MAONO PS22 Lite USB Audio Interface User Manual

Introduction

The MAONO PS22 Lite audio interface is designed for recording enthusiasts and streamers, offering high-resolution audio capture at 24-bit/192kHz with a dynamic range of 106dB. This USB audio interface is compatible with both PC and Mac, ensuring clear and realistic sound reproduction for various applications.

Key features include:

• High-resolution recording (24-bit/192kHz) and 106dB dynamic range for pristine audio.
• Support for condenser and dynamic microphones with up to 56 dB of preamp gain and 48V phantom power.
• Dedicated instrument input for guitars and other musical instruments, with impedance adjustment.
• Powerful ProStudio Routing Software for multi-channel control, virtual channels, loopbacks, and ASIO driver compatibility.
• Intuitive modes for recording, live broadcast, and instruments, offering plug-and-play functionality and direct monitoring.

Product Overview

Figure 1: The MAONO PS22 Lite audio interface shown with a dynamic microphone and desk stand.

Figure 2: Rear view of the MAONO PS22 Lite audio interface, highlighting the various input and output ports for connectivity.

Setup Guide

1. Connecting the Audio Interface

1. Connect the MAONO PS22 Lite to your computer (PC or Mac) using the provided USB cable. Ensure the connection is secure.
2. For microphones, connect your XLR dynamic or condenser microphone to the XLR input port on the interface. If using a condenser microphone, activate the 48V phantom power switch on the interface.
3. For instruments, connect your guitar or other high-impedance musical instrument to the dedicated instrument input.
4. Connect your headphones to the 3.5mm headphone jack for direct monitoring.

2. Software Installation

The MAONO PS22 Lite utilizes the ProStudio Routing Software for advanced control and routing. It is also compatible with ASIO drivers for low-latency performance on Windows systems.

• Visit the official MAONO website to download the latest version of the ProStudio Routing Software and any necessary drivers (e.g., ASIO drivers for Windows).
• Follow the on-screen instructions to complete the software installation.
• Restart your computer after installation if prompted.

Figure 3: The ProStudio Routing Software interface, demonstrating multi-channel control and routing capabilities.

Operating Instructions

Microphone Usage

The PS22 Lite provides up to 56 dB of preamp gain, suitable for both condenser and dynamic microphones. Ensure 48V phantom power is enabled for condenser microphones.

Figure 4: Demonstrating an XLR microphone connected to the MAONO PS22 Lite, highlighting the preamp gain control.

The microphone features an inner double layer pop filter and cardioid pickup pattern for effective noise reduction, ensuring clean and natural vocal audio.

Figure 5: Visual representation of the microphone's internal design for noise reduction, including the pop filter and cardioid pickup.

Instrument Input

Connect your guitar or other musical instruments to the dedicated input. Adjust the impedance as needed within the ProStudio software or on the device for optimal sound.

Figure 6: A user playing a guitar connected to the MAONO PS22 Lite, demonstrating its use for recording musical instruments.

ProStudio Routing Software and Loopback

The ProStudio Routing Software allows for advanced audio routing, including virtual channels and loopback functionality. This is particularly useful for live streaming and podcasting, enabling you to mix various audio sources seamlessly.

Figure 7: The ProStudio software interface displaying the loopback feature, allowing for flexible audio mixing and overlaying.

Indicator Lights

The device features a three-level indicator light system to quickly show the connection status:

• Blue Light: Powered on, but no data connection detected.
• Purple Light: USB data connection detected, and the device is in Instrument Stream Mode.
• Green Light: USB data connection detected, indicating normal operation.

Figure 8: Close-up of the MAONO PS22 Lite showing the different colored indicator lights and their meanings.

Maintenance

To ensure the longevity and optimal performance of your MAONO PS22 Lite audio interface, follow these maintenance guidelines:

• Cleaning: Use a soft, dry cloth to wipe down the exterior of the device. Avoid using liquid cleaners or abrasive materials, as they may damage the finish or internal components.
• Storage: When not in use, store the interface in a cool, dry place away from direct sunlight and extreme temperatures.
• Handling: Handle the device with care. Avoid dropping it or subjecting it to strong impacts, which could damage internal circuitry.
• Connectivity: Periodically check all cables and connections for wear and tear. Replace damaged cables to prevent signal loss or intermittent issues.

Troubleshooting

If you encounter issues with your MAONO PS22 Lite, refer to the following common troubleshooting steps:

Specifications

Warranty and Support

MAONO products are designed for reliability and performance. For information regarding warranty coverage, technical support, or service, please visit the official MAONO website or contact MAONO customer support directly.

You can often find support resources, FAQs, and contact information on the brand's official website:

Visit MAONO Official Website
