Depusheng RX2 USB Audio Interface User Manual

1. Introduction

The Depusheng RX2 USB Audio Interface is a professional-grade sound card designed for computer recording, home studio setups, and various audio production needs. It offers high-quality audio capture and playback with ultra-low latency, making it suitable for connecting microphones, guitars, and other audio devices to your computer. Its robust all-metal chassis ensures durability and portability, providing flexible options for music production, live streaming, podcasting, and more.

2. Setup

2.1 Package Contents

Upon opening the package, verify that all components are present:

• Depusheng RX2 USB Audio Interface Unit
• USB 2.0 Cable
• Type-C Cable (for additional power, if needed)
• User Manual (this document)

Figure 2.1: Depusheng RX2 USB Audio Interface and included USB cables.

2.2 Connecting to Your Computer

The RX2 audio interface connects to your computer via a standard USB 2.0 cable. No proprietary drivers are required for Mac OS or Windows XP and above, ensuring a plug-and-play experience.

1. Connect one end of the provided USB 2.0 cable to the USB 2.0 port on the rear of the RX2 interface.
2. Connect the other end of the USB 2.0 cable to an available USB port on your computer.

Figure 2.2: Rear panel connections of the RX2 interface, including USB 2.0 and 5VDC power input.

2.3 Powering the Device

The RX2 can be powered directly via the USB 2.0 connection from your computer. For additional power stability, especially when using 48V phantom power or multiple high-draw devices, you can use the 5VDC Type-C power input.

1. Connect the USB 2.0 cable to your computer as described above. This typically provides sufficient power.
2. If additional power is required, connect a standard 5VDC Type-C power adapter (not included) to the "5VDC" port on the rear of the unit.

Figure 2.3: The 5VDC Type-C power input on the rear of the RX2 interface for stable power delivery.

3. Operating the Depusheng RX2

3.1 Input Connections and Gain Control

The RX2 features two combo XLR/TRS inputs (Input 1 and Input 2) for connecting microphones, guitars, or other line-level instruments. Each input has independent gain control and indicators for signal presence (SIG) and overload (PK).

• Microphones: Connect XLR microphones to either Input 1 or Input 2. For condenser microphones requiring power, activate the 48V Phantom Power button.
• Instruments: Connect guitars or basses directly to Input 1 or Input 2 using a 1/4-inch TS cable. The high-headroom instrument input prevents distortion.
• Gain Knobs: Adjust the "GAIN 1" and "GAIN 2" knobs to set the input level for each channel. The "SIG" light indicates signal presence, and the "PK" light indicates an approaching overload, requiring gain reduction.

Figure 3.1: Connection diagram for microphones, guitars, and monitoring devices.

Figure 3.2: Independent gain control for each input channel.

Figure 3.3: High dynamic headroom instrument input for clear guitar and bass recording.

3.2 Monitoring and Output

The RX2 provides flexible monitoring options, allowing you to hear your input signals and playback simultaneously.

• Headphone Output: Connect headphones to the 6.35mm or 3.5mm headphone jack on the front panel. Use the "PHONES" knob to adjust the headphone volume independently.
• Direct Monitoring: The "MON" button enables direct monitoring, allowing you to hear your input signals with zero latency, mixed with the playback from your computer.
• Main Outputs: Use the two independent 1/4-inch TRS stereo output jacks on the rear panel to connect to active speakers, power amplifiers, or other recording equipment. Adjust the "OUT" knob for main output volume control.

Figure 3.4: Real-time monitoring through headphones.

Figure 3.5: Dedicated headphone output for private monitoring.

3.3 Software Compatibility and Usage Scenarios

The Depusheng RX2 is designed for broad compatibility and can be used with various popular recording software and applications.

• Operating Systems: Compatible with Mac OS and Windows XP or above.
• Applications: Ideal for professional studio recording, live broadcasting, podcasting, and content creation on platforms like Facebook, TikTok, and YouTube.

Figure 3.6: Software and platform compatibility for the RX2 interface.

Figure 3.7: Diverse usage scenarios for the Depusheng RX2, from podcasting to music recording.

4. Maintenance

To ensure the longevity and optimal performance of your Depusheng RX2 USB Audio Interface, follow these maintenance guidelines:

• Cleaning: Use a soft, dry cloth to wipe down the unit. Avoid abrasive cleaners, solvents, or waxes, as they may damage the finish or internal components.
• Storage: When not in use, store the interface in a cool, dry place away from direct sunlight, extreme temperatures, and excessive dust.
• Handling: Handle the unit with care. Avoid dropping it or exposing it to strong impacts, which could damage the internal circuitry or external casing.
• Connections: Periodically check all cable connections for secure fit and signs of wear. Ensure cables are not bent sharply or under strain.

5. Troubleshooting

If you encounter issues with your Depusheng RX2, refer to the following common troubleshooting steps:

6. Specifications

7. Warranty and Support

7.1 Warranty Information

Warranty details for the Depusheng RX2 USB Audio Interface are typically provided with the product packaging or can be found on the official Depusheng website. Please retain your proof of purchase for any warranty claims.

7.2 Customer Support

For technical assistance, product inquiries, or support, please contact Depusheng customer service. You can find more information and contact details on the official Depusheng store page:

Visit the Depusheng Store on Amazon
