KXAITO Military Waterproof Watch Model kxaito-8060 User Manual

Introduction

Thank you for choosing the KXAITO Military Waterproof Watch Model kxaito-8060. This watch combines robust military-inspired design with multi-functional capabilities, including dual analog and digital time display, alarm, stopwatch, date, and LED backlight. Designed for durability and comfort, it is suitable for various indoor and outdoor activities. Please read this manual carefully to understand the features and proper operation of your watch.

Image: KXAITO Military Waterproof Watch Model kxaito-8060, showcasing its robust design and dual display.

Product Overview and Button Functions

Familiarize yourself with the watch's components and button layout. The watch features a dual display (analog and digital) and multiple buttons for various functions.

Image: Detailed view of the KXAITO Military Watch Model kxaito-8060, highlighting its various display elements and button functions for easy identification.

• Time Display: Shows current time (digital).
• Luminous Buttons: Activates the LED backlight.
• Alarm Clock Mode: Accesses alarm settings.
• Nowtime: Displays current time.
• Switcher Mode: Cycles through different modes (Time, Alarm, Stopwatch, Date).
• Date Display: Shows the current date.
• Timing Reset: Resets the stopwatch.
• Week Showed: Displays the day of the week.
• Clockwise: Adjusts settings (e.g., increments time/date).
• Supplementary Control: Additional control for specific functions.
• The Second Hand Shows: Analog second hand movement.

Setup and Initial Configuration

Before using your watch, it is important to set the correct time and date.

Setting Digital Time and Date:

1. Press the Switcher Mode button repeatedly until the digital time display starts flashing, indicating it's in setting mode.
2. Use the Clockwise or Supplementary Control buttons to adjust the hours, minutes, date, month, and day of the week. Press Switcher Mode to move between settings.
3. Once all settings are correct, press the Switcher Mode button again to exit setting mode.

Setting Analog Time:

The analog hands are typically set independently. Pull out the crown (the knob on the side of the watch) to the first or second click position (refer to specific watch model for exact crown positions). Rotate the crown to adjust the analog hands to the correct time. Push the crown back in to synchronize with the digital time or to start the analog movement.

Operating Instructions

Your KXAITO watch offers several functions for daily use.

Using the Alarm:

1. Press the Switcher Mode button until you reach the Alarm Clock Mode.
2. Use the Clockwise or Supplementary Control buttons to set the desired alarm time.
3. Activate or deactivate the alarm using the designated button (often one of the side buttons, refer to watch diagram).

Using the Stopwatch:

1. Press the Switcher Mode button until you reach the Stopwatch mode. The display will show '00:00:00'.
2. Press the Clockwise or a similar button to start the stopwatch.
3. Press the same button to pause/resume.
4. Press the Timing Reset button to reset the stopwatch to zero.

LED Backlight:

To illuminate the digital display in low-light conditions, press any of the Luminous Buttons. The backlight will typically stay on for a few seconds.

Image: The KXAITO Military Watch Model kxaito-8060 displaying its luminous effect, providing clear readability in the dark.

12/24 Hour Format:

In time setting mode, you can usually toggle between 12-hour and 24-hour formats by pressing a specific button (often the Supplementary Control or Clockwise button) when the hour setting is flashing.

Dual Time Zone:

Your watch supports dual time zones. To set the second time zone, navigate to the dual time mode (if available, typically through the Switcher Mode) and adjust the time using the setting buttons as you would for the main time.

Maintenance and Care

Proper care will ensure the longevity and performance of your KXAITO watch.

Water Resistance (50 Meters / 3 ATM):

This watch is water-resistant up to 50 meters (3 ATM), making it suitable for daily use, including hand washing, cold baths, and exposure to rain. Important:

• Do not press any buttons underwater. This can compromise the water-resistant seals.
• Avoid exposure to steam and hot water (e.g., hot showers, saunas), as this can damage the waterproof ring.

Image: The KXAITO Military Watch Model kxaito-8060 demonstrating its 50M daily waterproof capability, suitable for splashes and rain.

Cleaning:

Wipe the watch case and strap with a soft, damp cloth. For stubborn dirt, a mild soap solution can be used, followed by rinsing with clean water and drying thoroughly. Avoid harsh chemicals or abrasive materials.

Battery:

The watch is powered by a battery. When the display dims or functions become erratic, it may be time for a battery replacement. It is recommended to have the battery replaced by a professional watch technician to ensure the water resistance is maintained.

Troubleshooting

If you encounter issues with your watch, try the following common troubleshooting steps:

• Time is inaccurate: Check if the watch is in setting mode. If not, the battery might be low and require replacement.
• Digital display is blank or dim: The battery may be depleted. Replace the battery.
• Buttons are unresponsive: Ensure the watch is not wet. If it is, dry it thoroughly. If the issue persists, a professional inspection may be needed.
• Alarm not sounding: Ensure the alarm is properly set and activated in the alarm mode.

For persistent issues not resolved by these steps, please contact customer support.

Specifications

Detailed technical specifications for the KXAITO Military Waterproof Watch Model kxaito-8060:

Warranty and Support

KXAITO is committed to providing excellent customer satisfaction. While specific warranty details are not provided, we strive to ensure the quality of our products.

For any questions, concerns, or support needs regarding your KXAITO Military Waterproof Watch Model kxaito-8060, please do not hesitate to contact our customer service team. We are dedicated to assisting you and will do our best to resolve any issues you may encounter.

Please refer to your purchase documentation or the retailer's website for contact information.
