1. Safety Information
Please read all instructions carefully before assembly and use. Keep this manual for future reference.
- Always assemble the unit on a soft, clean surface (e.g., carpet or cardboard) to prevent scratches.
- Ensure all parts and hardware are present before beginning assembly.
- For safety and ease of assembly, it is recommended that two adults assemble this product.
- Do not overtighten screws, as this may damage the material.
- Avoid exposure to excessive water or liquids. Handle with care to prevent potential hazards.
- Always use the provided anti-tip kit to secure the wardrobe to a wall, preventing accidental tipping and potential injury.
2. Package Contents
Verify that all components and hardware are included before starting assembly. Refer to the parts list in your package for specific labels.
2.1 Panels
- Top Panel
- Bottom Panel
- Side Panels (Left & Right)
- Middle Divider Panels
- Back Panels
- Shelf Panels
- Sliding Doors
- Drawer Fronts
- Drawer Side Panels
- Drawer Bottom Panels
2.2 Hardware
- Cam Locks and Pins
- Dowels
- Screws (various sizes)
- Hanging Rod
- Hanging Rod Brackets
- Sliding Door Track
- Sliding Door Rollers
- Sliding Door Handles
- Drawer Slides
- Drawer Pulls
- Shelf Pins
- Back Panel Clips
- Anti-Tip Kit (Brackets, Strap, Screws)
2.3 Tools Required (Not Included)
- Phillips Head Screwdriver
- Electric Drill (optional, use with caution to avoid overtightening)
3. Assembly Instructions
Follow these steps carefully to assemble your LITFAD Modern Wood Wardrobe.
3.1 Unboxing and Part Preparation
Carefully unbox all components. Lay out all panels and hardware on a soft surface. Identify each part by its label and ensure all pieces are accounted for.
Image: Overall dimensions and internal layout of the wardrobe.
Video: A person unboxes the wardrobe components and lays them out for assembly.
3.2 Assembling the Base Structure
Insert cam pins and dowels into the designated holes on the base panels. Attach the side panels to the bottom panel using cam locks and screws. Ensure the grooves for the back panels are correctly aligned.
Image: Close-up view of a panel showing pre-drilled holes for assembly.
3.3 Installing Back Panels and Shelves
Slide the back panels into the grooves of the assembled frame. Secure them with back panel clips. Insert shelf pins into the desired height holes and place the shelves.
Image: Close-up of the hanging rod being installed inside the wardrobe compartment.
3.4 Drawer Assembly
Assemble the drawer boxes by attaching the side panels to the front and back panels using screws. Slide the drawer bottom panels into the grooves. Install the drawer slides onto the drawer boxes and into the cabinet frame.
3.5 Sliding Door Installation
Attach the rollers and handles to the sliding doors. Install the sliding door track to the top of the wardrobe. Carefully hang the sliding doors onto the track, ensuring they move smoothly.
Image: Detailed view of the sliding door track mechanism at the top of the wardrobe.
Image: Illustration of the sliding door mechanism with arrows indicating movement.
3.6 Final Touches and Anti-Tip Kit
Cover any visible cam locks with the provided stickers. Secure the wardrobe to a wall using the anti-tip kit to prevent accidental tipping.
4. Product Care and Maintenance
- Clean the wardrobe with a soft, damp cloth. Avoid harsh chemicals or abrasive cleaners.
- Wipe up spills immediately to prevent damage to the wood material.
- Periodically check all fasteners and tighten them if necessary to ensure stability.
- Avoid exposure to excessive water or liquids. Handle with care to prevent potential hazards.
5. Troubleshooting
- Wobbly Unit: Ensure all cam locks and screws are fully tightened. Check that the wardrobe is placed on a level surface.
- Doors Not Sliding Smoothly: Verify that the sliding door track is clean and free of obstructions. Check that the rollers are properly seated in the track.
- Drawers Sticking: Inspect the drawer slides for proper alignment and ensure they are free of debris. Confirm that the drawer boxes are assembled correctly.
6. Specifications
- Brand: LITFAD
- Model: 65ad3478-2a21-415b-9802-51ad7d86bd2f
- Dimensions: 47"L x 18"W x 71"H
- Material: Wood (High-quality density board, Engineered Wood)
- Color: White
- Features: Sliding Doors, Multiple Shelves (5), Clothing Rod, Freestanding, Drawers
- Assembly Required: Yes
7. Warranty and Support
For any questions, concerns, or warranty claims regarding your LITFAD Modern Wood Wardrobe, please contact the manufacturer directly through your purchase platform. Please have your model number and purchase date available for faster service.
