Introduction
Thank you for choosing the SPANN Replacement Battery. This 10.8V Lithium-Ion battery is designed as a compatible replacement for various Makita power tools, offering reliable performance and extended tool life. It features advanced protection mechanisms to ensure safe operation.
This manual provides important information regarding the safe handling, installation, operation, maintenance, and troubleshooting of your new battery. Please read it thoroughly before first use and keep it for future reference.
Compatibility
This SPANN battery is compatible with the following Makita battery part numbers and tool models:
- Part Numbers: 194550-6, 194551-4, 195332-9, BL1013, BL1014
- Tool Models: HS300DWE, HS300DZ, HU01, HU01Z, JR100D, JR100DWE, JR100DZ, JR101, JR101D
Always verify the compatibility with your specific tool model before use.
Setup and Initial Charging
- Unpacking: Carefully remove the battery from its packaging. Inspect for any visible damage.
- Initial Charge: For optimal performance and battery longevity, it is recommended to fully charge the battery before its first use. Use a compatible Makita 10.8V Lithium-Ion battery charger.
- Installation: Align the battery with the battery slot on your compatible Makita power tool. Slide the battery firmly into place until it clicks, indicating it is securely locked.
Image 1: Side view of the SPANN 10.8V replacement battery, showing its general shape and connection points.
Operating Instructions
Once installed and charged, the battery operates like the original Makita battery. Follow your power tool's specific operating instructions for safe and effective use.
- Charging: Always use a charger designed for 10.8V Lithium-Ion batteries. Do not use chargers intended for other battery chemistries or voltages.
- Discharging: Avoid completely draining the battery. Recharge it when power noticeably decreases to prolong its lifespan.
- Temperature: Operate and charge the battery within recommended temperature ranges (typically 0°C to 40°C or 32°F to 104°F) to prevent damage and ensure safety.
Image 2: Angled view of the SPANN 10.8V replacement battery, highlighting its compact design.
Maintenance and Storage
Proper maintenance and storage are crucial for extending the life of your battery.
- Cleaning: Keep battery terminals clean and free of dirt or debris. Use a dry cloth to wipe them if necessary.
- Storage: If storing the battery for an extended period, charge it to approximately 50-70% capacity. Store in a cool, dry place, away from direct sunlight and extreme temperatures.
- Temperature Warning: DO NOT STORE ABOVE 60°C (140°F). High temperatures can severely damage the battery and pose a fire risk.
- Safety: This battery features built-in protection against over-charge, over-discharge, over-heat, over-current, and short-circuit. However, always handle with care.
Image 3: Bottom view of the SPANN 10.8V replacement battery, showing the product label with model and part numbers.
Troubleshooting
If you encounter issues with your SPANN replacement battery, consider the following common solutions:
- Battery Not Charging:
- Ensure the charger is properly plugged into a working power outlet.
- Verify the battery is correctly seated in the charger.
- Check if the charger is compatible with 10.8V Lithium-Ion batteries.
- Inspect battery terminals for dirt or damage.
- Tool Not Powering On:
- Confirm the battery is fully charged.
- Ensure the battery is securely installed in the tool.
- Check if the tool itself is functioning correctly with another known good battery.
- Reduced Run Time:
- The battery may not be fully charged.
- Operating in extreme temperatures can affect performance.
- Over time, all rechargeable batteries experience a natural decrease in capacity.
If problems persist, please refer to the Support section for assistance.
Image 4: Close-up of the battery label, detailing model number, part numbers, voltage, capacity, and important safety warnings.
Specifications
| Feature | Specification |
|---|---|
| Model Number | CS-MKT090PW |
| Battery Type | Lithium-Ion |
| Voltage | 10.8V |
| Capacity | 1500mAh / 16.20Wh |
| Dimensions (L x W x H) | 50.75 x 50.20 x 77.80mm (approx. 1.98 x 3.06 x 2 inches) |
| Weight | 347g |
| Reusability | Rechargeable |
| Protection Features | Over-charge, Over-discharge, Over-heat, Over-current, Short-circuit |
Warranty Information
This SPANN replacement battery comes with a 365-day warranty from the date of purchase. This warranty covers manufacturing defects and ensures the product meets its stated specifications under normal use.
The warranty does not cover damage caused by misuse, abuse, unauthorized modification, improper storage, or operation outside of recommended conditions. Please retain your proof of purchase for warranty claims.
Support and Contact
Our products undergo strict quality inspection. If you have any questions, concerns, or require technical assistance regarding your SPANN replacement battery, please do not hesitate to contact us.
Refer to your purchase platform or packaging for specific contact details for customer support.
