Important Safety Information
Please read all instructions carefully before using the TYLT Smart Water Bottle. Keep this manual for future reference.
- Do not immerse the Bluetooth speaker base in water. The speaker is water-resistant (IP66 rated) but not fully waterproof for submersion.
- Always detach the speaker base before washing the water bottle.
- Keep the charging ports dry and clean to prevent damage.
- Do not expose the product to extreme temperatures or direct sunlight for prolonged periods.
- Use only the provided charging cable or a certified USB-C cable for charging.
- Keep out of reach of children.
Product Overview
The TYLT Smart Water Bottle combines a 24oz insulated stainless steel water bottle with a detachable Bluetooth speaker and wireless charging capability. It is designed for convenience and versatility.
Image: The TYLT Smart Water Bottle, showcasing its sleek black design and integrated speaker base.
Setup
1. Initial Inspection
Upon unboxing, ensure all components are present: the water bottle, the detachable Bluetooth speaker base, the flip straw, and the USB-C charging cable.
Image: The water bottle with its speaker base detached, showing the separate components.
2. Charging the Speaker
- Locate the USB-C charging port on the speaker base. It is usually covered by a protective flap.
- Connect the provided USB-C cable to the speaker base and plug the other end into a compatible USB power adapter (not included).
- The LED indicator on the speaker will show charging status. A full charge provides up to 12 hours of audio playback.
Video: An official TYLT video demonstrating the features of the speaker bottle, including charging.
3. Attaching/Detaching the Speaker Base
- To attach: Align the speaker base with the bottom of the water bottle and twist clockwise until securely fastened.
- To detach: Twist the speaker base counter-clockwise until it separates from the bottle. This is necessary for cleaning the bottle.
4. Filling the Bottle
Unscrew the lid and fill the 24oz stainless steel bottle with your desired beverage. The wide-mouth design allows for easy filling and adding ice. Insert the flip straw into the lid before securing the lid back onto the bottle.
Operating Instructions
1. Powering On/Off the Speaker
Press and hold the power button on the speaker base for a few seconds until you hear an audible prompt ("Power On") and the LED indicator illuminates.
To power off, press and hold the power button again until you hear "Power Off".
2. Bluetooth Pairing
- Ensure the speaker is powered on and in pairing mode (LED will blink).
- On your mobile device, go to Bluetooth settings and search for "TYLT Speaker Bottle".
- Select the device to pair. You will hear "Bluetooth Connected" upon successful pairing.
3. Playing Audio
Once paired, you can stream audio from your device to the speaker. Use your device's controls to manage playback (play, pause, skip tracks, adjust volume).
Image: A smartphone placed on the speaker base, illustrating the wireless charging feature.
4. Wireless Charging Feature
The speaker base features a wireless charging pad. Place your Qi-compatible smartphone directly on the top surface of the detached speaker base to initiate wireless charging. Ensure the speaker is powered on.
5. Using the Flip Straw
Flip up the straw mouthpiece to drink. Push it down to seal the bottle and prevent spills.
Maintenance
1. Cleaning the Water Bottle
The stainless steel water bottle and lid are hand wash only. Detach the speaker base completely before washing. Use warm, soapy water and a bottle brush to clean the interior. Rinse thoroughly. The wide-mouth opening facilitates easy cleaning.
2. Cleaning the Speaker Base
Wipe the speaker base with a damp cloth. Do not immerse it in water. Ensure the charging port cover is securely closed to protect against splashes and dust (IP66 rating).
3. Storage
Store the bottle and speaker in a cool, dry place when not in use. Ensure the speaker is fully charged before long-term storage to maintain battery health.
Troubleshooting
Speaker Not Turning On
- Ensure the speaker is charged. Connect it to a power source using the USB-C cable.
- Press and hold the power button for at least 3-5 seconds.
Bluetooth Not Connecting
- Make sure the speaker is in pairing mode (blinking LED).
- Ensure your device's Bluetooth is enabled and within range (approx. 33 feet or 10 meters).
- Forget the device from your phone's Bluetooth list and try pairing again.
- Turn off and on both the speaker and your device.
No Sound from Speaker
- Check the volume levels on both the speaker and your connected device.
- Ensure the speaker is successfully paired and connected to your device.
- Try playing audio from a different application or source.
Wireless Charging Not Working
- Verify your device is Qi-compatible for wireless charging.
- Ensure the speaker base is powered on.
- Adjust the position of your phone on the speaker base to ensure proper alignment with the charging coil.
- Remove any thick phone cases that might interfere with wireless charging.
Specifications
| Feature | Detail |
|---|---|
| Brand | TYLT |
| Model Number | SPKRBTL24BK-T/4949R |
| Capacity | 24 oz (approx. 1.5 lbs) |
| Material | Stainless Steel (inner), Plastic (outer) |
| Insulation | Double-wall vacuum insulated (keeps liquids hot/cold for up to 12 hours) |
| Bluetooth Version | 5.0 |
| Speaker Playback Time | Up to 12 hours |
| Water & Dust Resistance | IP66 Rated (speaker base) |
| Charging Port | USB-C |
| Wireless Charging | Qi-compatible (on speaker base) |
| Dimensions | 5.12 x 1.83 x 6.89 inches |
| Item Weight | 11.2 ounces (317 grams) |
| UPC | 843257101904 |
Warranty and Support
TYLT products are designed for quality and durability. For warranty information, technical support, or customer service inquiries, please visit the official TYLT website or contact their customer support directly. Keep your purchase receipt as proof of purchase.
Manufacturer: TYLT
