HEI LIANG Fingerprint Smart Door Knob User Manual

Introduction

Thank you for choosing the HEI LIANG Fingerprint Smart Door Knob. This smart lock provides advanced security and convenient access through fingerprint recognition, app control, and traditional mechanical keys. Designed for ease of use and durability, it is suitable for various applications including bedrooms, utility rooms, apartments, offices, and hotels. Please read this manual carefully before installation and operation to ensure proper functionality and safety.

For additional support and detailed information, please refer to the official user guide PDF: Download User Guide (PDF)

1. Setup

1.1 What's Included

Before beginning installation, ensure all components are present:

• Smart Door Knob (Exterior and Interior Assemblies)
• Latch Mechanism
• Mounting Screws
• Mechanical Keys (2)
• Installation Template
• USB-A to Type-C Charging Cable
• User Manual

1.2 Tools Required

• Phillips Head Screwdriver
• Measuring Tape
• Pencil
• Drill (if modifying door for latch)

1.3 Installation Steps

The HEI LIANG Smart Door Knob is designed for easy installation on US standard doors (1.18"-2.17" thick). Follow these steps:

1. Prepare the Door: Ensure your door's bore hole and backset are compatible. The lock fits 2-3/8" or 2-3/4" (60mm or 70mm) backsets and 1-1/2" or 2-1/8" (38mm or 55mm) cross bore holes. Refer to the installation template for precise measurements.
2. Install the Latch: Insert the latch mechanism into the door edge, ensuring the bevel faces the door frame. Secure it with screws.
3. Install Exterior Assembly: Feed the cable from the exterior knob through the bore hole and align the spindle with the latch. Ensure the 'UP' sign on the exterior knob is facing upwards.
4. Install Interior Assembly: Connect the cable from the exterior assembly to the interior assembly. Align the interior knob with the spindle and secure both assemblies with the provided mounting screws.
5. Test Operation: Before closing the door, test the mechanical operation of the knob.
6. Initial Charging: The lock has a built-in 400mAh rechargeable battery. Fully charge the device for 3-4 hours using the provided USB-A to Type-C cable before first use. A low battery warning activates at 15% capacity.

Figure 1.1: Door compatibility and dimensions for installation.

Figure 1.2: Easy installation process and charging the smart door knob.

1.4 App Download and Pairing

Download the companion app (e.g., Tuya Smart or Smart Life app) from your device's app store. Follow the in-app instructions to pair your smart door knob via Bluetooth. Wi-Fi settings and remote access features may require an additional gateway (sold separately).

Figure 1.3: The smart lock app interface for control and management.

2. Operating Instructions

2.1 Unlocking Methods

• Fingerprint Recognition: Place your registered finger on the fingerprint sensor on the exterior knob. The lock will unlock in approximately 0.5 seconds if the fingerprint is recognized. The LED indicator will confirm successful unlock. The lock can store up to 20 fingerprints.
• App Control: Use the paired mobile app to remotely lock or unlock the door. This method provides convenience and allows for remote access management.
• Mechanical Key: In case of battery depletion or other issues, a hidden mechanical keyhole provides a backup entry method. Insert and turn the key to unlock.

Figure 2.1: The HEI LIANG Smart Door Knob, showcasing its fingerprint sensor, app control, and mechanical key backup.

Figure 2.2: Detailed view of the advanced biometric fingerprint reader, highlighting its quick recognition speed and high accuracy.

2.2 App Features and Management

The mobile app provides comprehensive control and monitoring capabilities:

• User Management: Add or delete fingerprints for authorized users. Up to 20 fingerprints can be stored.
• Access Logs: View real-time unlock records and traffic patterns, providing a history of who accessed the door and when.
• Automatic Locking: Configure the lock to automatically lock within 5 seconds after being opened, enhancing security.
• Temporary Access Codes: Create time-limited access codes for guests or service providers (e.g., 12 hours, 3 days, 1 week options).
• Intrusion Alerts: Receive notifications on your smartphone for any attempted unauthorized access.
• Passage Mode: Enable passage mode for continuous unlocked access, useful for events or when frequent entry/exit is needed.

Figure 2.3: The smart lock supports multiple user profiles, allowing easy management of access for various individuals.

Figure 2.4: The auto-lock feature ensures the door is secured automatically after a set period.

2.3 Official Product Videos

3. Maintenance

3.1 Cleaning

To maintain the appearance and functionality of your smart door knob, wipe it regularly with a soft, dry cloth. Avoid using abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish and electronic components.

3.2 Battery Management

The smart door knob is powered by a built-in 400mAh rechargeable battery. A full charge typically lasts approximately 8 months, depending on usage frequency.

• Charging: When the battery level is low (at 15% capacity), the lock will provide a visual battery display and an audible low battery alarm. Connect the provided USB-A to Type-C cable to the charging port on the knob and a power source (e.g., USB charger, power bank) for 3-4 hours to fully recharge.
• Battery Life: Regular charging ensures uninterrupted operation.

Figure 3.1: Charging interface and battery indicator on the smart door knob.

4. Troubleshooting

If you encounter issues with your HEI LIANG Smart Door Knob, refer to the following common problems and solutions:

For more detailed troubleshooting or issues not listed here, please consult the full user guide PDF or contact customer support.

5. Specifications

6. Warranty & Support

HEI LIANG products are manufactured to high-quality standards and are backed by a manufacturer's warranty. Please refer to the product packaging or the official user guide PDF for specific warranty terms and conditions.

For technical support, troubleshooting assistance, or warranty claims, please contact HEI LIANG customer service through the contact information provided on the product packaging or the official brand website. When contacting support, please have your product model (HL-2) and purchase details ready.

Official User Guide: https://manuals.plus/m/bdf976f401819034d57756d1da35231e8c98026debbd4ba4b0181b55efad4998
