1. Important Safety Instructions
Please read and understand all safety instructions before using this appliance. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- DO NOT COVER: Never cover the heater during operation. This can lead to overheating and fire.
- Placement: Maintain a safe distance from flammable materials such as furniture, papers, clothes, and curtains. Refer to installation guidelines for specific clearances.
- Overheat Protection: The heater is equipped with an automatic overheat protection system. If the heater overheats, it will automatically shut off. Unplug the unit and allow it to cool before restarting.
- Water Resistance: This heater has an IP45 water and dust resistance rating, making it suitable for both indoor and outdoor use. However, avoid direct exposure to heavy rain or submersion in water.
- Power Supply: Ensure the power outlet matches the voltage requirements of the heater (120 Volts). Do not overload electrical circuits.
- Children and Pets: Keep children and pets away from the heater during operation. The heating element becomes very hot.
- Maintenance: Do not attempt to open or repair the heater. There are no user-serviceable parts inside. Refer all servicing to qualified personnel.
- Flame Retardant Material: The heater is constructed from high-quality, flame-retardant material for enhanced safety.
2. Product Overview
The AKIRES 1500W Wall Mounted Electric Infrared Patio Heater provides efficient and targeted warmth using advanced infrared technology and a carbon fiber heating tube. Designed for versatility, it is suitable for various indoor and outdoor environments.
Key Features:
- 1-Second Fast Heating: Delivers immediate warmth, directly heating objects and people.
- Super Quiet Operation: Fan-less design ensures silent heating, ideal for noise-sensitive areas.
- 3 Heat Settings: Adjustable power levels (500W, 1000W, 1500W) for customized comfort.
- Remote & Touch Control: Convenient operation via included remote control or integrated touch screen.
- 24-Hour Timer: Program automatic shut-off for energy efficiency and convenience.
- IP45 Waterproof: Durable and rust-resistant design suitable for various weather conditions.
- Wall Mounted Design: Saves floor space and blends seamlessly into any setting.
Image: The AKIRES 1500W Wall Mounted Electric Infrared Patio Heater, showcasing its sleek black design and heating element.
Image: Diagram illustrating the dimensions of the AKIRES 1500W Patio Heater: 34.5 inches (W) x 5.12 inches (H) x 3.35 inches (D).
3. Package Contents
Please check the package contents upon receipt to ensure all items are present and undamaged.
- AKIRES 1500W Wall Mounted Electric Infrared Patio Heater
- Remote Control (requires 2 AAA batteries, not included)
- Mounting Brackets (L-shaped)
- Stainless Steel Screws
- Nuts and Disc Tails
- User Manual
4. Installation
This heater is designed for wall-mounted, horizontal installation only. Do not attempt to install it vertically.
Installation Steps:
- Choose Location: Select a suitable wall location, ensuring it is a stable surface and provides adequate clearance from flammable materials. The heater should be mounted at least 1.7 feet (0.5m) from any vertical surface, 2.3 feet (0.7m) from the ceiling, and the bottom of the heater should be at least 5.9 feet (1.8m) above the floor.
- Mark Drilling Points: Use the L-shaped mounting brackets as a template to mark the drilling points on the wall.
- Drill Holes: Drill holes at the marked points. Insert wall anchors if necessary for secure mounting.
- Attach Brackets: Secure the L-shaped brackets to the wall using the provided stainless steel screws.
- Mount Heater: Carefully lift the heater and attach it to the mounted brackets. Use the nuts and disc tails to firmly secure the heater in place. Ensure the heater is level and securely fastened.
- Connect Power: Plug the heater into a grounded electrical outlet. The power cord is approximately 7 feet long.
Image: Components for installation, including L-shaped brackets, stainless steel screws, and nuts/disc tails.
Image: Examples of the AKIRES Patio Heater installed in an alfresco dining area, porch, and courtyard, demonstrating its versatility for indoor and outdoor use.
5. Operating Instructions
The AKIRES patio heater offers convenient operation through its remote control or integrated touch screen.
Powering On/Off:
- Main Power Switch: Locate the main power switch on the side of the heater. Flip it to the 'ON' position.
- Remote Control/Touch Screen: Press the 'ON/OFF' button on the remote control or the power icon on the touch screen to turn the heater on or off.
Adjusting Heat Settings:
The heater features three distinct heat levels: 500W (Low), 1000W (Medium), and 1500W (High).
- Using Remote Control: Press the '500W', '1000W', or '1500W' buttons on the remote to select the desired heat level.
- Using Touch Screen: Tap the heat level icon on the touch screen to cycle through the available settings.
Timer Function:
Set the heater to automatically shut off after a specified period (1-24 hours).
- Using Remote Control: Press the 'TIMER' button on the remote and then use the up/down arrows (if available, or repeatedly press TIMER) to set the desired number of hours.
- Using Touch Screen: Tap the timer icon on the touch screen to adjust the timer setting.
Video: Demonstration of the AKIRES Wall-Mounted Electric Infrared Patio Heater, showing its features and operation with the remote control and touch screen.
Video: A short clip highlighting the 1-second fast heating capability of the AKIRES Patio Heater.
6. Maintenance
Regular maintenance helps ensure the longevity and efficient operation of your heater.
- Cleaning: Before cleaning, always unplug the heater and allow it to cool completely. Wipe the exterior with a soft, damp cloth. Do not use abrasive cleaners or solvents.
- Storage: If storing the heater for an extended period, ensure it is clean and dry. Store it in a cool, dry place, preferably in its original packaging.
- Internal Components: Do not attempt to clean or service internal components. The heater contains no user-serviceable parts.
7. Troubleshooting
If you encounter issues with your heater, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Heater does not turn on. | No power supply; Main switch off; Remote control batteries dead. | Check power outlet and circuit breaker. Ensure main power switch is ON. Replace remote control batteries (2 AAA). |
| Insufficient heat output. | Low heat setting selected; Heater too far from target area. | Increase heat setting to 1000W or 1500W. Ensure heater is positioned optimally for direct infrared warmth. |
| Heater turns off unexpectedly. | Overheat protection activated; Timer function engaged. | Unplug and allow to cool for 15-20 minutes. Check if timer is set. Ensure heater is not covered. |
If the problem persists after attempting these solutions, please contact customer support.
8. Specifications
| Feature | Specification |
|---|---|
| Brand | AKIRES |
| Model | 1500W Wall Mounted Electric Infrared Patio Heater |
| Color | Black |
| Power Output | 500W / 1000W / 1500W (3 Heat Levels) |
| Voltage | 120 Volts |
| Indoor/Outdoor Usage | Indoor, Outdoor |
| Product Dimensions | 3.35"D x 34.5"W x 5.12"H |
| Item Weight | 5.38 pounds |
| Mounting Type | Wall Mount (Horizontal) |
| Special Features | 24H Timer, Fast Heating, Overheat Protection, Remote & Touch Control, Noiseless, IP45 Weatherproof, Adjustable Tilt Head, Energy Efficient |
| Fuel Type | Electric |
| ASIN | B0CC1NV251 |
9. Warranty and Support
This AKIRES product is designed for reliability and performance. For specific warranty details, please refer to the documentation included with your purchase or contact AKIRES customer support.
Customer Support:
If you have any questions, require technical assistance, or need to report an issue, please contact AKIRES customer service through the retailer's platform or the official AKIRES website. Please have your product model and purchase date available when contacting support.
