MOKA SFX Professional 3D Kinetic Light LED Lifting Ball System User Manual

1. Introduction

This manual provides essential information for the safe and effective operation of your MOKA SFX Professional 3D Kinetic Light LED Lifting Ball System. Please read this manual thoroughly before installation and use, and retain it for future reference. This system is designed to create dynamic visual effects for professional stage, nightclub, bar, and theater environments.

2. Safety Information

WARNING: Failure to follow these safety instructions may result in fire, electric shock, injury, or damage to the product or property.

• Always connect the unit to a grounded power outlet.
• Ensure the power supply voltage matches the unit's requirements (AC90-240V, 50-60Hz).
• Do not expose the unit to rain or moisture.
• Disconnect from power before cleaning or servicing.
• Installation must be performed by qualified personnel and adhere to local electrical codes.
• Ensure secure mounting to truss, grid, or ceiling points using appropriate safety cables.
• Maintain a safe distance from moving parts during operation.
• Do not operate if the power cord is damaged.
• Avoid direct eye exposure to the LED light source.

3. Package Contents

Verify that all items are present and in good condition upon unpacking:

• 1 x 3D LED Light Lifting System (Kinetic Light)
• 1 x Power Cord
• Accessories (including safety-rated suspension rope)
• 1 x User Manual

Image: Contents of the MOKA SFX Kinetic Light System package, including the main unit, power cord, accessories, and user manual.

4. Product Features

• Dynamic Vertical Motion: 20cm luminous sphere with 0-3 meter vertical range for mesmerizing visual effects.
• Quiet Operation: Engineered for smooth vertical motion with minimal operational noise, suitable for live performances.
• DMX512 Control: 6 independent DMX channels for precise control over RGB intensity, master dimming, strobe speed, and exact lift height.
• Seamless Integration: Easily daisy-chain with other DMX devices via standard 3-pin DMX.
• Durable Construction: Features a durable heat-resistant housing and includes a safety-rated suspension rope.
• High-Quality LED Beads: Equipped with 42PCS 0.5W RGB 3in1 LED beads for long lifespan and low power consumption.
• Multiple Control Modes: Supports DMX512, Sound-Activated, and Auto modes.

Image: Diagram illustrating the 20cm ball diameter and 0-3 meter lifting height capability of the kinetic light system.

Image: Close-up view highlighting the high-quality LED beads (42PCS 0.5W RGB 3in1) and their estimated 50,000-hour lifespan.

5. Specifications

Image: Visual representation of key product parameters and specifications.

6. Setup Instructions

6.1 Mounting

1. Identify a suitable mounting location (truss, grid, or ceiling) that can safely support the weight of the unit and withstand dynamic motion.
2. Securely attach the main lifting mechanism to the chosen mounting point using appropriate clamps or hardware (not included, unless specified in accessories).
3. Attach the safety-rated suspension rope from the unit to a separate, independent support structure as a backup.
4. Connect the 20cm RGB sphere to the lifting cable mechanism. Ensure it is securely fastened.

6.2 Electrical Connection

1. Ensure the power switch on the unit is in the "OFF" position.
2. Connect the provided power cord to the unit's power input.
3. Plug the power cord into a grounded AC90-240V, 50-60Hz power outlet.

6.3 DMX Connection (Optional)

1. For DMX control, connect a standard 3-pin DMX cable from your DMX controller's output to the DMX IN port on the kinetic light unit.
2. To daisy-chain multiple units, connect a DMX cable from the DMX OUT port of the first unit to the DMX IN port of the next unit, and so on.
3. Ensure the last unit in the DMX chain has a DMX terminator connected to its DMX OUT port (if available and recommended by your DMX controller).

7. Operating Instructions

7.1 Power On/Off

Flip the main power switch to the "ON" position to power on the unit. Flip to "OFF" to power down.

7.2 Control Modes

The unit supports three primary control modes:

• Auto Mode: The unit will cycle through pre-programmed patterns and colors automatically.
• Sound Control Mode: The unit will react to ambient sound, changing patterns and motion based on audio input.
• DMX Console Mode: Provides full control over all parameters via an external DMX512 controller.

Select the desired mode using the control panel on the unit or via DMX if applicable.

Image: Illustration of the available control modes: Auto, Sound Control, and DMX Console, with a DMX controller shown.

7.3 DMX Control (6 Channels)

When in DMX mode, the unit responds to 6 DMX channels:

1. Channel 1: Red Intensity (0-255 for 0-100% Red)
2. Channel 2: Green Intensity (0-255 for 0-100% Green)
3. Channel 3: Blue Intensity (0-255 for 0-100% Blue)
4. Channel 4: Master Dimming & Strobe Speed (Controls overall brightness and strobe effects from subtle pulse to rapid flash)
5. Channel 5: Lift Height Control (0-255 for 0-3 meter vertical position)
6. Channel 6: Special Effects/Macros (Triggers pre-programmed patterns or movements)

Refer to your DMX controller's manual for detailed programming instructions. Experiment with channel values to achieve desired lighting and motion effects.

8. Maintenance

Regular maintenance ensures optimal performance and extends the lifespan of your kinetic light system.

• Cleaning: Periodically clean the exterior of the unit and the LED sphere with a soft, dry cloth. Do not use abrasive cleaners or solvents. Ensure the unit is powered off and unplugged before cleaning.
• Inspection: Regularly inspect all cables (power, DMX, lifting cable) for any signs of wear, damage, or fraying. Check mounting hardware for tightness and security.
• Ventilation: Ensure that the ventilation openings on the main unit are clear and not obstructed to prevent overheating.
• Storage: If storing the unit for an extended period, ensure it is clean, dry, and protected from extreme temperatures and humidity.

9. Troubleshooting

10. Warranty and Support

MOKA SFX products are manufactured to high quality standards. For warranty information, please refer to the warranty card included with your product or visit the official MOKA SFX website.

For technical support, service, or replacement parts, please contact MOKA SFX customer service directly. Provide your product model number (MK-LB01) and purchase date when contacting support.
