tectake Arges Ergonomic Office Chair with Lumbar Support (Model 405323)

Introduction

Thank you for choosing the tectake Arges Ergonomic Office Chair. This manual provides essential information for the safe and efficient assembly, operation, and maintenance of your new office chair. Please read these instructions carefully before use and retain them for future reference.

The tectake Arges office chair is designed to provide optimal seating comfort and support, helping to alleviate back issues during long periods of sitting. Its features include a height and angle-adjustable headrest, comfortable reclinable armrests, continuous height adjustment, breathable mesh fabric, and a height-adjustable lumbar support with adjustable tilt resistance.

Safety Instructions

• Ensure all components are present and undamaged before assembly. Do not use if any parts are missing or damaged.
• Assemble the chair on a soft, clean surface to prevent scratches.
• Do not stand on the chair.
• Do not use the chair as a step stool.
• Keep children away from the chair during assembly. Small parts can be a choking hazard.
• The maximum load capacity for this chair is 120 kg (264 lbs). Do not exceed this weight limit.
• Regularly check all screws and connections to ensure they are tight. Retighten if necessary.
• Avoid exposing the chair to direct sunlight or extreme temperatures for prolonged periods.

Setup and Assembly

Follow these steps to assemble your tectake Arges office chair. It is recommended to have two people for assembly.

1. Unpack Components: Carefully remove all parts from the packaging and lay them out on a protected surface. Verify all parts are present against the included parts list (refer to your product packaging for the complete list).
2. Attach Casters to Base: Insert the five casters into the holes at the end of each leg of the chair base. Push firmly until they click into place.
3. Insert Gas Lift: Place the gas lift cylinder into the center hole of the chair base.
4. Assemble Seat and Backrest: Attach the backrest to the seat using the provided screws and tools. Ensure the orientation is correct.
5. Attach Armrests: Secure the armrests to the seat and backrest assembly using the designated screws.
6. Mount Mechanism: Attach the control mechanism to the underside of the seat using the appropriate screws. Ensure the lever is facing the front or right side for easy access.
7. Connect Seat to Gas Lift: Carefully place the assembled seat onto the gas lift cylinder, ensuring it is centered and stable.
8. Attach Headrest: Slide the headrest into the designated slots at the top of the backrest and secure it.

After assembly, sit on the chair to ensure all components are securely connected and stable.

Operating Instructions and Adjustments

Your tectake Arges office chair offers several adjustment options to customize your seating experience for optimal comfort and ergonomic support.

Chair Height Adjustment

To adjust the seat height (approx. 45-55 cm):

• To raise: Lift the lever located under the seat on the right side while taking your weight off the seat. The seat will rise automatically.
• To lower: Lift the lever while seated. The seat will lower under your weight. Release the lever at the desired height.

Backrest Tilt Function

The chair features a tilt function with adjustable resistance.

• To activate/deactivate tilt: Pull out or push in the lever located under the seat (often the same lever as height adjustment, or a separate one).
• To adjust tilt resistance: Turn the round knob located under the front of the seat. Turn clockwise to increase resistance (making it harder to tilt) and counter-clockwise to decrease resistance (making it easier to tilt).

Adjustable Lumbar Support

The lumbar support is height-adjustable to provide targeted support for your lower back.

• Grasp the lumbar support pad on the backrest and slide it up or down to your preferred position.

Image: Close-up of the adjustable lumbar support mechanism on the chair's backrest.

Adjustable Headrest

The headrest can be adjusted in both height and angle.

• Height Adjustment: Gently pull the headrest up or push it down to adjust its height.
• Angle Adjustment: Tilt the headrest forward or backward to find the most comfortable angle for your neck and head.

Image: Close-up of the adjustable headrest, showing its height and angle adjustment capabilities.

Reclinable Armrests

The armrests can be tilted backward to allow the chair to be pushed closer to a desk or for easier movement.

• Simply lift the armrests upwards to recline them. Push them back down to their original position.

Maintenance and Care

Proper maintenance will extend the life of your tectake office chair.

• Cleaning: Clean the chair using a damp cloth. For stubborn stains, a mild soap solution can be used. Avoid harsh chemicals or abrasive cleaners.
• Fabric Care: The breathable mesh fabric and padded seat can be gently wiped. Do not saturate with water.
• Frame Care: Wipe metal and plastic parts with a damp cloth.
• Caster Maintenance: Periodically check casters for hair or debris and clean them to ensure smooth movement.
• Fastener Check: Regularly inspect all screws and bolts to ensure they are tight. Retighten as needed to maintain stability and safety.
• Storage: If storing the chair for an extended period, keep it in a cool, dry place away from direct sunlight.

Troubleshooting

If you encounter issues not listed here or if the suggested solutions do not resolve the problem, please contact tectake customer support for assistance.

Specifications

Image: Detailed dimensions of the tectake Arges office chair.

Warranty and Support

For warranty information or technical support, please refer to the purchase documentation or contact tectake customer service directly. Contact details can typically be found on the manufacturer's website or your purchase receipt.

Manufacturer: tectake

Seller: tectake nederland

Return Policy: 30 days
