1. Introduction
Thank you for choosing the Ledmo KW1323B 15W LED Wall Lamp. This manual provides essential information for the safe installation, operation, and maintenance of your new lighting fixture. Please read these instructions carefully before installation and retain them for future reference.
This LED wall lamp is designed for both indoor and outdoor use, featuring a durable, weather-resistant construction and a warm white light output suitable for various applications.
2. Safety Instructions
- Electrical Safety: Installation must be performed by a qualified electrician or a competent person in accordance with local electrical codes and regulations. Always disconnect power at the main circuit breaker before installation, maintenance, or cleaning.
- Voltage: Ensure the power supply voltage matches the lamp's specified voltage (220 Volts).
- IP65 Rating: This product is IP65 rated, meaning it is protected against dust ingress and low-pressure water jets from any direction. While suitable for outdoor use, avoid submerging the lamp in water.
- Handling: Handle the lamp with care. Do not drop or subject it to strong impacts.
- Heat: The LED lamp may generate some heat during operation. Ensure adequate ventilation around the fixture. Do not cover the lamp with flammable materials.
- Light Source: The LED light source is non-replaceable. Do not attempt to disassemble the lamp.
3. Package Contents
Please check that all components are present and undamaged:
- Ledmo KW1323B LED Wall Lamp Unit (2 units if purchased as a pack)
- Mounting Bracket
- Screws and Wall Plugs
- Instruction Manual (this document)
4. Specifications
| Feature | Specification |
|---|---|
| Brand | Ledmo |
| Model Number | KW1323B |
| Power Consumption | 15 Watts |
| Voltage | 220 Volts |
| Light Color Temperature | 3000K (Warm White) |
| Brightness | 1600 Lumens |
| Dimensions (H x W x D) | 20 cm x 16 cm x 4.5 cm |
| Weight | 1.4 Kilograms |
| IP Rating | IP65 (Dust tight, protected against water jets) |
| Shape | Rectangular |
| Fixture Color | Black |
| Power Source | Electric Cable |
| Installation Type | Wall Mount |
| Control Method | Compatible with external tactile/touch switch |
| Number of LEDs | 75 high-quality SMD 2835 LEDs |
| Energy Efficiency Class | F |
| Energy Consumption | 12 kWh/1000h |
For detailed energy information, please refer to the EU EPREL database: https://eprel.ec.europa.eu/qr/1656791
5. Installation (Setup)
Before you begin: Ensure the power supply is turned OFF at the circuit breaker. Gather necessary tools (screwdriver, drill, pencil, measuring tape).
- Choose Location: Select a suitable wall location for mounting. Mark the drilling points for the mounting bracket using a pencil.
- Drill Holes: Drill holes at the marked points. Insert the wall plugs if necessary.
- Attach Mounting Bracket: Secure the mounting bracket to the wall using the provided screws.
- Wiring: Connect the electrical wires from your power supply to the terminals on the lamp's base. Ensure correct polarity (Live, Neutral, Earth) and secure connections.
- Mount the Lamp: Carefully align the lamp unit with the mounting bracket and secure it in place. Ensure it is firmly attached.
- Restore Power: Once installation is complete and all connections are secure, restore power at the circuit breaker.
Image Description: This image provides a clear, step-by-step visual guide for the installation of the Ledmo KW1323B LED wall lamp. It shows the process from mounting the base plate to the wall, connecting the electrical wires, securing the light fixture, and finally, the fully installed and illuminated lamp.
Image Description: A technical diagram detailing the physical dimensions of the Ledmo KW1323B LED wall lamp, measuring 20cm in height, 16cm in width, and 4.5cm in depth. An accompanying inset image reveals the internal structure, highlighting the 75 high-quality SMD 2835 LEDs that provide its illumination.
6. Operation
The Ledmo KW1323B LED Wall Lamp operates by connecting to your main electrical supply. It does not have an integrated switch on the fixture itself. To turn the lamp ON or OFF, use an external wall switch or a compatible tactile/touch switch connected to your electrical circuit.
Image Description: This image displays two Ledmo KW1323B LED wall lamps, featuring a black base and a white rectangular diffuser, mounted on a wall. The lamps are illuminated, showcasing their warm white light output.
7. Maintenance
- Cleaning: Ensure the power is OFF before cleaning. Wipe the lamp with a soft, damp cloth. Do not use abrasive cleaners or solvents, as these may damage the finish or diffuser.
- Inspection: Periodically inspect the lamp and its wiring for any signs of damage or wear. If any damage is found, disconnect power and consult a qualified electrician.
- LED Lifespan: The integrated LED light source has a long lifespan and does not require replacement.
8. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Lamp does not light up | No power supply Loose wiring connection Faulty wall switch | Check if power is ON at the circuit breaker. Ensure all wiring connections are secure (with power OFF). Test the wall switch or consult an electrician. |
| Light is flickering | Unstable power supply Loose wiring connection | Check power supply stability. Verify all wiring connections are tight (with power OFF). |
| Water ingress (for outdoor use) | Improper installation Damaged seal | Ensure the lamp is correctly sealed against the mounting surface. Inspect for any visible damage to the lamp's housing or seals. If damaged, discontinue use and replace. |
Image Description: This image highlights the weather-resistant features of the Ledmo KW1323B LED wall lamp, showing it installed on an exterior wall. Accompanying icons illustrate its waterproof, high temperature resistance, snowproof, and storm resistance capabilities, suitable for various outdoor conditions.
Image Description: A visual comparison demonstrating the consistent performance of the Ledmo KW1323B LED wall lamp in diverse weather conditions, including rain, snow, strong winds, and thunderstorms. It contrasts with a solar-powered light, emphasizing that the Ledmo lamp provides reliable illumination regardless of sunlight.
9. Warranty and Support
Information regarding specific warranty terms for the Ledmo KW1323B LED Wall Lamp is not provided in the product details. For warranty claims, technical support, or inquiries about spare parts, please contact your retailer or the Ledmo customer service directly.
Availability of spare parts for this product is currently unavailable according to product information.
10. Product Overview Images
Image Description: This image provides a detailed view of the Ledmo KW1323B LED wall lamp, emphasizing its elegant design and key lighting specifications. It displays icons for 15W power consumption, 1600 lumens brightness, 3000K warm white color temperature, and an IP65 waterproof rating.
Image Description: This collage illustrates the versatility of the Ledmo KW1323B LED wall lamp, showing it seamlessly integrated into multiple environments. Examples include a modern patio, a poolside area, a home's front entrance, and a garden setting, demonstrating its suitability for both aesthetic and functional lighting.
Image Description: The EU Energy Label for the Ledmo 791 Square wall lamp, indicating an energy efficiency class of F. It also specifies an energy consumption of 12 kWh per 1000 hours of operation. A QR code is present for further product information.
