VGR V-933 Professional Corded & Cordless Hair Trimmer User Manual

1. Introduction

Thank you for choosing the VGR V-933 Professional Corded & Cordless Hair Trimmer. This manual provides essential information for the safe and effective use of your new trimmer. Please read these instructions carefully before first use and retain them for future reference.

2. Important Safety Instructions

To reduce the risk of electric shock, injury, or fire, always follow these basic safety precautions:

• Do not immerse the trimmer in water or use it near water.
• Keep the appliance away from heated surfaces.
• Do not use the trimmer if it is damaged or malfunctioning.
• Ensure the charging cable is not damaged before connecting to a power source.
• This appliance is not intended for use by persons with reduced physical, sensory, or mental capabilities unless supervised or instructed.
• Keep out of reach of children.
• Only use the provided charging cable and accessories.

3. Package Contents

Verify that all items are present in your package:

• VGR V-933 Hair Trimmer
• USB Type-C Charging Cable
• 3 Guide Combs (1.5mm, 3.0mm, 4.5mm)
• Cleaning Brush
• Lubricating Oil
• User Manual

Image 1: VGR V-933 Hair Trimmer and its retail packaging, showing the device and included accessories.

4. Product Overview

The VGR V-933 trimmer features a precision stainless steel blade for close cutting and a powerful motor for efficient performance. It operates both corded and cordless, offering flexibility.

• Precision Blade: Fine-cutting teeth for extremely close trimming.
• Guide Combs: Three attachment guards (1.5mm, 3.0mm, 4.5mm) for varied cutting lengths.
• USB Charging: Convenient Type-C USB charging.
• LED Indicator: White light indicates operation; flashing white light signals low battery or charging status.
• On/Off Switch: Simple control for operation.
• Motor: High-speed 6500 RPM motor with low noise and overheat protection.

Image 2: The VGR V-933 trimmer showcasing its features: 500 minutes runtime, 2000mAh battery, corded & cordless operation, and 3 guide combs.

Image 3: Illustration of the VGR V-933 trimmer's powerful motor, emphasizing low noise, vibration, overheat protection, and 6500 RPM speed.

Image 4: Close-up of the VGR V-933 trimmer's stainless steel blades, highlighting water-resistance, durability, and self-sharpening features.

5. Charging the Trimmer

The VGR V-933 features a 2000mAh Lithium battery, providing up to 500 minutes of operating time on a full charge. A full charge takes approximately 4 hours.

1. Ensure the trimmer is switched off.
2. Insert the USB Type-C cable into the charging port at the bottom of the trimmer.
3. Connect the other end of the USB cable to a compatible USB power adapter (not included) or a computer USB port.
4. The LED indicator will flash white during charging.
5. Once fully charged, the LED indicator will stop flashing and remain solid white.
6. Disconnect the trimmer from the charging cable after charging is complete.

Note:

• The trimmer can be used while corded if the battery is depleted.
• If the LED indicator flashes white during use, it indicates a low battery and reminds you to recharge.

Image 5: The VGR V-933 trimmer illustrating its charging capabilities, including 500 minutes operating time, 4 hours charging time, 2000mAh battery, and Type-C USB charging port.

6. Attaching and Removing Guide Combs

The VGR V-933 comes with three guide combs for different trimming lengths: 1.5mm, 3.0mm, and 4.5mm.

1. To Attach: Align the guide comb with the trimmer blade and push it down firmly until it clicks into place.
2. To Remove: Gently push the comb upwards from the back, away from the blade, until it detaches.

Caution:

• Always ensure the trimmer is switched off before attaching or removing guide combs.

Image 6: The VGR V-933 trimmer's three guide combs (1.5mm, 3.0mm, 4.5mm) for precise length control.

7. Operating Instructions

The VGR V-933 is suitable for trimming hair, beards, body hair, and ear locks.

1. Preparation: Ensure your hair is clean and dry. For best results, comb your hair in the direction of growth before trimming.
2. Select Length: Attach the desired guide comb for your preferred hair length. For a very close trim, use without a guide comb.
3. Power On: Press the On/Off switch to turn on the trimmer. The LED indicator will illuminate white.
4. Trimming: Hold the trimmer with the blade flat against the skin or at a slight angle, moving against the direction of hair growth. Use slow, controlled strokes.
5. Power Off: After use, press the On/Off switch to turn off the trimmer.

Image 7: A user demonstrating the VGR V-933 trimmer for beard trimming, highlighting its precision and 'Nick Proof Design'.

Image 8: The VGR V-933 trimmer shown in use for various grooming applications: hair, beard, body, and ear lock trimming.

8. Maintenance and Cleaning

Regular cleaning and maintenance will ensure optimal performance and extend the life of your trimmer.

1. Cleaning the Blades: After each use, switch off the trimmer and remove any attached guide comb. Use the provided cleaning brush to brush away loose hairs from the blades.
2. Rinsing Blades: The stainless steel blades are water-resistant. You may carefully rinse the blade head under running water. Ensure the trimmer body does not get wet.
3. Drying: Allow the blades to air dry completely before reattaching any comb or storing the trimmer.
4. Lubrication: Periodically apply a small drop of the provided lubricating oil to the blades to maintain their sharpness and smooth operation. Turn on the trimmer for a few seconds to distribute the oil.
5. Storage: Store the trimmer in a cool, dry place, away from direct sunlight and moisture.

9. Troubleshooting

10. Specifications

11. Warranty and Support

VGR products are manufactured to high-quality standards. For warranty information or technical support, please refer to the warranty card included in your package or contact VGR customer service through their official website. Please retain your proof of purchase for any warranty claims.
