TECKNET Bluetooth Wireless Mouse User Manual

1. Product Overview

The TECKNET TK309 is a versatile wireless mouse designed for multi-device connectivity, offering both Bluetooth (BT 5.0/3.0) and 2.4GHz USB receiver options. It features adjustable DPI settings, an ergonomic design, and smart power-saving functions, making it suitable for various computing environments.

Image: Top view of the green TECKNET Bluetooth Wireless Mouse.

Package Contents:

• TECKNET Bluetooth Wireless Mouse
• USB-A Receiver
• User Manual

2. Product Layout

Familiarize yourself with the various buttons and indicators on your TECKNET wireless mouse.

Image: Diagram illustrating the numbered components of the TECKNET mouse, including the Bluetooth Pair button, Power/BT/2.4G Switch, Battery Compartment, USB Receiver slot, LED Indicator, and DPI Switch.

1. Bluetooth Pair Button
2. Power/BT/2.4G Switch
3. Battery Compartment
4. USB Receiver Slot
5. LED Indicator
6. DPI Switch Button
7. Left Click Button
8. Right Click Button
9. Scroll Wheel
10. Forward Button (Windows/Android only)
11. Backward Button (Windows/Android only)

3. Setup Instructions

3.1 Battery Installation

The mouse requires one AA battery (not included). To install:

1. Open the battery compartment cover on the bottom of the mouse.
2. Insert one AA battery, ensuring correct polarity (+/-).
3. Close the battery compartment cover.

3.2 2.4G Mode Connection

To connect the mouse using the 2.4G USB receiver:

1. Insert the AA battery into the mouse.
2. Toggle the Power/BT/2.4G switch on the bottom of the mouse to the "2.4G" position. The LED indicator will flash green.
3. Remove the Nano USB receiver from its storage slot in the mouse and plug it into an available USB-A port on your computer.
4. The mouse should connect automatically. Press any button to activate if it's in sleep mode.

Image: Visual guide for connecting the mouse in 2.4G mode, showing battery insertion, switch position, and USB receiver connection.

3.3 Bluetooth Mode Connection

To connect the mouse via Bluetooth:

1. Insert the AA battery into the mouse.
2. Toggle the Power/BT/2.4G switch on the bottom of the mouse to the "BT" position. The LED indicator will flash blue.
3. Press and hold the Bluetooth Pair button (located on the bottom of the mouse) for 3 seconds until the blue LED indicator flashes rapidly. This indicates pairing mode.
4. On your device (laptop, tablet, etc.), enable Bluetooth and search for new devices.
5. Select either "BM20X-3.0" or "BM20X-5.0" from the list of available devices to connect.

Image: Visual guide for connecting the mouse in Bluetooth mode, showing battery insertion, switch position, and Bluetooth pairing steps on a device.

4. Operating Instructions

4.1 Switching Between Devices (Multi-Mode)

The mouse supports connecting to two devices simultaneously: one via 2.4G USB receiver and one via Bluetooth. To switch between connected devices:

• Simply toggle the Power/BT/2.4G switch on the bottom of the mouse to the desired connection mode (2.4G or BT).
• The mouse will automatically connect to the last paired device in that mode.

Image: A laptop and tablet connected to the TECKNET mouse, illustrating the multi-device, one-key switch functionality.

4.2 DPI Adjustment

The mouse offers 6 adjustable DPI levels (800/1200/1600/2400/3200/4000) to suit different tasks and preferences. To change the DPI:

• Press the DPI Switch button located behind the scroll wheel.
• Each press cycles through the available DPI settings. The cursor speed will change accordingly.

Image: A computer screen displaying different DPI settings (800, 1200, 1600, 2400, 3200, 4000) and their corresponding uses, with the mouse shown below.

4.3 Forward and Backward Buttons

The side buttons allow for quick navigation:

• Press the Forward Button to move to the next page in web browsers or documents.
• Press the Backward Button to return to the previous page in web browsers or documents.
• Note: These side buttons are not supported on Mac operating systems.

Image: The TECKNET mouse with its forward and backward side buttons labeled, indicating their function and a note about Mac system incompatibility.

4.4 Smart Sleep Mode

To conserve battery life, the mouse features an automatic sleep mode:

• The mouse will enter standby mode after 10 seconds of inactivity.
• After 10 minutes of inactivity, it will enter a deeper auto-sleep mode.
• To wake the mouse, simply double-click any button.

Image: A visual representation of the mouse's smart sleep feature, showing states from working to standby, auto-sleep, and click to activate.

5. Compatibility

The TECKNET TK309 mouse is compatible with a wide range of operating systems and devices:

• Operating Systems: Windows, macOS, Linux, iOS, Android, Chrome OS
• Device Types: Laptops, Tablets, PCs, Smartphones

Image: Icons representing compatibility with Windows, Chrome, Linux, Apple (macOS/iOS), and Android operating systems.

6. Maintenance

To ensure optimal performance and longevity of your TECKNET mouse:

• Cleaning: Use a soft, dry cloth to clean the mouse. Avoid using harsh chemicals or abrasive materials.
• Battery Replacement: Replace the AA battery when the mouse performance degrades or the LED indicator suggests low power.
• Storage: When not in use for extended periods, store the USB receiver in its designated slot within the mouse.

7. Troubleshooting

If you encounter issues with your TECKNET mouse, refer to the following common solutions:

• Mouse not responding:
  • Ensure the battery is correctly installed and has sufficient charge. Replace if necessary.
  • Check the Power/BT/2.4G switch is in the correct position for your desired connection mode.
  • For 2.4G mode, ensure the USB receiver is securely plugged into a working USB-A port. Try a different port.
  • For Bluetooth mode, ensure Bluetooth is enabled on your device and the mouse is paired. Re-pair if connection is lost.
  • Wake the mouse from sleep mode by double-clicking any button.
• Intermittent connection:
  • Reduce the distance between the mouse and your device.
  • Remove any potential sources of interference (e.g., other wireless devices, large metal objects).
• Cursor movement is erratic or slow:
  • Adjust the DPI setting using the DPI Switch button.
  • Ensure the mouse is used on a suitable surface. Tru-Wave tracking works on most surfaces, but highly reflective or transparent surfaces may cause issues.
• LED Indicator meanings:
  • Green LED: Indicates 2.4G mode.
  • Blue LED: Indicates Bluetooth mode.
  • Flashing LED: Indicates pairing mode (rapid flash) or low battery (slow flash).
• Windows 7/XP Note: For 2.4G USB adapter usage on Windows 7/XP, a manual driver installation may be required.

8. Specifications

9. Warranty and Support

TECKNET provides a 36-month warranty for this product upon registration. For warranty claims, technical support, or inquiries regarding damaged/missing parts, please contact TECKNET customer service. Refer to the product packaging or the official TECKNET website for contact details.
