lights to turn on at sunset or off at a specific time, or create a "Movie Night" scene that turns off certain lights.

Figure 7: Set timers and scenes for automated lighting control.

6. Maintenance

The AMPAI Smart Switch requires minimal maintenance. To keep it clean and functioning properly:

• Cleaning: Gently wipe the glass panel with a soft, damp cloth. Avoid using abrasive cleaners or solvents, as they may damage the surface.
• Power Cycle: If the switch becomes unresponsive, try turning off the power at the circuit breaker for 10 seconds, then turning it back on.
• Firmware Updates: Periodically check the Smart Life/Tuya app for any available firmware updates for your switch to ensure optimal performance and security.

7. Troubleshooting

8. Specifications

9. Warranty and Support

For warranty information and technical support, please contact AMPAI customer service. You can often find support contact details on the product packaging, the manufacturer's official website, or through your purchase platform (e.g., Amazon).

Manufacturer: AMPAI

For further assistance, please visit the AMPAI Store on Amazon.
