1. Introduction
This manual provides detailed instructions for the installation, operation, and maintenance of your XTRONS IX82A3AHL Single Din Car Stereo. Please read this manual thoroughly before use to ensure proper functionality and to prevent damage.
1.1 Applicable Models and Years
- Audi A3 8P (2003-2012)
- Audi A3 8P1 3-door Hatchback (2003-2012)
- Audi S3 8P (2006-2012)
- Audi RS3 Sportback (2011-2012)
2. Safety Information
Always prioritize safety during installation and operation. Improper installation can lead to vehicle damage or personal injury. Consult a professional if you are unsure about any installation steps.
- Do not operate the device in a way that distracts you from driving.
- Ensure all wiring is correctly connected and insulated to prevent short circuits.
- Avoid exposing the unit to extreme temperatures, direct sunlight for prolonged periods, or moisture.
- Do not attempt to disassemble or modify the unit. This may void the warranty and cause damage.
3. Package Contents
Verify that all items listed below are present in the package before beginning installation.
- 2 × ISO Wiring Harness
- 1 × RCA Cable
- 1 × 4G Antenna
- 1 × SIM Card Slot Cable
- 1 × CANbus Box
- 2 × USB Cable
- 1 × GPS Antenna
- 1 × Radio Antenna Cable
- 1 × WiFi Antenna
- 2 × Uninstallation Tool
- 2 × Clip
- 1 × User Manual
4. Setup and Installation
Careful installation is crucial for optimal performance. If you are not experienced with car audio installation, it is recommended to seek professional assistance.
4.1 Important Compatibility Notes
- Ensure your vehicle's original CD player is single DIN size. This unit is not compatible with double DIN setups.
- If your vehicle has an RNS-D (Radio Navigation System) or BNS 5.x (Basic Navigation System), this unit is not compatible.
- Check your vehicle's radio antenna port. If it matches the image provided, you may need to order an additional cable for installation (XTRONS ICE/ACS/ISOFZ is compatible).
- For vehicles experiencing static noise from rear speakers, XTRONS AK/INIB/NRCBL may be required. Ensure your original ISO wiring harness plug is 40-pin before purchasing.
4.2 Wiring Diagram
Refer to the following diagram for correct wiring connections. Each numbered point corresponds to a specific connection.
Key to Wiring Diagram:
- Wi-Fi Antenna
- 4G Antenna
- Mini Microphone
- Radio Antenna Port
- GPS Antenna
- 4G SIM Card Slot
- SUBWOOFER, Subwoofer Output
- RL OUT, Rear Left Audio Output
- RR OUT, Rear Right Audio Output
- AUX IN, Video Input
- CAM IN, Camera Video Input
- Wi-Fi Antenna
- FL OUT, Front Left Audio Output
- FR OUT, Front Right Audio Output
- IR Port
- Front DVR VIDEO IN
- AUX-RIN, Audio Input Right
- AUX-LIN, Audio Input Left
- REVERSE, Reversing Control Cable
- USB Port1
- USB Port2
- USB Port3
- K1, Steering wheel control key1
- GND
- K2, Steering wheel control key2
- Rear Right Audio Output
- Rear Left Audio Output
- Front Left Audio Output
- Front Right Audio Output
- AUX R OUT, Audio Output Right
- AUX L OUT, Audio Output Left
- CANbus Box
- ISO Wiring Harness
5. Operating Instructions
This section covers the basic operation of your XTRONS car stereo, including its user interface, connectivity features, and navigation.
5.1 User Interface (UI)
The unit features an intuitive user interface designed for ease of use while driving. You can customize themes and access frequently used functions via the quick menu bar.
5.2 Smartphone Connectivity (CarAutoPlay & Android Auto)
Connect your smartphone for seamless integration of navigation, music, and communication features. The unit supports both wireless CarAutoPlay and wireless/wired Android Auto.
- Wireless CarAutoPlay: Connect via Bluetooth for Apple CarPlay functionality.
