1. Introduction
Thank you for choosing the Electrolux 90cm Slope Chimney, UltimateTaste 500, model ECS9610K. This appliance is designed to provide powerful and efficient extraction of cooking fumes and odors from your kitchen. To ensure safe operation and optimal performance, please read this manual thoroughly before installation and use. Keep this manual for future reference.
2. Safety Information
Always follow basic safety precautions when using electrical appliances to reduce the risk of fire, electric shock, and injury.
- Ensure the power supply matches the voltage specified on the rating plate.
- Installation must be performed by a qualified technician in accordance with local regulations.
- Do not operate the chimney if the power cord is damaged.
- Maintain a minimum distance between the hob and the lower part of the chimney as specified in the installation section.
- Regularly clean the filters to prevent grease buildup, which can be a fire hazard.
- Do not flambé under the range hood.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
3. Product Overview
The Electrolux ECS9610K is a 90cm slope chimney designed for efficient kitchen ventilation. Key features include:
- Powerful Extraction: Quickly removes unwanted odors and fumes.
- 4 Fan Speeds: Adjustable airflow to suit various cooking intensities.
- PowerBoost Function: Temporarily increases airflow for strong odors.
- Glass Touch Control Panel: Intuitive and easy to clean.
- Delay Off Function: Continues ventilation after cooking to clear kitchen air.
- Centrifugal Motor: Energy-efficient operation.
- Dishwasher-Safe Filters: Easy to clean and maintain.
- LED Lighting: Bright and energy-efficient illumination for your cooking area.
Figure 3.1: Front view of the Electrolux 90cm Slope Chimney. This image highlights the sleek design and the glass touch control panel.
4. Setup and Installation
Proper installation is crucial for the safe and efficient operation of your chimney. It is recommended that installation be carried out by a qualified professional.
4.1. Mounting Requirements
- The chimney is designed for wall-mount installation.
- Ensure the wall structure is strong enough to support the weight of the appliance (approximately 40.6 kg).
- Maintain adequate clearance from the cooking surface. For gas hobs, a minimum distance of 650mm is required. For electric hobs, a minimum distance of 600mm is required.
4.2. Dimensions and Clearance
Figure 4.1: Detailed dimensions for the Electrolux ECS9610K chimney installation. This diagram shows the overall height (1052-1329mm), width (896mm), depth (382mm), and ducting diameter (185mm). It also illustrates the minimum clearance requirements from the cooking surface: 600mm for electric hobs and 650mm for gas hobs.
4.3. Ducting
This model uses ducted ventilation. Ensure proper ducting is installed to vent extracted air outside. The ducting diameter is 185mm.
5. Operating Instructions
The Electrolux ECS9610K chimney features a glass touch control panel for easy operation.
5.1. Power On/Off
- Touch the power symbol (O) on the control panel to turn the chimney on or off.
Figure 5.1: Close-up of the intuitive glass touch control panel. This panel allows for simple operation and is easy to clean.
5.2. Adjusting Fan Speed
The chimney offers 4 adjustable fan speeds to match your cooking needs.
- Press the fan speed buttons (1, 2, 3, 4) to select the desired extraction level.
- Speed 1: For light cooking, simmering.
- Speed 2-3: For general cooking.
- Speed 4: For heavy cooking or strong odors.
Figure 5.2: Illustration of the four adjustable fan speed levels. These settings allow you to customize the airflow based on the intensity of your cooking.
5.3. PowerBoost Function
Activate PowerBoost for a temporary increase in extraction power.
- Press the PowerBoost button (often indicated by 'P' or a similar symbol) to engage maximum extraction.
- This function is ideal for quickly clearing very strong odors or smoke. It typically runs for a set duration (e.g., one minute) before returning to the previous speed setting.
Figure 5.3: Visual representation of the PowerBoost function. This feature provides an immediate surge in airflow to effectively eliminate strong cooking odors.
5.4. Delay Off Function
The Delay Off function allows the chimney to continue running for a short period after you finish cooking, ensuring all residual odors are removed.
- Press the Delay Off button (often indicated by a clock or 'OFF' symbol) after cooking.
- The chimney will operate for a preset time (e.g., 10-15 minutes) and then automatically switch off.
Figure 5.4: Depiction of the Delay Off feature. This function allows the chimney to continue clearing the air after cooking, ensuring a fresh kitchen environment.
5.5. Lighting
- Press the light button (often indicated by a light bulb symbol) to turn the LED lights on or off.
6. Maintenance
Regular maintenance ensures the longevity and efficiency of your Electrolux chimney.
6.1. Cleaning Filters
The metal grease filters should be cleaned regularly to maintain optimal performance. They are dishwasher-safe.
- Ensure the chimney is turned off and disconnected from the power supply before cleaning.
- Remove the grease filters by releasing their latches.
- Place the filters in a dishwasher or wash them by hand using hot water and a mild detergent.
- Allow the filters to dry completely before re-installing them.
Figure 6.1: View of the dishwasher-safe filters. These filters are designed for easy removal and cleaning, promoting better hygiene and environmental care.
6.2. Cleaning Exterior Surfaces
- Wipe the stainless steel and glass surfaces with a soft cloth and a non-abrasive cleaner.
- Avoid using harsh chemicals or abrasive pads, as these can damage the finish.
6.3. Oil Cup
The chimney is equipped with an oil cup to collect excess oil. Empty and clean the oil cup regularly.
7. Troubleshooting
If you encounter issues with your Electrolux chimney, refer to the following table for common problems and solutions.
| Problem | Possible Cause | Solution |
|---|---|---|
| Chimney does not turn on | No power supply Power cord not connected | Check circuit breaker/fuse Ensure power cord is securely plugged in |
| Low extraction power | Clogged grease filters Improper ducting Fan speed too low | Clean or replace filters Check ducting for obstructions or leaks Increase fan speed |
| Excessive noise | Loose components Ducting issues Motor malfunction | Check for loose screws or parts Inspect ducting for proper installation Contact customer support if motor noise persists |
| Lights not working | Faulty LED bulb Electrical connection issue | Replace LED bulb (if user-replaceable) Contact customer support |
If the problem persists after attempting these solutions, please contact Electrolux customer support.
8. Specifications
| Feature | Detail |
|---|---|
| Model | ECS9610K |
| Type | Slope Chimney, Wall Mount |
| Material | Glass, Stainless Steel |
| Dimensions (LxWxH) | 38.2D x 89.6W x 105H Centimeters |
| Airflow Displacement | 1500 CMPH |
| Noise Level | 60 Decibels |
| Number of Speeds | 4 |
| Controls Type | Touch |
| Filter Type | Mesh (Dishwasher-safe) |
| Light Source Type | LED |
| Voltage | 230 Volts |
| Annual Energy Consumption | 335 Watts |
| Item Weight | 40 kg 600 g |
| Included Components | 1 Chimney unit |
9. Warranty and Support
9.1. Warranty Information
This Electrolux chimney comes with a standard 2-year warranty. Please retain your purchase receipt for warranty claims. For detailed terms and conditions, refer to the warranty card included with your product or visit the official Electrolux website.
9.2. Customer Support
For any queries, technical assistance, or service requests, please contact Electrolux customer support:
- Customer Support Number: 1800 202 1800 (Toll Free)
- Importer Address: Electrolux India Private Limited, 1st Floor, Plus Offices, Landmark Cyber Park, Sector 67, Gurugram-122018 Haryana, India.
