Introduction
Thank you for choosing the Mycket Digital DAB/DAB+ Radio. This versatile device combines a retro FM radio, a powerful Bluetooth speaker, and a rechargeable music player with AUX and U disk support. Designed for both home and portable use, it offers superior sound quality and a wide range of features, including 80 preset stations, an LED display, and a sleep timer. This manual provides essential information for setting up, operating, and maintaining your radio to ensure optimal performance and longevity.
Figure 1: Front view of the Mycket Digital DAB/DAB+ Radio, showcasing its wood finish, display screen, and control buttons.
Setup
Unpacking and Initial Inspection
Carefully remove all components from the packaging. Verify that all items listed in the "Included Components" section are present and undamaged. Retain the packaging for future storage or transport.
Powering the Device
The Mycket radio can be powered via two methods:
- Mains Power: Connect the provided USB Type-C cable to the radio's charging port and plug the other end into a compatible USB power adapter (not included) or a USB port.
- Battery Power: The radio features a built-in 2000 mAh Lithium-ion rechargeable battery. A full charge provides up to 10 hours of listening time. Ensure the battery is fully charged before initial portable use.
Figure 2: The radio can be powered via mains, suitable for extended listening at home.
Antenna Positioning
For optimal radio signal reception (DAB/DAB+ and FM), extend the integrated telescopic antenna fully. Adjust its position to achieve the clearest sound. The radio is equipped with an ultra-long, highly sensitive antenna for improved reception.
Operating Instructions
Turning On/Off
Press and hold the Power button (usually marked with a power symbol) to turn the radio on or off.
Mode Selection
Press the Mode button to cycle through available modes: DAB/DAB+ Radio, FM Radio, Bluetooth, AUX Input, and U Disk Playback.
Radio Operation (DAB/DAB+ and FM)
- Automatic Scan: In DAB or FM mode, press the Scan or Auto Scan button (refer to specific button labels on your device) to automatically search for and store available stations. The radio can store up to 80 preset stations (40 DAB, 40 FM).
- Manual Tuning: Use the Tune or Select/Enter knob/buttons to manually adjust the frequency.
- Preset Stations: Use the Preset button or navigation buttons to recall saved stations.
- LED Display: The integrated LED screen displays station information, time, and other relevant data, making station selection and navigation clear and easy.
Figure 3: The portable radio with its key features highlighted, including 80 preset stations and an LED screen.
Bluetooth Connectivity
In Bluetooth mode, the radio will enter pairing mode. Enable Bluetooth on your smartphone, tablet, or other compatible device and select "Mycket Radio" (or similar) from the list of available devices to connect. Once paired, you can stream audio wirelessly to the radio.
AUX Input
Connect an external audio device (e.g., MP3 player, CD player) to the radio's AUX-in port using a 3.5mm audio cable (not included). Switch the radio to AUX mode to play audio from the connected device.
U Disk Playback
Insert a USB flash drive (U disk) containing audio files into the radio's USB port. Switch the radio to U Disk mode to play music directly from the drive. The radio supports various audio formats.
Figure 4: Demonstrating USB Disk Playback functionality, allowing users to enjoy music from a USB stick.
Sleep Timer
The sleep timer allows you to set a duration after which the radio will automatically turn off. This feature is useful for falling asleep to music or radio without worrying about turning off the device manually. Refer to your device's specific button or menu options for setting the sleep timer.
Maintenance
Cleaning
To clean the radio, gently wipe the exterior with a soft, dry cloth. For stubborn marks, a slightly damp cloth can be used, followed by a dry cloth. Do not use abrasive cleaners, solvents, or strong chemicals, as these may damage the wood finish or electronic components.
Storage
When not in use for extended periods, store the radio in a cool, dry place away from direct sunlight and extreme temperatures. Ensure the battery is partially charged (around 50%) before long-term storage to preserve battery health.
Battery Care
To maximize the lifespan of the built-in Lithium-ion battery:
- Avoid fully discharging the battery frequently.
- Avoid leaving the radio connected to power for prolonged periods after it is fully charged.
- Charge the battery at room temperature.
Troubleshooting
If you encounter any issues with your Mycket Digital Radio, please refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| No Power / Does not turn on | Battery depleted; Power cable not connected properly; Power adapter faulty. | Charge the battery; Ensure USB Type-C cable is securely connected; Try a different USB power adapter. |
| Poor Radio Reception | Antenna not extended or positioned correctly; Weak signal area; Interference. | Fully extend and adjust the telescopic antenna; Move the radio to a location with better signal; Avoid placing near other electronic devices. |
| Bluetooth Pairing Failure | Radio not in Bluetooth mode; Device Bluetooth off; Device too far; Already paired with another device. | Ensure radio is in Bluetooth mode; Turn on Bluetooth on your device; Move device closer to radio; Disconnect from other Bluetooth devices. |
| No Sound from AUX/U Disk | Incorrect mode selected; Cable not connected properly; U disk not formatted correctly or no supported files. | Switch to AUX or U Disk mode; Check cable connections; Ensure U disk is FAT32 formatted and contains compatible audio files. |
If the problem persists after trying these solutions, please contact customer support.
Specifications
| Feature | Detail |
|---|---|
| Brand | Mycket |
| Model Number | fcd38451-4bd5-4d9f-878a-d20e1d3ef03b |
| Color | Wood Finish |
| Connectivity Technology | Bluetooth, DAB, USB, FM, DAB+, AUX |
| Special Features | Built-in Clock, Portable, Integrated Antenna, Rechargeable |
| Compatible Devices | Tablet, Smartphone, USB devices |
| Battery Type | 1 Lithium-ion (included) |
| Battery Life | Up to 10 hours (on a single charge) |
| Power Source | Battery Powered, Electric Cable (USB Type-C) |
| Supported Radio Bands | FM, DAB, DAB+ |
| Preset Stations | 80 (40 DAB, 40 FM) |
| Speaker Output | 5W (integrated) with Bass Reflex subwoofer |
| Product Dimensions | 20L x 15W x 12H centimeters |
| Included Components | 1 DAB radio, 1 USB power cable, 1 user manual |
Warranty and Support
Mycket is committed to providing high-quality products and excellent customer service. Your Mycket Digital DAB/DAB+ Radio comes with a 12-month warranty from the date of purchase, covering manufacturing defects.
For any inquiries, technical assistance, or warranty claims, please contact our customer support team. We offer 24/7 customer support to ensure your satisfaction.
Please retain your proof of purchase for warranty validation.
Figure 5: Warranty and Support Information.