- Wireless & Wired Android Auto: Connect via Bluetooth for wireless Android Auto or via USB for a wired connection.
- Utilize voice commands (e.g., "Hey Siri" or "Hey Google") for hands-free operation.
Video 1: Demonstration of the XTRONS Car Stereo for Audi A3, highlighting features like Android Auto, DSP, and QLED display.
5.3 4G Connectivity
The unit features a global 4G LTE modem. Insert a Micro-SIM card (not included) to access mobile broadband. You can also share your mobile network via USB tethering from your phone.
- Supports 99% of worldwide carriers.
- Supported Bands: 1, 2, 3, 4, 5, 7, 8, 12, 17, 20, 28, 38, 40, 41, 42.
- Not Supported Bands: 13, 25, 26.
- CAT7 Modem offers download speeds up to 300Mbps.
5.4 Digital Sound Processor (DSP)
The built-in DSP enhances audio quality, allowing for precise sound customization. Adjust equalizer settings, sound field, and volume levels to optimize your listening experience.
5.5 GPS Navigation
The unit supports various Android-compatible navigation software, including Google Maps, Sygic, and Waze. Ensure a GPS antenna is properly connected for accurate positioning.
5.6 Split Screen and Picture-in-Picture
- Split Screen: Run two applications simultaneously, such as navigation and a music player.
- Picture-in-Picture: Maintain video playback in a small window while using other functions on the main screen.
6. Specifications
Key technical specifications of the XTRONS IX82A3AHL car stereo.
| Feature | Detail |
|---|---|
| Operating System | Android 12 |
| Processor | Octa Core CPU |
| RAM | 8GB |
| ROM | 128GB |
| Screen Size | 8.8 inches |
| Display Type | QLED Touch Screen |
| Resolution | 1280x480 |
| Connectivity | Bluetooth 5.0, Cellular (4G LTE), USB, Wi-Fi (2.4GHz & 5GHz) |
| Controller Type | Android, Google Assistant, iOS |
| Audio Output Mode | Stereo |
| Number of Channels | 4 |
| Special Features | Built-in DSP, Wireless CarAutoPlay, Full-featured Android Auto, Split Screen, Picture-in-Picture |
7. Maintenance
Proper maintenance ensures the longevity and optimal performance of your car stereo.
- Cleaning: Use a soft, dry cloth to clean the screen and exterior. Avoid abrasive cleaners or solvents.
- Software Updates: Periodically check for and install software updates to ensure the system runs efficiently and securely.
- Environmental Care: Protect the unit from extreme heat, cold, and direct moisture.
8. Troubleshooting
This section addresses common issues you might encounter. If a problem persists, contact customer support.
| Problem | Possible Cause / Solution |
|---|---|
| No Power | Check power connections and fuses. Ensure the ACC wire is correctly connected. |
| No Sound / Poor Sound Quality | Verify speaker connections. Check audio settings (volume, balance, fader, DSP). Ensure all audio cables are securely connected. If static, consider XTRONS AK/INIB/NRCBL. |
| GPS Signal Loss / Inaccurate Positioning | Ensure the GPS antenna is installed in a clear line of sight to the sky. Check antenna connection. |
| Bluetooth Connectivity Issues | Ensure Bluetooth is enabled on both the unit and your phone. Delete previous pairings and re-pair. |
| Microphone Echo / Poor Call Quality | Adjust microphone gain settings. Ensure the microphone is positioned correctly and not obstructed. |
| Unit Freezes / Unresponsive | Perform a soft reset (refer to the device's specific reset procedure). If persistent, consider a factory reset (data will be lost). |
9. Warranty and Support
XTRONS provides a 1-year warranty for this unit, covering manufacturing defects from the date of purchase. This warranty does not cover damage caused by improper installation, misuse, accidents, or unauthorized modifications.
For technical support, warranty claims, or any inquiries, please contact XTRONS customer service through the platform where the product was purchased. Provide your product model number (IX82A3AHL) and purchase details for faster assistance.
