OLEVS Men's Quartz Watch WD-S-G9809G-R Instruction Manual

1. Introduction

Thank you for choosing the OLEVS Men's Quartz Watch, model WD-S-G9809G-R. This manual provides essential information for the proper setup, operation, and maintenance of your new timepiece. Please read these instructions carefully to ensure optimal performance and longevity of your watch.

Image 1.1: OLEVS Men's Quartz Watch WD-S-G9809G-R, showcasing the watch, strap adjustment tool, and packaging.

2. Product Features

The OLEVS WD-S-G9809G-R watch is designed with precision and durability. Key features include:

• Quartz Movement: Equipped with an original imported quartz movement for stable and accurate timekeeping.
• Stainless Steel Construction: Features a robust stainless steel case and strap for enhanced durability and comfort.
• Date Display: A practical date window on the dial for convenient time management.
• Luminous Hands and Markers: High-definition luminous elements allow for easy time reading in low-light conditions.
• Water Resistance: Rated for 30 meters (3ATM) water resistance, suitable for daily splashes and rain.
• Adjustable Strap: The stainless steel bracelet length is adjustable, and a tool is provided for easy modification.

Image 2.1: The OLEVS WD-S-G9809G-R watch displayed on a stand, highlighting its design.

3. Setup

3.1. Strap Adjustment

The watch strap can be adjusted to fit your wrist size. A strap adjustment tool is included with your watch for this purpose.

1. Identify the pins on the side of the strap links that need to be removed.
2. Place the strap in the adjustment tool with the pin facing the tool's pusher.
3. Slowly turn the screw on the tool to push the pin out.
4. Remove the desired number of links.
5. Reassemble the strap by inserting the pins back into the links and gently tapping them into place.

If you are unsure, it is recommended to seek assistance from a professional watch repair service.

3.2. Setting Time and Date

To set the time and date on your OLEVS watch:

1. Pull out the crown: Gently pull the crown (the knob on the side of the watch) to the first click position to set the date, or to the second click position to set the time.
2. Set the date: In the first click position, rotate the crown clockwise or counter-clockwise until the correct date is displayed in the date window.
3. Set the time: In the second click position, rotate the crown to move the hour and minute hands. Continue rotating until the correct time is displayed. To ensure accuracy, set the time a few minutes ahead and then push the crown back in when a time signal (e.g., from a radio or phone) reaches the desired minute.
4. Push the crown back in: Once the time and date are set, push the crown fully back into its original position to start the watch and ensure water resistance.

Image 3.1: The OLEVS WD-S-G9809G-R watch worn on a wrist, demonstrating its fit and appearance.

4. Operating Instructions

4.1. Reading Time

The watch displays time using three hands: an hour hand, a minute hand, and a second hand. The hour markers, some with diamond accents, provide clear visibility.

4.2. Luminous Display

The hands and certain hour markers on your OLEVS watch feature a luminous coating. After exposure to light, these elements will glow in the dark, allowing you to read the time in low-light conditions. The duration and intensity of the glow depend on the exposure time and intensity of the light source.

Image 4.1: The watch dial with luminous hands and markers glowing in a dark environment.

5. Maintenance

5.1. Water Resistance

Your OLEVS watch has a water resistance rating of 30 meters (3ATM). This means it is suitable for daily use and can withstand splashes, rain, and handwashing. However, it is not suitable for showering, bathing, swimming, diving, or any activities involving prolonged water immersion or exposure to hot water/steam. Always ensure the crown is fully pushed in to maintain water resistance.

Image 5.1: The watch demonstrating its 30M water resistance against splashes.

5.2. Cleaning

To maintain the appearance of your watch:

• Wipe the watch case and strap with a soft, dry cloth regularly.
• For stainless steel, a slightly damp cloth can be used, followed by immediate drying.
• Avoid using chemical cleaners, solvents, or abrasive materials, as these can damage the watch's finish.

5.3. Storage

When not in use, store your watch in a cool, dry place, away from direct sunlight, extreme temperatures, and strong magnetic fields.

6. Troubleshooting

If you encounter any issues with your watch, please refer to the following common troubleshooting tips:

• Watch not running: Check if the crown is fully pushed in. If the watch still does not run, the battery may need replacement. Quartz watches typically require battery replacement every 1-2 years.
• Date not changing: Ensure the time is set correctly, especially past midnight. The date mechanism usually changes around midnight. If the date changes at noon, you may need to advance the time by 12 hours.
• Inaccurate timekeeping: While quartz movements are highly accurate, significant deviations may indicate a low battery or a need for servicing.
• Strap discomfort: Ensure the strap is adjusted correctly to your wrist size. It should be snug but not too tight.

For issues not resolved by these steps, please contact customer support.

7. Specifications

Detailed specifications for the OLEVS WD-S-G9809G-R watch:

Image 7.1: Visual representation of the watch's dimensions and key parameters.

8. Warranty and Support

8.1. Warranty Information

OLEVS provides a commitment to quality for its products. If you encounter any issues with your watch after purchase, please contact customer support for assistance. The manufacturer offers a full refund for product-related problems.

8.2. Customer Support

For any questions, concerns, or support needs regarding your OLEVS watch, please contact the seller directly through the Amazon platform. The seller, OLEVS WATCHES 1989, is available to assist you with product-related inquiries.
