Introduction
Thank you for choosing the Legami My Super Power Portable Charger, Koala Model (POW0025). This external battery is designed to provide convenient power on the go for your smartphones and tablets. It allows you to charge up to two devices simultaneously, ensuring you never run out of power when you need it most.
Please read this manual carefully before using the product to ensure safe and optimal performance. Keep this manual for future reference.
Product Overview
The Legami My Super Power Portable Charger is a compact and portable power bank featuring a high-quality lithium battery with a 4800mAh capacity. It includes a USB to Type-C cable for versatile charging.
Figure 1: Legami My Super Power Portable Charger (Koala Model)
The charger features a durable PVC casing with a charming Koala design. It is equipped with both USB-A and USB Type-C output ports, allowing for simultaneous charging of multiple devices.
Figure 2: Charging Ports (USB-A and USB Type-C)
Safety Information
- Do not expose the power bank to extreme temperatures, direct sunlight, or fire.
- Avoid dropping, hitting, or disassembling the device.
- Keep away from water and other liquids.
- Do not use if the power bank is damaged or swollen.
- Keep out of reach of children.
- Use only the provided or certified compatible charging cables.
Setup
Charging the Power Bank
- Connect the included USB to Type-C cable to the power bank's Type-C port.
- Connect the other end of the cable (USB-A) to a compatible USB power adapter (not included) or a computer's USB port.
- The power bank will begin charging. The LED indicator (if present, refer to product for specific indicator behavior) will show the charging status.
- Once fully charged, disconnect the cable.
Operating Instructions
Charging Your Devices
- Connect your device's charging cable to one of the power bank's output ports (USB-A or USB Type-C).
- Connect the other end of the cable to your smartphone, tablet, or other compatible device.
- The power bank will automatically begin charging your device.
- To charge two devices simultaneously, connect a second device to the available output port using its respective charging cable.
- Once your device is charged, disconnect it from the power bank.
Figure 3: Charging a Smartphone with the Power Bank
Maintenance
- Clean the power bank with a soft, dry cloth. Do not use harsh chemicals or abrasive materials.
- Store the power bank in a cool, dry place away from direct sunlight and moisture.
- If not used for extended periods, charge the power bank at least once every three months to maintain battery health.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Power bank not charging | Cable not connected properly; faulty cable; power source issue. | Ensure cables are securely connected. Try a different cable or power adapter. |
| Device not charging from power bank | Power bank battery is empty; faulty cable; device incompatibility. | Charge the power bank. Try a different charging cable for your device. Ensure your device is compatible. |
| Slow charging | Using a low-power adapter; cable resistance; device drawing high current. | Use a higher-output USB power adapter for charging the power bank. Ensure cables are in good condition. |
Specifications
| Feature | Detail |
|---|---|
| Brand | Legami |
| Model Number | POW0025 |
| Battery Capacity | 4800mAh |
| Battery Composition | Lithium |
| Voltage | 5 Volts |
| Connector Type | USB Type C (Input/Output), USB-A (Output) |
| Special Feature | Portable, Dual Device Charging |
| Recommended Uses | Smartphone, Tablet |
| Product Dimensions (L x W x H) | 11.6 x 3.5 x 2 cm |
| Item Weight | 200 g |
| Material | PVC |
Warranty and Support
For warranty information and customer support, please refer to the documentation included with your purchase or visit the official Legami website. If you encounter any issues not covered in this manual, please contact Legami customer service for assistance.
