Aanyhoh USB Rechargeable LED Bulb with Remote Control

Introduction

Thank you for choosing the Aanyhoh USB Rechargeable LED Bulb. This versatile 5W E27 LED bulb features a built-in 3600 mAh lithium battery, offering both touch and remote control for dimming and color temperature adjustments. It is designed for various applications, including home lighting, camping, and emergency situations.

Please read this manual carefully before use to ensure proper operation and to maximize the product's lifespan.

Product Overview

The Aanyhoh rechargeable LED bulb provides flexible lighting with adjustable color temperatures and brightness levels. It includes a remote control for convenient operation and a timer function.

Image: The Aanyhoh USB Rechargeable LED Bulb, showing its E27 base and compact design.

Setup

Initial Charging

Upon receiving the bulb, it is recommended to fully charge it before first use. This is due to potential long-term storage affecting the battery level.

• Connect the included Type-C charging cable to the bulb's charging port.
• Connect the other end of the cable to a 5V/2A USB power adapter (not included), a power bank, or a car charger.
• A full charge typically takes 5-6 hours. The charging indicator light will change once fully charged.

Caution: Do not charge with an adapter exceeding 5V/2A. Using fast-charging mobile phone chargers is prohibited as it may damage the bulb.

Image: Illustration of the bulb being charged via a Type-C cable, showing charging and fully charged indicators.

Installation

• The bulb is compatible with standard E27 lamp sockets.
• Screw the bulb into an E27 socket. Note that this product does not directly use AC mains power; the socket serves as a holder.
• Alternatively, use the included hook for portable hanging applications.

Warning: Do not connect this product directly to a 220V AC power supply. It is designed for 5V USB rechargeable operation only.

Operating Instructions

Touch Control Operation

The bulb features a touch-sensitive button for basic control:

• Light Touch: Switches between available color temperatures (3000K Warm Light, 4500K Neutral Light, 6000K White Light).
• Long Press: Adjusts the brightness level continuously. Release to set the desired brightness.

Remote Control Operation

The included remote control provides comprehensive control over the bulb's functions:

Image: The bulb and its remote control, illustrating the touch button function and remote control features.

• ON/OFF Button: Turns the bulb on or off.
• Color Temperature Adjustment: Buttons to cycle through or directly select 3000K (Warm), 4500K (Neutral), and 6000K (White) light.
• Brightness Adjustment: Buttons to increase (+) or decrease (-) brightness from 10% to 100%.
• Preset Brightness Levels: Quick selection for 10%, 30%, 50%, and 100% brightness.
• Timer Function: Set the bulb to turn off automatically after 15, 30, or 60 minutes.
• Night Light Mode: Activates a low-brightness, warm light setting, ideal for sleep or subtle illumination.

Image: Visual representation of the three color temperatures (3000K, 4500K, 6000K) and four brightness levels (10%, 30%, 50%, 100%).

Image: Demonstrates the timer function (15, 30, 60 minutes) and night light mode, suitable for scheduling sleep time.

Applications

This versatile LED bulb is suitable for a wide range of scenarios:

• Home Lighting: Use with wall lamps, table lamps, floor lamps, or chandeliers.
• Emergency Lighting: Provides illumination during power outages, storms, or other emergencies.
• Outdoor Activities: Ideal for camping, night fishing, or other outdoor uses where a portable light source is needed.
• DIY Wireless Lamps: Create custom lighting solutions without the need for permanent wiring.

Image: Examples of the bulb used in chandeliers, floor lamps, table lamps, and bedside wall lamps.

Image: Demonstrates the bulb's use for outdoor camping, during power outages, and as a portable light source.

Maintenance

Battery Care

• Only the special built-in battery can be used. Do not attempt to replace the battery yourself, as this may damage the LED bulb and void the warranty.
• To prolong battery life, avoid fully discharging the bulb frequently.
• Store the bulb in a cool, dry place if not used for extended periods, and recharge it periodically.

Cleaning

• Ensure the bulb is turned off and disconnected from any charging source before cleaning.
• Wipe the bulb with a soft, dry cloth. Do not use abrasive cleaners or solvents.

Environmental Considerations

This product has an IP44 rating, meaning it is protected against solid objects larger than 1mm and splashing water from any direction. It is suitable for indoor use. When using outdoors, ensure it is protected from heavy rain or prolonged exposure to water.

Troubleshooting

• Bulb not turning on:
  • Ensure the bulb is sufficiently charged. Connect it to a charger and check the indicator light.
  • Check the remote control battery if using the remote.
  • Verify the touch button is being pressed correctly (light touch or long press).
• Brightness or color not changing:
  • Ensure the remote control has working batteries and is pointed towards the bulb.
  • For touch control, ensure you are using the correct gesture (light touch for color, long press for brightness).
• Short battery life:
  • Ensure the bulb is fully charged (5-6 hours).
  • Operating at 100% brightness will consume battery faster than lower settings or night light mode.
  • Battery performance may decrease over time with extensive use.

Specifications

Image: The energy label for the Aanyhoh LED Bulb, indicating an energy efficiency class E and 5 kWh/1000h consumption.

For detailed product information, refer to the official EU EPREL database: https://eprel.ec.europa.eu/qr/1571709

Warranty and Support

Our products come with a one-year warranty from the date of purchase. This warranty covers manufacturing defects under normal use.

If you have any questions, concerns, or require technical assistance with your Aanyhoh USB Rechargeable LED Bulb, please do not hesitate to contact our customer support team. We are committed to providing a satisfactory solution within 24 hours.

Contact Information:

• Please refer to your purchase platform or product packaging for specific contact details.
