EPEVER MPPT Solar Charge Controller User Manual

1. Introduction

This manual provides detailed instructions for the installation, operation, and maintenance of the EPEVER MPPT Solar Charge Controller, model Xtra3215n. This controller is designed to efficiently manage power from solar panels to charge various battery types, including Lead-Acid (Sealed, Gel, Flooded) and Lithium (LiFePO4, Li[NiCoMn]O2) batteries, in 12V or 24V automatic identification systems. It features advanced Maximum Power Point Tracking (MPPT) technology for optimal energy harvesting and includes multiple electronic protections to ensure system safety and longevity.

2. Safety Information

WARNING:

• Risk of Electric Shock: Do not remove the cover. There are no user-serviceable parts inside. Refer servicing to qualified service personnel only.
• Risk of Electric Shock: When the photovoltaic array is exposed to light, it supplies a DC voltage to this equipment. Always ensure solar panels are disconnected or covered before working on the system.
• Hot Surfaces: To reduce the risk of burns, do not touch the controller during operation as surfaces may become hot.

3. Key Features

• MPPT Technology: High tracking efficiency up to 99.5% and peak conversion efficiency of 98%, maximizing energy from solar panels.
• Battery Compatibility: Supports Sealed (AGM), Gel, Flooded, LiFePO4, Li(NiCoMn)O2, and user-defined battery types.
• Charging Stages: Four stages of charging (bulk, absorption, float, Equalization) to prolong battery lifecycle.
• Display & Control: Integrated LED indicators and LCD display for monitoring PV/Battery/Load status. Five buttons for easy parameter adjustment and browsing.
• Communication: RS485 interface for connecting accessories like MT50 remote meter, BLE/WiFi Adapter (APP), or PC software for detailed monitoring and parameter modification.
• Protections: Built-in protections against reverse polarity, overcharging, over-discharging, overload, short-circuiting, and reverse current.
• Grounding: Common negative grounding design for wide application in various systems (e.g., communication base stations, household systems, RV solar systems).

4. Package Contents

The standard package for the EPEVER MPPT Solar Charge Controller (Model: XTRA3215N) includes the following items:

• 1 x MPPT Solar Charge Controller 30A (Model: XTRA3215N)
• 1 x Temperature sensor unit for controller (Model: RT-MF58R47K3.81A)
• 1 x User Manual (English)

Figure 4.1: EPEVER MPPT Solar Charge Controller (Xtra3215n) front view.

Figure 4.2: Optional accessories for the EPEVER Solar Charge Controller, including remote meter, WiFi/Bluetooth adapters, and communication cables.

5. Installation and Setup

5.1 Physical Dimensions

Figure 5.1: Dimensions of the XTRA3215N controller. The unit measures 255mm (10.03in) in length, 185mm (7.28in) in width, and 67.8mm (2.66in) in depth.

5.2 Wiring Connection Steps

It is crucial to follow the correct wiring sequence to prevent damage to the controller and other components. Always connect the battery first.

1. Connect the Battery: Connect the battery to the controller's battery terminals. Ensure correct polarity (+ to + and - to -). The controller will power on once the battery is connected.
2. Connect the DC Load: Connect the DC load to the controller's load terminals.
3. Connect the Solar Panel: Connect the solar panel array to the controller's PV terminals. Ensure correct polarity.

Disconnection Steps (Reverse Order):

1. Disconnect the Solar Panel.
2. Disconnect the DC Load.
3. Disconnect the Battery.

Figure 5.2: Diagram illustrating the correct connection sequence for the battery, DC load, and solar panel to the EPEVER MPPT Solar Charge Controller.

Figure 5.3: Rear view of the EPEVER MPPT Solar Charge Controller showing the terminal connections for PV, Battery, Load, Temperature Sensor (RTS), and RS485 communication port.

5.3 Installation Video Guide

6. Operation

6.1 LCD Display and Indicators

The controller features an LED LCD display and three color LED indicators (PV, Battery, Load) that provide real-time status information. The five buttons below the LCD allow for navigation and setting adjustments.

Figure 6.1: Table detailing the color, status, and instruction for each LED indicator (PV, Battery, Load) on the EPEVER Solar Charge Controller, providing quick visual diagnostics.

6.2 Battery Type Selection

The controller supports various battery types. For Lead-acid batteries (Sealed, Gel, Flooded), default parameters are used. For Lithium batteries (LiFePO4, Li[NiCoMn]O2) or custom settings, the 'User' type must be selected, and parameters configured manually.

Figure 6.2: Visual representation of supported battery types (Sealed, Gel, Flooded, LiFePO4, Li(NiCoMn)O2, User) for the EPEVER Solar Charge Controller.

Figure 6.3: Table showing default and customizable voltage parameters for various battery types, including Lead-Acid and Lithium, for the EPEVER Solar Charge Controller.

6.3 Remote Monitoring

The controller offers real-time remote monitoring capabilities through various accessories, allowing users to view and modify parameters via mobile apps (2.4G WiFi or Bluetooth) or PC software.

Figure 6.4: Illustration of remote monitoring options for the EPEVER Solar Charge Controller, including mobile app via 2.4G WiFi to Cloud and PC Cloud Platform.

7. Maintenance

Regular maintenance ensures optimal performance and longevity of your EPEVER MPPT Solar Charge Controller. Perform the following checks periodically:

• Cleanliness: Keep the controller clean and free from dust and debris. Ensure ventilation openings are not blocked.
• Connections: Periodically check all wiring connections for tightness. Loose connections can cause overheating and damage.
• Indicators: Monitor the LED indicators and LCD display for any abnormal readings or error codes. Refer to the troubleshooting section for specific issues.
• Environment: Ensure the controller is installed in a dry, well-ventilated area, away from direct sunlight and extreme temperatures.

8. Troubleshooting

This section provides solutions to common issues you might encounter with your EPEVER MPPT Solar Charge Controller. For more complex problems, please contact customer support.

9. Technical Specifications

Figure 9.1: Detailed electrical parameters for various XTRA series models, including XTRA3215N.

10. Warranty and Support

For any questions or technical support regarding your EPEVER MPPT Solar Charge Controller, please seek assistance via EPEVER's officially authorized vendor, Goland Century. They provide free technical support to customers.
