Introduction
This manual provides instructions for the proper use and maintenance of your ZWP Replacement Remote Control. This remote is designed to operate specific Tec Flame and Real Flame fireplace models. Please read this manual thoroughly before use to ensure correct operation and to prevent damage.
Compatible Models:
- Tec Flame Fireplace TT-FRPL-EF01-28
- Real Flame Firebox 4099 Focal Point EF11-35
Safety Information
Please observe the following safety precautions:
- Keep the remote control away from water and excessive moisture.
- Do not expose the remote control to direct sunlight or extreme temperatures.
- Do not attempt to disassemble or modify the remote control. This will void the warranty.
- Keep batteries out of reach of children. If swallowed, seek immediate medical attention.
- Dispose of used batteries according to local regulations.
Setup: Battery Installation
The ZWP Replacement Remote Control requires button batteries for operation. Batteries are not included with the remote control.
Required Battery Type:
- One (1) 3V Lithium Button Battery (e.g., CR2025 or similar, refer to the battery compartment for exact type).
Installation Steps:
- Locate the battery compartment on the back of the remote control. It typically has a small tab or indentation marked "RELEASE".
- Gently press the release tab or slide the cover to open the battery compartment.
- Insert the 3V Lithium Button Battery, ensuring the positive (+) side faces upwards, as indicated inside the compartment.
- Close the battery compartment cover securely until it clicks into place.
Figure 1: Battery compartment on the back of the remote control and the required 3V lithium button battery.
Note: No programming is required for this remote control. Once batteries are installed correctly, it is ready for use with compatible fireplace models.
Operating Instructions
The remote control features several buttons for managing your fireplace functions. Ensure the remote is pointed towards the fireplace receiver for optimal performance.
Figure 2: Front view of the remote control with button layout.
Button Functions:
| Symbol | Function | Description |
|---|---|---|
| ⏻ | Power On/Off | Turns the fireplace unit on or off. |
| 💡 | Flame/Light Control | Adjusts the brightness or mode of the flame effect and internal lighting. |
| ⏸ | Heat Up | Increases the heat output or temperature setting. |
| ⏷ | Heat Down | Decreases the heat output or temperature setting. |
| ⏱ | Timer | Activates or adjusts the timer function for automatic shut-off. |
| 🔥 | Flame Effect | Cycles through different flame effects or modes. |
Operating Range: The remote control has a maximum operating range of 10 meters (approximately 33 feet). Ensure there are no obstructions between the remote and the fireplace receiver.
Maintenance
Proper maintenance ensures the longevity and reliable operation of your remote control.
- Cleaning: Wipe the remote control with a soft, dry cloth. Do not use liquid cleaners or abrasive materials.
- Battery Replacement: Replace batteries when the remote's range decreases or if the fireplace does not respond to commands. Always replace with the specified battery type.
- Storage: If the remote control will not be used for an extended period, remove the batteries to prevent leakage and corrosion. Store in a cool, dry place.
Troubleshooting
If you experience issues with your remote control, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Remote not working. | Dead or incorrectly installed batteries. | Check battery orientation. Replace with new 3V Lithium Button Battery. |
| Limited range or intermittent response. | Low battery power; Obstruction between remote and fireplace; Remote not pointed correctly. | Replace batteries. Ensure a clear line of sight to the fireplace receiver. Point the remote directly at the fireplace. |
| Fireplace does not respond to any commands. | Remote is incompatible with the fireplace model; Fireplace receiver issue. | Verify your fireplace model is listed as compatible (TT-FRPL-EF01-28 or 4099 Focal Point EF11-35). Consult your fireplace's manual for troubleshooting its receiver. |
If the problem persists after trying these solutions, please contact customer support.
Specifications
- Model: TT-FRPL-EF01-28 (Replacement Remote)
- Material: High-quality ABS
- Color: Black
- Power Source: 1 x 3V Lithium Button Battery (not included)
- Operating Range: Up to 10 meters (33 feet)
- Dimensions: Approximately 10 x 3 x 1 inches (Package Dimensions)
- Item Weight: Approximately 2.4 ounces
- Special Feature: Ergonomic design
Figure 3: Remote control dimensions.
Warranty and Support
This ZWP Replacement Remote Control is manufactured with high-quality materials and undergoes strict quality control. For any questions or issues, please contact the seller directly through your purchase platform before leaving feedback. We are committed to assisting you with any concerns.
Please retain your proof of purchase for any warranty claims.
