SUNPIE 30L Portable Car Refrigerator Instruction Manual

Introduction

Thank you for purchasing the SUNPIE 30L Portable Car Refrigerator. This appliance is designed to provide efficient cooling and freezing for your food and beverages, whether in your vehicle or at home. This manual contains important information regarding the safe use, operation, and maintenance of your refrigerator. Please read it thoroughly before use and keep it for future reference.

Safety Precautions

• Ensure the power supply matches the voltage requirements of the refrigerator (DC 12V/24V, AC 100V).
• Do not operate the refrigerator with wet hands or near water to prevent electric shock.
• Keep ventilation openings clear of obstructions to ensure proper airflow and prevent overheating.
• Avoid placing flammable or explosive substances inside the refrigerator.
• Do not attempt to repair or modify the appliance yourself. Contact qualified service personnel for assistance.
• When using in a vehicle, secure the refrigerator to prevent movement during driving.

Package Contents

Verify that all items are present in the package:

• SUNPIE 30L Refrigerator Body
• AC Power Cord + Adapter (approx. 2.0m)
• DC Power Cord (approx. 3.5m)
• Instruction Manual (Japanese, includes warranty information)

Product Overview

The SUNPIE 30L Portable Car Refrigerator features a robust design with two independent temperature zones, allowing for simultaneous refrigeration and freezing. It includes a user-friendly control panel, a USB charging port, and an internal LED light for convenience.

Image: Overview of the SUNPIE 30L Portable Car Refrigerator, highlighting its dual compartments and control panel.

Image: Detailed dimensions of the refrigerator (66cm D x 37cm W x 39cm H) and its internal storage boxes, along with the control panel layout.

Key Features:

• Dual-Zone Temperature Control: Independently set temperatures for two compartments, ranging from -20°C to 10°C.
• Rapid Freezing: Achieves -20°C in approximately 35 minutes (MAX mode).
• High-Density Insulation: Provides superior thermal retention, keeping contents cool for over 24 hours without power (at 20-25°C ambient).
• 3-Way Power Supply: Compatible with DC 12V/24V (car) and AC 100V (home), and portable power sources.
• Battery Protection System: Prevents vehicle battery drain with adjustable low-voltage cut-off settings.
• Quiet Operation: Designed for low noise levels (approx. 45dB).
• USB Charging Port: Conveniently charge mobile devices.
• Internal LED Light: Illuminates the interior for easy visibility in low light conditions.

Setup

1. Placement

Place the refrigerator on a flat, stable surface. Ensure there is adequate space (at least 10 cm) around all sides for proper ventilation. Avoid direct sunlight or heat sources.

2. Power Connection

The refrigerator supports three power input methods:

• DC 12V/24V (Vehicle Use): Connect the DC power cord to the refrigerator's DC input port and then to your vehicle's cigarette lighter socket.
• AC 100V (Home Use): Connect the AC adapter to the refrigerator's AC input port, then plug the AC power cord into a standard 100V wall outlet.
• Portable Power Source: The refrigerator can also be powered by compatible portable power stations using either the DC or AC connection methods.

Image: Illustration of the 3-way power compatibility, including vehicle DC, home AC, and portable power connections.

3. Initial Cleaning

Before first use, wipe the interior and exterior of the refrigerator with a damp cloth and mild detergent. Ensure it is completely dry before plugging it in.

Operating Instructions

1. Power On/Off

Press the On/Off button on the control panel to turn the refrigerator on or off. The digital display will illuminate when powered on.

2. Temperature Adjustment (Dual Zone)

The refrigerator has two independent compartments. You can set different temperatures for each:

• Press the Setting button to select the desired compartment (Big Box or Small Box).
• Use the + and - buttons to adjust the temperature. The temperature range is -20°C to 10°C.
• The display will show the set temperature, then revert to the current internal temperature after a few seconds.

Image: Visual guide to dual-zone temperature settings, demonstrating how to set different temperatures for freezing and refrigeration.

3. Mode Selection (MAX/ECO)

The refrigerator offers two operating modes:

• MAX Mode (80W): Provides rapid cooling and freezing. Use this mode when you need to quickly reach the desired temperature.
• ECO Mode (40W): Optimizes energy consumption for longer operation. Use this mode for maintaining temperatures once the desired level is reached.
• To switch modes, press the Setting button until the mode indicator (MAX or ECO) flashes, then use + or - to select.

Image: Demonstration of rapid cooling performance and battery protection settings (H, M, L) with corresponding voltage cut-off values.

4. Battery Protection Settings

This feature prevents your vehicle's battery from draining. You can choose from three protection levels:

• H (High): Highest protection, cuts off power at a higher voltage.
• M (Medium): Moderate protection.
• L (Low): Lowest protection, allows the refrigerator to run longer before cut-off.

To adjust the battery protection level, press and hold the Setting button for 3 seconds until the battery icon flashes, then use + or - to select H, M, or L. The recommended setting for most vehicles is M.

Image: Visual representation of the battery protection system and the refrigerator's anti-vibration design, ensuring stable operation.

Maintenance

1. Cleaning

• Always unplug the refrigerator before cleaning.
• Use a soft cloth dampened with mild detergent and water to clean the interior and exterior surfaces.
• Do not use abrasive cleaners, harsh chemicals, or sharp objects, as these can damage the surfaces.
• Ensure all surfaces are dry before reconnecting power.

2. Defrosting

Frost may accumulate inside the freezer compartment over time. To defrost:

• Turn off the refrigerator and unplug it.
• Remove all contents.
• Leave the lid open to allow the frost to melt naturally.
• Wipe away melted water with a clean cloth. Do not use sharp objects to remove frost.

3. Storage

If storing the refrigerator for an extended period, ensure it is clean and dry. Leave the lid slightly ajar to prevent odors and mold growth.

Troubleshooting

If you encounter issues with your refrigerator, refer to the table below for common problems and solutions:

Specifications

Warranty and Support

The SUNPIE 30L Portable Car Refrigerator comes with a 2-year warranty from the date of purchase. This warranty covers manufacturing defects and malfunctions under normal use.

For warranty claims, technical support, or any inquiries, please refer to the contact information provided in the Japanese instruction manual included with your product. For initial defects (within 10 days of order date), SUNPIE will cover return shipping costs for new product exchange.

This product is PSE certified, ensuring compliance with electrical appliance safety standards.
