BODEGACOOLER 121 Quart Dual Zone Portable Car Refrigerator

Introduction

The BODEGACOOLER 121 Quart Dual Zone Portable Car Refrigerator (Model tww115) is designed to provide reliable cooling and freezing capabilities for various outdoor and travel scenarios. This versatile unit can function as a refrigerator, freezer, or a combination of both, with independent temperature control for its two compartments. Equipped with smart features like APP control and robust construction, it ensures your food and beverages remain at optimal temperatures wherever your journey takes you.

What's in the Box

• Portable Refrigerator (1 unit)
• Cigarette Lighter Connector (1 unit)
• Wall Plug (1 unit)
• Wall Plug Adapter (1 unit)
• User Manual (1 unit)
• Dual Zone Basket (1 unit)
• USB Socket (1 unit)
• Bottle Opener (1 unit)

Key Features

• Dual Zone Temperature Control: Two compartments with independent temperature settings, allowing for simultaneous refrigeration and freezing.
• APP Control: Manage settings and monitor the cooler remotely via a smartphone application.
• Voltage Protection: H/M/L 3-level low-voltage protection to prevent vehicle battery drain.
• Multiple Power Options: Compatible with 12/24V DC and 100-240V AC power sources.
• Portability: Equipped with wheels and an extensible handle for easy transport.
• Removable Doors: Doors can be installed to open from either direction for flexible access.
• Internal LED Light: Provides visibility inside the cooler.
• USB Socket: Convenient for charging small electronic devices.
• Bottle Opener: Integrated for convenience.

Setup

1. Initial Placement: Before first use, allow the refrigerator to stand upright for at least 6 hours. Ensure adequate ventilation space around the unit.
2. Power Connection:
   • For vehicle use, connect the cigarette lighter connector to your vehicle's 12V or 24V DC outlet.
   • For home or office use, connect the wall plug adapter to the wall plug, then plug into a standard 100-240V AC outlet.

   Video: Demonstrates connecting the cooler to various power sources, including car and wall outlets.

3. Handle and Wheels: The cooler comes with pre-installed wheels and an extensible handle for easy movement. The handles on the sides are also robust for lifting.

   Image: The BODEGACOOLER showing its extensible handle and durable wheels for easy transport.
4. Removable Doors: The refrigerator doors are detachable and can be reinstalled to open from either the left or right, adapting to your preferred access direction.

   Image: The BODEGACOOLER demonstrating its removable doors that can be configured for 2-way opening.

5. Dual Zone Basket: Place the included dual zone basket into the larger compartment for organized storage.

Operating Instructions

1. Power On/Off: After connecting to a power source, press the power button on the control panel to turn the unit on. Press again to turn off.
2. Temperature Setting:
   • Use the '+' and '-' buttons on the control panel to adjust the temperature for each zone independently.
   • The temperature range is -4°F (-20°C) to 68°F (20°C).
   • Press and hold the '+' or '-' button for fast scrolling.


   Image: Close-up of the intelligent touch screen control panel showing temperature settings and mode indicators.

3. ECO/MAX Mode: Press the settings button to switch between ECO (energy-saving) and MAX (fast cooling) modes.
4. °C/°F Mode: Press and hold the '+' and '-' buttons simultaneously for 3 seconds to switch between Celsius and Fahrenheit display.
5. APP Control: Download the BODEGACOOLER app. Connect your smartphone via WiFi to control the refrigerator remotely. The app allows you to adjust temperature, switch modes, and monitor battery protection levels.

   Video: Demonstrates the use of the smartphone app to control the cooler's settings and monitor its status.

6. Battery Protection: Press the settings button to cycle through H (High), M (Medium), and L (Low) battery protection levels. This feature prevents your vehicle's battery from draining completely.
7. Internal LED Light: The cooler features an internal LED light for visibility in low-light conditions.
8. USB Socket: Use the integrated USB socket to charge small electronic devices.

Maintenance

1. Cleaning: To clean the interior, unplug the unit and remove all contents. Use a mild detergent and a damp cloth. For easy drainage, remove the drain plug located at the bottom of the cooler. Ensure the unit is completely dry before closing or reconnecting power.
2. Exterior Care: Wipe the exterior with a soft, damp cloth. Avoid abrasive cleaners that could damage the surface.
3. Ventilation: Regularly check that the ventilation grilles are clear of dust and debris to ensure efficient operation.

Troubleshooting

• Unit Not Powering On:
  • Check power connection: Ensure the power cable is securely plugged into both the cooler and the power source.
  • Verify power source: Confirm the power outlet (vehicle or AC) is functional.
  • Check fuse: If using DC, inspect the fuse in the cigarette lighter connector.
• Insufficient Cooling:
  • Door seal: Ensure the lid is properly closed and the rubber gasket is intact.
  • Ventilation: Check that the cooler's vents are not blocked.
  • Temperature setting: Verify the desired temperature is set correctly on the control panel or app.
  • Ambient temperature: In very hot environments, cooling performance may be affected.
• Unusual Noise:
  • Vibration: Ensure the cooler is placed on a flat, stable surface.
  • Fan noise: A slight fan noise is normal during operation, especially in MAX mode.
• App Connectivity Issues:
  • WiFi connection: Ensure your phone's WiFi is enabled and connected to the cooler's network.
  • App version: Make sure your app is updated to the latest version.

Specifications

Warranty & Support

BODEGACOOLER offers a 5-year lifespan warranty on the compressor and a 1-year warranty on all other parts. For any problems or technical support, please contact us via Amazon. Our professional technical support team will respond within 24 hours to ensure a satisfactory experience.
