Surakey High Power Turbo Fan Instruction Manual

1. Introduction

This manual provides essential instructions for the safe and efficient operation of your Surakey High Power Turbo Fan. Designed for powerful dust removal and versatile cleaning, this device features a high-speed brushless motor and a portable design. Please read this manual thoroughly before using the product and retain it for future reference.

Image 1.1: The Surakey High Power Turbo Fan, illustrating its compact design and nozzle.

2. Safety Instructions

To ensure safe operation and prevent damage, observe the following safety guidelines:

• Read all instructions before use.
• Keep the device away from water or other liquids. Do not operate with wet hands.
• Do not disassemble, repair, or modify the device yourself. Contact qualified service personnel for assistance.
• Use only the charging cable provided with the product.
• Keep the device out of reach of children and pets.
• Avoid blocking the air intake or outlet during operation.
• The fan is equipped with an over-temperature protection function. If the fan temperature exceeds 150 ℃, it will automatically stop running to prevent damage. Allow the device to cool down before resuming use.
• Do not point the fan directly at eyes or sensitive body parts.

3. Package Contents

Verify that all items are present in the package:

• 1 x High Power Turbo Fan
• 1 x Charging Cable

4. Product Features

The Surakey High Power Turbo Fan offers a range of features designed for effective and convenient use:

• High Performance Brushless Motor: Equipped with a low-noise, high-speed brushless motor, delivering a maximum output speed of 130,000 RPM and 200W engine power for strong, stable performance.
• Over-Temperature Protection: Features an automatic shutdown mechanism if the fan temperature exceeds 150 ℃, ensuring device longevity and safety.
• Strong Dust Removal: Provides powerful airflow capable of effectively removing small particles, dust, sand, hair, and other debris from various surfaces and tight spaces.
• Rechargeable Large Capacity Battery: Integrated 3000mAh lithium battery offers up to 4 hours of continuous use and supports 15W QC fast charging protocol.
• Portable Design: Constructed from durable ABS and metal materials, weighing only 305g. Its compact size and integrated magnetic suction nozzle make it easy to carry and handle.
• Versatile Application: Suitable for a wide range of cleaning needs in homes, cars (air vents, dashboards, cracks), offices, and even for outdoor activities like blowing charcoal fires for camping or barbecues.

Image 4.1: Visual representation of the fan's core features including wind speed, temperature protection, battery capacity, charging, and weight.

Image 4.2: Detailed view of the 13W high-speed brushless motor, emphasizing its strong and durable output.

Image 4.3: Representation of the fan's large capacity 3000mAh lithium battery, providing extended usage.

5. Setup

5.1 Charging the Fan

1. Connect the provided charging cable to the charging port on the fan.
2. Plug the other end of the cable into a compatible USB power adapter (not included).
3. The charging indicator (if present) will show the charging status. A full charge typically takes over 2.5 hours.
4. Disconnect the charger once fully charged.

5.2 Attaching the Nozzle

The fan features an integrated design with a magnetic suction nozzle. Simply align the nozzle with the fan's air outlet and it will securely attach magnetically.

6. Operating Instructions

6.1 Powering On/Off

• To power on the fan, press and hold the power button (control method: Touch/Button Control).
• To power off the fan, press and hold the power button again.

6.2 Using the Fan for Cleaning

Once powered on, direct the nozzle towards the area you wish to clean. The powerful airflow will dislodge and blow away dust and debris. Move the fan steadily across the surface for optimal cleaning.

Image 6.1: Examples of the fan's application for strong dust removal in various settings, including automotive interiors and home furniture.

7. Maintenance

7.1 Cleaning the Device

• Ensure the fan is powered off and disconnected from any power source before cleaning.
• Wipe the exterior of the fan with a soft, dry cloth.
• Do not use abrasive cleaners, solvents, or immerse the device in water.
• Periodically check the air intake and outlet for any obstructions and clear them carefully.

7.2 Storage

Store the fan in a cool, dry place away from direct sunlight and extreme temperatures. Ensure the battery is partially charged if storing for extended periods to maintain battery health.

8. Troubleshooting

If you encounter issues with your High Power Turbo Fan, refer to the following common problems and solutions:

• Fan does not turn on: Ensure the battery is charged. Connect the fan to a power source using the provided cable and allow it to charge.
• Reduced airflow or power: The battery might be low. Recharge the device. Check for any obstructions in the air intake or nozzle.
• Fan stops unexpectedly: The over-temperature protection may have activated. Allow the fan to cool down for a few minutes before attempting to restart. Ensure the air vents are not blocked.
• Unusual noise during operation: Power off the device and check for any foreign objects lodged in the fan blades or air pathways. If the noise persists, discontinue use and contact support.

9. Specifications

Detailed technical specifications for the Surakey High Power Turbo Fan:

10. Warranty and Support

For warranty information or technical support, please refer to the product packaging or contact Surakey customer service through the retailer's platform where the product was purchased. Keep your purchase receipt as proof of purchase.
