Product Overview
The Bonaire Durango Mini Split Air Conditioner and Heater is a versatile 12000 BTU unit designed to provide efficient cooling and heating for rooms up to 750 sq. ft. Featuring energy-saving inverter technology and smart Wi-Fi app control, this ductless wall AC unit offers personalized comfort and reduced energy consumption. Its quiet operation and easy installation make it an ideal solution for maintaining optimal indoor temperatures year-round.
This system includes both an indoor and outdoor unit, a remote control, Wi-Fi dongle, and all necessary components for a straightforward setup.
Setup and Installation
The Bonaire Durango Mini Split system is designed for user-friendly installation. While professional installation is always recommended for HVAC systems, this unit includes components that facilitate a more accessible setup process for experienced DIYers.
Included Components for Installation
- Indoor Unit
- Outdoor Unit
- Remote Controller & Wall Holder
- Wi-Fi Dongle
- Line Set - 16 ft Pair Coil Copper Piping with Insulated Wrap (pre-charged to accommodate a line set up to 25 ft)
- Communication Cable - Indoor to Outdoor Unit
- Wiring Cable - Connection Box to Outdoor Unit
- Drain Tubing Extension
- Indoor Unit Wall Mount Bracket
- Outdoor Unit Vibration Foot Pads (4)
- Thermal Tape
- Through Hole Edge Cover
- Drain Port for Outdoor Unit
- User Manual
Figure 1: Overview of the Bonaire Durango Mini Split AC system and its main components.
Figure 2: Detailed view of DIY inclusions and their respective parts for installation.
Operating Instructions
The Bonaire Durango Mini Split offers multiple ways to control your comfort, including a remote control and smart Wi-Fi app connectivity.
Remote Control Operation
Use the included remote control to adjust settings such as temperature, fan speed, operating mode (Cool, Heat, Fan, Dry, Auto), and timer functions. Refer to the remote control section in the physical manual for specific button functions.
Smart Wi-Fi App Control
The unit is Wi-Fi enabled, allowing you to control it remotely via a smartphone app. This feature enables you to pre-chill or pre-heat your room before arrival, adjust settings from anywhere, and monitor energy usage. Download the Bonaire Durango app from your device's app store and follow the in-app instructions for pairing.
Figure 3: Control your Bonaire Durango AC remotely using the dedicated smartphone application.
Key Operating Features
- Energy Saving Inverter Technology: Provides efficient cooling and heating by adjusting compressor speed, leading to lower energy consumption compared to traditional units.
- Quiet Operation: Designed for low noise levels (as low as 42 dB), ensuring a peaceful environment, especially during sleep.
- Heating and Cooling Functionality: Offers year-round comfort, capable of both cooling in warm weather and heating in cold conditions.
- Fast Cooling: Quickly brings your room to the desired temperature.
- Air Purification Filter: Helps maintain fresh and clean air circulation.
- 24-Hour Timer: Schedule the unit to turn on or off automatically.
- Auto Restart: Automatically resumes operation with previous settings after a power outage.
Figure 4: Key features of the Optima NM-Series, including various operational modes.
Figure 5: The unit's quiet operation ensures a serene environment for rest.
Figure 6: Inverter technology contributes to whisper-quiet operation for uninterrupted comfort.
Figure 7: DC Inverter Technology provides consistent comfort and superior performance.
Figure 8: The unit provides efficient performance for both cooling and heating across various ambient temperatures.
Maintenance
Regular maintenance ensures optimal performance and longevity of your Bonaire Durango Mini Split AC unit. The most critical routine maintenance involves cleaning the air filters.
Cleaning Air Filters
The air filters should be cleaned regularly, typically every two weeks or more frequently depending on usage and air quality. Dirty filters can reduce airflow, decrease efficiency, and impact air quality.
- Turn off the unit and disconnect power before performing any maintenance.
- Open the front panel of the indoor unit.
- Carefully remove the air filters.
- Clean the filters using a vacuum cleaner or wash them with lukewarm water and a mild detergent.
- Rinse thoroughly and allow them to dry completely in a shaded area before re-installing. Do not expose to direct sunlight.
- Re-install the dry filters and close the front panel.
Figure 9: Easy-to-clean filters ensure fresh and clean air circulation.
Other Maintenance Tips
- Outdoor Unit: Keep the area around the outdoor unit clear of debris, leaves, and other obstructions to ensure proper airflow.
- Coils: Periodically check the indoor and outdoor coils for dirt buildup. If heavily soiled, professional cleaning may be required.
- Drainage: Ensure the condensate drain line is not clogged to prevent water leakage.
Troubleshooting
Before contacting customer support, please refer to the following common troubleshooting steps for minor issues.
| Problem | Possible Cause | Solution |
|---|---|---|
| Unit does not turn on | No power supply; Remote control batteries are dead; Unit is in standby mode. | Check power connection and circuit breaker; Replace remote control batteries; Press the power button on the unit or remote. |
| Insufficient cooling/heating | Dirty air filters; Obstruction near air intake/outlet; Incorrect mode selected; Room size exceeds capacity. | Clean air filters; Remove obstructions; Select appropriate mode (Cool/Heat); Ensure unit capacity matches room size. |
| Unusual noise | Loose parts; Unit not level; Debris in fan. | Check for loose components; Ensure unit is installed on a level surface; Inspect for and remove any debris. |
| Water leakage from indoor unit | Clogged drain pipe; Improper installation. | Check and clear the drain pipe; Consult installation manual or professional for proper installation. |
| Wi-Fi connection issues | Poor Wi-Fi signal; Incorrect network settings; App issues. | Ensure strong Wi-Fi signal; Reconfigure network settings in the app; Restart the app and unit. |
If the problem persists after attempting these solutions, please contact Bonaire customer support for further assistance.
Specifications
| Specification | Detail |
|---|---|
| Brand Name | BONAIRE |
| Model Info | CRC7000012 |
| Item Weight | 25.5 pounds |
| Product Dimensions (Indoor Unit) | 8.46"D x 35.43"W x 12.2"H |
| Product Dimensions (Overall) | 37.01 x 26.97 x 20.08 inches |
| Capacity | 1 Tons (12000 BTU) |
| Cooling Power | 12000 British Thermal Units |
| Annual Energy Consumption | 1000 Watts |
| Noise Level | 42 dB |
| Installation Type | Split System |
| Special Features | Inverter Compressor, WiFi Enabled, Heating And Cooling Function, Fast Cooling, Air Purification Filter |
| Color | White |
| Voltage | 208 Volts |
| Wattage | 2254 watts |
| Floor Area Coverage | Up to 750 Square Feet |
| Refrigerant | R-410A |
Figure 10: Dimensions of the indoor and outdoor units.
Figure 11: BTU and coverage area guide for optimal performance.
Warranty and Support
For detailed warranty information, please refer to the warranty card included with your product or visit the official BONAIRE website. Warranty terms typically cover manufacturing defects for a specified period from the date of purchase.
For technical support, service requests, or inquiries regarding your Bonaire Durango Mini Split Air Conditioner and Heater, please contact BONAIRE customer service. Contact details can usually be found on the manufacturer's website or in the product packaging.
It is recommended to keep your purchase receipt and product serial number readily available when contacting support.
