AIBORS Gold-01
AIBORS Dog Clippers User Manual
Model: Gold-01 | Brand: AIBORS
1. Product Overview
The AIBORS Dog Clippers are designed for professional pet grooming, featuring a heavy-duty motor, low noise operation, and a rechargeable cordless design. This kit provides all necessary tools for efficient and comfortable pet hair trimming.
Figure 1: AIBORS Dog Clippers and included accessories.
Key Features:
- Self-Sharpening Precision & Safe Blade: High-carbon steel blades ensure smooth, snag-free cutting. R-shaped clog-proof blade design for pet safety.
- 3 Hour Run Time: Built-in 2000mAh Li-ion Battery provides 180 minutes of operational power after 3-4 hours of charging. Cordless design for flexibility, with corded operation also available.
- Low Noise & Low Vibration: Operates at approximately 60dB, minimizing stress for pets during grooming.
- Adjustable Blade & Guide Combs: Four adjustable blade lengths (0.5mm/1.3mm/2.0mm/2.5mm) and four guide combs (3mm/6mm/9mm/12mm) for various hair lengths and styles.
- Easy to Use: Suitable for both experienced groomers and beginners.
2. Package Contents
Ensure all items are present before first use:
- 1x Pet Clippers
- 4x Guide Combs (3mm, 6mm, 9mm, 12mm)
- 1x Cleaning Brush
- 1x Oil Bottle
- 1x User Manual
- 1x Charging Adapter
- 1x Metal Comb
- 1x Grooming Scissors
3. Setup
3.1 Initial Charging
Before first use, fully charge the clippers. Connect the charging adapter to the charging port at the bottom of the clippers and plug it into a power outlet. The digital display will indicate the charging progress.
Figure 2: Charging the clippers and battery indicator.
Figure 3: Digital display showing power percentage and charging reminder.
3.2 Attaching Guide Combs
To attach a guide comb, align the comb with the clipper blade and push it firmly until it snaps into place. Ensure it is securely fastened before use.
Figure 4: Four guide combs and adjustable taper lever for different hair lengths.
4. Operating the Clippers
4.1 Power On/Off
Slide the power switch located on the side of the clippers up to turn it on, and down to turn it off.
4.2 Adjusting Blade Length
The clippers feature an adjustable taper lever on the side, allowing you to select blade lengths of 0.5mm, 1.3mm, 2.0mm, or 2.5mm without a guide comb. This provides precision for different grooming needs.
Figure 5: Close-up of the blade, highlighting no hair clog, sharp but safe, and anti-overheating features.
4.3 Grooming Your Pet
Before clipping, ensure your pet's coat is clean and free of tangles. Use the included metal comb to remove any knots. Select the appropriate guide comb or blade length. Gently move the clippers against the direction of hair growth for an even cut. For sensitive areas, use caution and consider using the grooming scissors for precision.
Figure 6: Demonstrating ease of use for grooming different animals.
Figure 7: Low noise design helps keep pets calm during grooming.
5. Maintenance
5.1 Cleaning the Blades
After each use, turn off the clippers and remove any attached guide combs. Use the provided cleaning brush to remove hair from the blades. For thorough cleaning, the blade can be detached by pushing it forward (refer to the diagram in the physical manual for exact steps if needed).
5.2 Oiling the Blades
Regularly apply a few drops of the included oil to the blades to ensure smooth operation and prolong their lifespan. Turn on the clippers for a few seconds after oiling to distribute the oil evenly.
6. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Clippers not turning on | Low battery; Power switch off | Charge the clippers fully; Ensure power switch is in the 'ON' position. |
| Poor cutting performance / Pulling hair | Blades are dull or dirty; Insufficient oil; Hair is tangled | Clean and oil blades; Sharpen or replace blades if necessary; Comb pet's hair thoroughly before clipping. |
| Excessive noise or vibration | Blades not properly aligned or oiled | Ensure blades are clean and well-oiled; Check blade alignment. |
7. Specifications
- Brand: AIBORS
- Model: Gold-01
- Power Source: Battery Powered (2000mAh Li-ion)
- Charging Time: 3-4 hours
- Operating Time: Up to 180 minutes
- Noise Level: Approximately 60dB
- Blade Material: High-carbon steel
- Adjustable Blade Lengths: 0.5mm, 1.3mm, 2.0mm, 2.5mm
- Guide Comb Sizes: 3mm, 6mm, 9mm, 12mm
- Item Weight: 1.39 pounds
- Package Dimensions: 8.82 x 8.31 x 2.28 inches
- Country of Origin: China
8. Warranty and Support
AIBORS offers a One Year Warranty for this pet trimmer. If you encounter any issues or are not satisfied with the product, please contact AIBORS customer support for assistance.
