Introduction
Thank you for choosing the Ezebaby Baby High Chair. This manual provides essential information for the safe assembly, operation, and maintenance of your high chair. Please read all instructions carefully before use and retain this manual for future reference.
The Ezebaby Baby High Chair in its various configurations: full high chair, folded for storage, and as a booster seat attached to a dining chair.
Safety Information
WARNING: Failure to follow these warnings and instructions could result in serious injury or death.
- Always secure your child in the high chair with the 5-point harness.
- Never leave your child unattended in the high chair.
- Ensure the high chair is fully assembled and all locking mechanisms are engaged before placing a child in it.
- Do not use the high chair if any parts are broken, torn, or missing.
- Keep children away from moving parts during adjustment.
- The maximum weight recommendation for this high chair is 25 kilograms (approximately 55 lbs).
- When using as a booster seat, always secure the booster to an adult chair using the provided straps. Ensure the adult chair is stable.
- Do not place the high chair near open flames, heaters, or other heat sources.
- Regularly inspect the high chair for wear and tear.
Package Contents
Please verify that all components are present before beginning assembly:
- High Chair Frame (main body with legs and wheels)
- Seat Unit with 5-point harness and PU cushion
- Removable Tray
- Toy Rack with hanging toys
- Booster Seat Straps (for convertible mode)
- Instruction Manual
Setup and Assembly
Follow these steps to assemble your Ezebaby Baby High Chair:
- Unfold the Frame: Place the main high chair frame on a flat, stable surface. Press the fold buttons on both sides of the frame and extend the legs until they click securely into place. Ensure all four legs are fully extended and locked.
- Attach the Seat Unit: Align the seat unit with the attachment points on the frame. Push down firmly until you hear a click, indicating it is securely fastened.
- Install the Tray: Slide the removable tray onto the armrests until it locks into position. The tray can be adjusted forward or backward to fit your child.
- Attach the Toy Rack: If desired, attach the toy rack to the designated slots on the armrests.
- Final Check: Before first use, double-check all connections and locking mechanisms to ensure the high chair is stable and safe.
Operating Instructions
Adjusting Seat Recline
The high chair offers 3 recline positions for your child's comfort during feeding, playing, or resting.
- Locate the recline adjustment handle, typically found on the back of the seat.
- Press the handle and gently push or pull the seatback to the desired recline angle.
- Release the handle and ensure the seatback is securely locked in position before use.
Illustration of the three adjustable recline angles for the high chair seat.
Adjusting Height
The high chair features 7 adjustable height positions to accommodate various table heights and activities.
- Locate the height adjustment buttons on both sides of the high chair frame, near the seat.
- Press both buttons simultaneously and raise or lower the seat to the desired height.
- Release the buttons and ensure the seat is securely locked at the chosen height.
Visual representation of the high chair's 7 adjustable height positions, ranging from 43 cm to 60 cm.
Using the Wheels and Locks
The high chair is equipped with 4 wheels that rotate 360° for easy movement. Each wheel has a lock for stability.
- To move the high chair, ensure all wheel locks are disengaged.
- To keep the high chair stationary, press down on the locking lever on each wheel until it clicks. Verify that the chair does not move.
The high chair features 360° wheels for mobility and integrated locks for stability.
Converting to Booster Seat
The seat unit can be detached and used as a booster seat, allowing your child to join the family at the dining table.
- Ensure the child is removed from the high chair.
- Locate the release buttons or levers on the sides of the seat unit where it connects to the frame.
- Press the release mechanisms and lift the seat unit off the high chair frame.
- Place the booster seat on a stable adult dining chair.
- Use the provided booster seat straps to securely fasten the booster to the adult chair. Ensure both the back and bottom straps are tightly secured.
- Always use the 5-point harness to secure your child in the booster seat.
The high chair seat converted into a booster seat, securely attached to a dining chair for family meals.
Folding for Storage
The high chair can be folded into a compact size for convenient storage and transport.
- Remove the child from the high chair.
- Ensure the tray is removed or pushed to its furthest position.
- Locate the fold buttons on both sides of the high chair frame.
- Press both buttons simultaneously and push the legs inward until the high chair folds compactly.
The high chair shown in its open and folded configurations, illustrating its space-saving design.
Maintenance and Cleaning
Regular cleaning and maintenance will ensure the longevity and hygiene of your high chair.
- Seat Cushion: The PU leather cushion is waterproof and can be easily wiped clean with a damp cloth and mild soap. Do not machine wash or tumble dry.
- Tray: The removable tray is dishwasher safe for thorough cleaning. For manual cleaning, use warm soapy water.
- Frame: Wipe the plastic and aluminum alloy frame with a damp cloth. Avoid abrasive cleaners.
- Harness: The 5-point harness straps can be spot cleaned with mild soap and water. Allow to air dry completely.
- Storage: Store the high chair in a clean, dry place away from direct sunlight when not in use.
Demonstration of the waterproof PU cushion being wiped clean and the tray being placed in a dishwasher.
Troubleshooting
If you encounter any issues with your Ezebaby Baby High Chair, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| High chair feels unstable. | Legs not fully extended or locked; wheels not locked. | Ensure all legs are fully extended and click into place. Engage all wheel locks. |
| Seat recline or height adjustment is difficult. | Buttons/handles not fully pressed; mechanism obstructed. | Press adjustment buttons/handles firmly. Check for any obstructions. Do not force. |
| Tray does not attach securely. | Tray not aligned correctly; release buttons engaged. | Ensure the tray is properly aligned with the armrest slots. Push firmly until it clicks. Release any tray release buttons if they are accidentally pressed. |
| Booster seat slides on adult chair. | Straps not tightened sufficiently. | Re-attach and tighten both the back and bottom booster straps securely around the adult chair. |
Specifications
- Model: B0CNVYS7NH
- Product Dimensions (Unfolded): 32"D x 22"W x 40"H (approximately 81.3 cm D x 55.9 cm W x 101.6 cm H)
- Item Weight: Approximately 20.1 pounds (9.15 kg)
- Maximum Weight Recommendation: 25 Kilograms (55 lbs)
- Material Type: Acrylic (for certain components), PU Leather (cushion), Aluminum Alloy (frame)
- Color: Grey
- Adjustable Height Positions: 7 levels (from 43 cm to 60 cm)
- Adjustable Recline Positions: 3 levels
- Portability: Yes, foldable design with 360° wheels
- Tray Features: Removable, Dishwasher Safe
Warranty and Support
Ezebaby products are designed for quality and durability. For specific warranty information, please refer to the documentation included with your purchase or visit the official Ezebaby website.
If you have any questions, require assistance with assembly, or need to report a missing or damaged part, please contact Ezebaby customer support through the retailer where the product was purchased or via the contact information provided on the Ezebaby official website.
