Bulova Men's Classic Chronograph Watch Model 96B409 Instruction Manual

1. Introduction

Thank you for choosing the Bulova Men's Classic 6-Hand Chronograph High Performance Quartz Watch, Model 96B409. This timepiece combines a bold, modern design with advanced functionality, featuring a high-precision quartz movement. This manual provides essential information for the proper setup, operation, and care of your watch.

2. Watch Components

Familiarize yourself with the key components of your Bulova watch:

• Crown: Used for setting time and date.
• Pushers (A & B): Operate the chronograph functions.
• Hour, Minute, Second Hands: Indicate current time.
• Chronograph Second Hand: Central hand for stopwatch function.
• Chronograph Sub-dials: Measure elapsed time (e.g., 1/20th second, 60 minutes).
• Date Display: Shows the current date.
• 24-Hour Time Display: Indicates time in a 24-hour format.
• Case: 44mm silver-tone stainless steel with geometric bezel.
• Crystal: Mineral crystal for durability.
• Bracelet: Integrated silver-tone stainless steel with push-button foldover sport buckle.

3. Initial Setup

3.1 Setting the Time and Date

1. Pull out the crown to position 2 (second click). The second hand will stop.
2. Rotate the crown to set the hour and minute hands. Ensure the 24-hour hand is also correctly set (e.g., if it's 10 AM, the 24-hour hand should point to 10; if it's 10 PM, it should point to 22).
3. Push the crown back to position 1 (first click).
4. Rotate the crown to set the date. Avoid setting the date between 9 PM and 1 AM to prevent damage to the movement.
5. Push the crown back to position 0 (normal position).

3.2 Bracelet Adjustment

The stainless steel bracelet is designed for a comfortable fit. If adjustment is needed, it is recommended to visit a qualified jeweler or watchmaker to add or remove links for optimal sizing.

4. Operating the Chronograph

Your watch features a 6-hand chronograph for precise timing of events.

1. Starting the Chronograph: Press pusher A to start the central chronograph second hand.
2. Stopping/Pausing: Press pusher A again to stop or pause the chronograph. The elapsed time will be indicated by the central chronograph second hand and the chronograph sub-dials.
3. Resuming: Press pusher A to resume timing from the paused point.
4. Resetting: After stopping the chronograph, press pusher B to reset all chronograph hands to their zero positions.

4.1 24-Hour Time Display

The dedicated 24-hour sub-dial synchronizes with the main hour hand, providing a clear indication of AM/PM for accurate timekeeping.

5. Care and Maintenance

5.1 Cleaning

To maintain the appearance of your watch, regularly wipe the case and bracelet with a soft, dry cloth. For stainless steel, a slightly damp cloth can be used, followed by a dry polish. Avoid harsh chemicals or abrasive materials.

5.2 Water Resistance

This watch is water resistant to 100 meters (10 ATM). This means it is suitable for swimming and snorkeling, but not for high-impact water sports or diving. Ensure the crown is fully pushed in before any contact with water.

5.3 Battery Replacement

The high-performance quartz movement is powered by a battery. When the battery needs replacement, it is recommended to take your watch to an authorized Bulova service center or a reputable watchmaker to ensure proper sealing and function.

6. Troubleshooting

If you encounter any issues with your watch, refer to the following common solutions:

• Watch not running: Check if the crown is fully pushed in. If not, push it in. If the watch still doesn't run, the battery may need replacement.
• Incorrect time/date: Refer to section 3.1 to reset the time and date.
• Chronograph not resetting to zero: This may require a chronograph reset procedure. Consult an authorized service center if repeated attempts to reset using pusher B are unsuccessful.
• Water ingress: If moisture appears inside the watch, immediately take it to an authorized service center to prevent further damage.

7. Specifications

8. Warranty & Support

8.1 Limited Warranty

Your Bulova watch Model 96B409 comes with a 3-Year Limited Warranty. This warranty covers manufacturing defects in materials and workmanship under normal use. It does not cover damage resulting from accidents, improper handling, unauthorized repairs, or normal wear and tear.

8.2 Customer Support

For warranty claims, service, or additional support, please contact Bulova customer service or visit an authorized Bulova service center. Keep your proof of purchase for warranty validation.
