Slypadan 0289-WD-SE-GF-2P-BGUS

Slypadan Outdoor Motion Sensor Porch Light with GFCI Outlet User Manual

Model: 0289-WD-SE-GF-2P-BGUS

1. Introduction

Thank you for choosing the Slypadan Outdoor Motion Sensor Porch Light with GFCI Outlet. This manual provides essential information for the safe and efficient installation, operation, and maintenance of your new lighting fixture. Please read it thoroughly before installation and retain it for future reference.

2. Safety Information

  • WARNING: To avoid electric shock, ensure the electricity is turned off at the circuit breaker or fuse box before installation, servicing, or changing the bulb.
  • All wiring connections must be in accordance with local and national electrical codes. If you are unsure about wiring, consult a qualified electrician.
  • Do not exceed the maximum wattage specified for the bulb. Use only incandescent or DIMMABLE E26 LED bulbs.
  • The GFCI outlet must be tested after installation and reset regularly to ensure proper function and safety. A complete test involves pressing the TEST button once and then the RESET button once.
  • Ensure the fixture is securely mounted to a stable surface.

3. Package Contents

Carefully unpack your lighting fixture and ensure all components are present and undamaged. If any parts are missing or broken, please contact customer support.

  • Outdoor Motion Sensor Porch Light (2 units)
  • Mounting Hardware (crossbar-style mount plate, wire connectors, mounting screws)
  • User Manual
Two Slypadan outdoor motion sensor porch lights with GFCI outlets

Image: Two Slypadan outdoor motion sensor porch lights with GFCI outlets, showcasing their design and integrated outlets.

4. Product Features

  • Advanced Built-in GFCI Sockets: Features 2 outlets for 2-hole and 3-hole plug devices, with a downward open design to prevent rainwater ingress. Provides protection against power surges and short circuits.
  • Settable PIR Motion Sensor: Innovative technology with 3 lighting modes (PC, Auto, Auto+). Adjustable sensor distance (0-40ft), illumination time (20s-180s), and dim light brightness (0%-50% in Auto+ mode).
  • Weather Resistance: Constructed with heavy-duty rugged high-quality aluminum and clear seeded glass panels. Anti-rust, waterproof, and resistant to various weather conditions including rain, snow, and heat.
  • Durable Construction: Made with 100% aluminum alloy and high-tempered glass for long-lasting performance.
Close-up of the built-in GFCI outlet on the porch light

Image: A detailed view of the built-in GFCI outlet, highlighting its protective cover and electrical specifications.

Porch light with water droplets, illustrating its weather resistance

Image: The porch light shown with water droplets, demonstrating its weather-resistant and waterproof design.

5. Setup and Installation

Before beginning installation, ensure the power supply is turned OFF at the circuit breaker to prevent electric shock.

  1. Unpack and Inspect: Carefully remove the fixture from its packaging. The glass panels are pre-assembled. Remove any protective plastic or cardboard pieces.
  2. Disassemble Fixture Base: Locate the two small nuts on the face of the fixture's base. Remove these nuts and the plastic O-rings. This will allow you to separate the main fixture body from the mounting plate.
  3. Mount the Base Plate: Securely screw the mounting plate (the part you just removed from the fixture) to your wall's electrical box. Ensure the two posts on the mounting plate are level for proper fixture alignment.
  4. Wire Connections: Connect the electrical wires. Match black to black (live), white to white (neutral), and green/bare copper to green (ground). Use the provided wire connectors and ensure all connections are secure.
  5. Secure the Fixture: Align the fixture body with the posts on the mounted base plate. Push the fixture onto the posts, then reattach the plastic O-rings and secure with the nuts you removed earlier. Tighten firmly but do not overtighten.
  6. Install Bulb: Screw in an incandescent or DIMMABLE E26 LED bulb (not included) into the socket.
  7. Restore Power: Turn the electricity back ON at the circuit breaker.
Installed porch light on a house exterior

Image: A Slypadan porch light installed on the exterior of a house, demonstrating its aesthetic appeal and placement.

6. Operating Instructions

Your Slypadan porch light features an advanced PIR motion sensor and dusk-to-dawn functionality. It offers three distinct lighting modes:

  • PC Mode (Photocell): Light turns on automatically at dusk and off at dawn. Motion sensor is inactive.
  • Auto Mode: Light remains off during the day. At night, it turns on to full brightness when motion is detected and turns off after the set illumination time.
  • Auto+ Mode: Light remains off during the day. At night, it stays on at a dim brightness (0%-50% adjustable) and brightens to full intensity when motion is detected, returning to dim after the set illumination time.

Motion Sensor Settings:

The motion sensor allows for customization of its detection and illumination parameters:

  • Sensor Distance: Adjustable from 0-40ft.
  • Illumination Time: Adjustable from 20s-180s (duration the light stays on after motion detection).
  • Dim Light Brightness: Adjustable from 0%-50% (only applicable in Auto+ mode).
Diagram showing motion sensor detection angle and distance

Image: A visual representation of the motion sensor's 220-degree ultra-wide detection angle and up to 40ft detection distance.

7. Maintenance

  • Cleaning: To maintain the appearance and performance of your fixture, clean it periodically with a soft, damp cloth. Do not use abrasive cleaners or solvents.
  • GFCI Outlet Testing: Regularly test the GFCI outlet to ensure it is functioning correctly. Press the
