OGACFO 36-inch Electric Fireplace

Important Safety Information

Please read and understand this entire manual before attempting to assemble, operate, or install this electric fireplace. Failure to follow these instructions may result in electric shock, fire, property damage, or personal injury.

• Always disconnect power before cleaning or performing maintenance.
• Do not operate any fireplace with a damaged cord or plug, or if the heater has malfunctioned or been dropped/damaged.
• Keep combustible materials at least 3 feet (0.9 m) from the front of the fireplace.
• This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
• Ensure the power outlet is properly grounded and rated for 1500W.
• This fireplace is equipped with an overheat protection feature. If the heater overheats, it will automatically shut off.

Package Contents

Carefully remove all components from the packaging and check against the list below. Ensure all items are present and undamaged before proceeding with installation.

• Electric Fireplace Unit (1)
• Remote Control (1)
• Faux Log Set (1)
• Crystal Stones (1 bag)
• Mounting Hardware (screws, anchors, brackets)
• Instruction Manual (1)

Setup and Installation

This electric fireplace offers versatile installation options: recessed, wall-mounted, or freestanding.

1. Choosing a Location

Select a flat, stable surface or wall. Ensure there is a grounded 120V, 60Hz, 15 Amp electrical outlet nearby. Avoid locations near water, direct sunlight, or areas with high humidity.

2. Recessed Installation

For recessed installation, a wall opening of specific dimensions is required. Refer to the diagram below for precise measurements.

Image Description: A diagram illustrating the precise dimensions for a recessed wall opening for the 36-inch electric fireplace. The required opening is approximately 35.31 inches (89.7 cm) wide, 17.95 inches (45.59 cm) high, and 3.86 inches (9.8 cm) deep.

1. Construct a wall opening according to the dimensions provided in the diagram.
2. Carefully insert the fireplace unit into the opening.
3. Secure the unit using the provided mounting brackets and screws.

3. Wall-Mounted Installation

1. Mark the desired mounting height on the wall. Ensure it is at least 12 inches (30 cm) from the ceiling and 24 inches (60 cm) from the floor.
2. Attach the wall mounting bracket to the wall studs using the provided screws. If studs are not available, use appropriate wall anchors.
3. Carefully lift the fireplace unit and hook it onto the wall mounting bracket.
4. Secure the bottom of the fireplace to the wall using additional screws if necessary.

4. Freestanding Installation

This option typically involves attaching a base or stand (if included or purchased separately) to the bottom of the fireplace unit. Follow the instructions provided with the stand for assembly.

5. Installing Decorative Media

Once the fireplace is securely installed, carefully place the faux log set and/or crystal stones into the media tray at the bottom of the unit.

Operating Instructions

The fireplace can be operated using the touch screen controls on the unit or the included remote control.

Image Description: A detailed view of the fireplace's touch control panel and the accompanying remote control. The touch panel features buttons for Digital Display, Crystal, Heating, Power, Adjusting, Timer, and Flame functions. The remote control has similar buttons for convenient operation.

1. Power On/Off

• Press the Power Button (⏻) on the unit or remote to turn the fireplace ON or OFF.

2. Heater Settings

The fireplace features two heat settings: 750W and 1500W. It can effectively heat areas up to 400 square feet.

Image Description: A visual representation of the electric fireplace installed in a living room, demonstrating its ability to provide even heating and comfort for areas up to 400 square feet.

• Press the Heating Button (≈) to cycle between LOW (750W), HIGH (1500W), and OFF.
• The heater can operate independently of the flame effect.

3. Flame Effects

Customize the flame color, speed, and brightness.

Image Description: A visual representation of the 12 available flame colors and 12 ember bed colors for the electric fireplace, showcasing a wide range of aesthetic options.

• Press the Flame Button (🔥) to cycle through 12 different flame colors.
• Use the Adjusting Button (↕) to change flame speed and brightness (5 stages).
• Press the Crystal Button to change the color of the crystal ember bed (12 colors).

4. Timer Function

Set the fireplace to automatically turn off after a specified duration, up to 12 hours.

Image Description: This image highlights the intelligent temperature control features, including a 12-hour timer for continuous comfort and the convenience of remote control operation from anywhere in the home.

• Press the Timer Button (⏱) to set the auto-off timer. Each press increases the timer by one hour, up to 12 hours.
• The digital display will show the set timer duration.

5. Overheat Protection and Child Safety Lock

Image Description: An image demonstrating the "Cool to Touch" feature of the fireplace, where a child and an adult are shown safely touching the glass panel while the flames are active, indicating that the heating function can be turned off separately.

• The unit is equipped with an automatic overheat protection system. If the heater reaches an unsafe temperature, it will automatically shut off. Unplug the unit, wait 10-15 minutes, and then plug it back in.
• The heating function can be operated independently of the flame effects, allowing the glass panel to remain cool to the touch when only flames are active.
• A child safety lock feature is integrated for enhanced safety. Refer to the remote control or unit for specific activation instructions.

Maintenance

Regular maintenance ensures optimal performance and longevity of your electric fireplace.

• Cleaning: Always unplug the fireplace before cleaning. Use a soft, damp cloth to wipe surfaces. Do not use abrasive cleaners or sprays.
• Glass Panel: Clean the glass panel with a soft cloth and a glass cleaner. Do not scratch the surface.
• Air Intake/Outlet: Periodically check and clean the air intake and outlet vents to ensure proper airflow and prevent overheating. Use a vacuum cleaner with a brush attachment to remove dust.
• Storage: If storing the fireplace for an extended period, unplug it and store it in a dry, dust-free location.

Troubleshooting

If you experience issues with your fireplace, consult the following table before contacting support.

Specifications

Warranty Information

This product comes with a Limited Warranty. For specific details regarding warranty coverage, duration, and terms, please refer to the warranty card included with your purchase or contact OGACFO customer support directly. Keep your proof of purchase for warranty claims.

Customer Support

If you have any questions, require technical assistance, or need to report a problem not covered in this manual, please contact OGACFO customer support. Contact information can typically be found on the product packaging, the manufacturer's website, or your purchase documentation.

When contacting support, please have your model number (XRHM37BK-40BK) and proof of purchase readily available.
