tectake Solar Shower 40L - Instruction Manual

1. Product Overview

The tectake Solar Shower is designed for outdoor use, providing a refreshing shower experience using solar energy to heat water. It features a practical mixer tap for precise temperature control, combining heated water from the reservoir with cold water from your supply hose. The weather-resistant construction includes a large rain-effect shower head with a rotating spherical head for optimal coverage.

This ecological garden shower is ideal for use after swimming, gardening, or during camping trips, offering a convenient and energy-efficient way to enjoy warm water outdoors.

Image 1.1: Overview of the tectake Solar Shower, highlighting its flexible shower head, efficient solar energy use, stepless temperature control, weather resistance, robust construction, universal connection, foot shower, and easy installation.

2. Safety Instructions

• Ensure the shower is securely mounted to a stable, level surface to prevent tipping.
• Do not exceed the recommended water pressure of 3.5 bar.
• Always test the water temperature before showering, especially for children, as solar-heated water can reach high temperatures.
• Drain the shower completely before freezing temperatures to prevent damage.
• Keep children and pets away from the shower during operation and when water is hot.
• Do not attempt to modify the shower's components. Use only original replacement parts if needed.

3. Package Contents

Before beginning assembly, please check that all parts are present and undamaged.

• Solar Shower Unit
• Mounting Material (screws, anchors)
• Assembly Instructions (this manual)

4. Setup and Installation

The tectake Solar Shower is designed for easy ground mounting. Choose a location that receives ample sunlight throughout the day for optimal water heating.

4.1 Site Selection

• Select a firm, level surface, such as concrete or a sturdy wooden deck.
• Ensure the location has access to a garden hose for water supply.
• Position the shower where it will receive maximum direct sunlight.

4.2 Mounting the Shower

1. Place the shower base on the chosen surface and mark the positions for drilling.
2. Drill holes according to the marked positions.
3. Insert the appropriate anchors (if required for your surface type).
4. Secure the shower base to the ground using the provided mounting screws. Ensure it is stable and does not wobble.

Image 4.1: The robust base of the solar shower with pre-drilled holes for secure ground mounting and the universal water connection point.

4.3 Water Connection

1. Connect a standard ½ inch garden hose to the universal water inlet at the base of the shower.
2. Ensure the connection is tight to prevent leaks.
3. Slowly turn on the water supply to fill the 40L water tank.
4. Allow the tank to fill completely before first use.

Image 4.2: This image shows the practical mixer tap for temperature control, the large rain shower head with 360° rotation, the universal hose connection for filling the 40-liter water tank, and the low-placed faucet for foot rinsing or draining.

5. Operating Instructions

5.1 Heating the Water

The solar shower uses direct sunlight to heat the water stored in its 40L tank. The heating time will vary depending on sunlight intensity, ambient temperature, and initial water temperature. On a sunny day, water can reach temperatures up to 60°C.

5.2 Adjusting Water Temperature

The integrated mixer tap allows you to blend the solar-heated water with cold water from your garden hose to achieve your desired shower temperature.

1. Turn the mixer tap handle to the desired position. Moving it towards the red indicator will increase the hot water flow, while moving it towards the blue indicator will increase the cold water flow.
2. Always test the water temperature with your hand before stepping under the shower head to avoid scalding.

Image 5.1: The mixer tap allows for continuous adjustment of water temperature, blending hot solar-heated water with cold supply water.

5.3 Using the Shower Head and Foot Faucet

• The large rain-effect shower head can be rotated 360° to direct the water flow as desired.
• The lower faucet is suitable for rinsing feet or filling small containers. It can also be used to drain the shower tank.

Image 5.2: This image illustrates the internal hot and cold water mixing process and highlights the fully rotatable rain shower head for flexible adjustment.

6. Maintenance

• Cleaning: Clean the shower regularly with a mild soap solution and a soft cloth. Avoid abrasive cleaners or harsh chemicals that could damage the surface.
• Winterization: Before the first frost, completely drain all water from the shower tank and pipes. Disconnect the garden hose. Store the shower in a frost-free location if possible, or cover it securely if left outdoors. Failure to do so will void the warranty.
• Durability: The shower is constructed from weather-resistant materials (PVC, ABS plastic, brass, EPDM plastic, steel) designed for outdoor use and resistance to corrosion, high temperatures, and UV rays.

7. Troubleshooting

8. Specifications

Image 8.1: Detailed product information including overall dimensions, shower head diameter, base dimensions, and technical specifications.

9. Warranty and Support

For warranty information and customer support, please refer to the purchase documentation or contact tectake customer service directly. Ensure you retain your proof of purchase for any warranty claims.

Note: Damage caused by improper installation, misuse, lack of winterization, or unauthorized modifications is not covered under warranty.
