Introduction
Thank you for choosing the VGR V-393 Hybrid Shaver. This manual provides essential information for the safe and effective use, maintenance, and troubleshooting of your device. Please read it thoroughly before first use and keep it for future reference.
Safety Warning:
- Always clean the shaver after use and allow it to dry completely before storing.
- Do not use the shaver near water while charging to prevent the risk of electric shock.
- Keep the device out of reach of children.
- Do not disassemble or attempt to repair the shaver yourself. Contact qualified personnel for service.
Package Contents
Verify that all items are present in your package:
- 1 x VGR V-393 Hybrid Shaver
- 1 x Oil Bottle
- 1 x Cleaning Brush
- 1 x Charging Connector (USB cable)
- 1 x Smoothing Head
- 3 x Guide Combs (1mm, 3mm, 5mm)
Image: The VGR V-393 shaver shown with its included accessories, including the cleaning brush, charging cable, and guide combs.
Product Features
The VGR V-393 Hybrid Shaver is designed for versatile grooming with several key features:
- Dual-Face Shaving Blade: Provides a smooth and precise shave from both top and bottom.
- Floating Head: Adapts to facial contours for a comfortable shave.
- IPX5 Waterproof: Allows for easy cleaning under running water and use in wet conditions.
- Rechargeable Lithium Battery: Offers cordless operation with a 90-minute run time after a 1.5-hour charge.
- One-Key Switch: Simple and intuitive operation.
- Guide Combs: Includes 1mm, 3mm, and 5mm combs for various trimming lengths.
Image: Diagram highlighting key features of the VGR V-393 shaver, including the floating head, one-key switch, IPX5 waterproofing, and attachable guide combs.
Setup
Initial Charging
Before using your VGR V-393 shaver for the first time, ensure it is fully charged.
- Connect the charging connector to the shaver and plug the USB end into a compatible 5V USB power source (e.g., computer, laptop, USB charger, power bank).
- The indicator light will illuminate during charging.
- Allow approximately 1.5 hours for a full charge. A full charge provides up to 90 minutes of operating time.
Important: Use a charging head that does not exceed 1 Ampere to prolong battery life.
Image: The VGR V-393 shaver displaying its battery capacity (500mAh), charge time (1.5 hours), and work time (90 minutes), along with compatible USB charging methods.
Operating Instructions
General Shaving
- Ensure the shaver is charged.
- For best results, wet the area to be shaved and apply shaving cream or gel. The shaver can also be used for dry shaving.
- Press the power button to turn on the shaver. The green indicator light will illuminate.
- Move the shaver over the skin with gentle, even strokes, against the direction of hair growth. The floating head will adapt to your contours.
- After shaving, turn off the shaver.
Using Guide Combs
To trim hair to a specific length, attach one of the included guide combs (1mm, 3mm, or 5mm) onto the shaver head. Ensure it clicks securely into place before use.
Image: Examples of how to use the VGR V-393 shaver for various grooming tasks, including trimming earlobes, shaving stubble, trimming beards, and grooming body hair.
Maintenance and Cleaning
Regular cleaning ensures optimal performance and extends the lifespan of your shaver.
Cleaning After Each Use
- Turn off the shaver.
- Detach the shaving head by gently pulling it upwards.
- Rinse the shaving head and the main body of the shaver under running water. The device is IPX5 waterproof, allowing for easy wet cleaning.
- Use the included cleaning brush to remove any stubborn hair residue from the blades and internal components.
- Shake off excess water and allow all parts to air dry completely before reattaching the head and storing the shaver.
Lubrication
Periodically apply a small drop of the included oil to the blades to maintain their sharpness and ensure smooth operation. Turn on the shaver for a few seconds to distribute the oil.
Image: The VGR V-393 shaver submerged in water, illustrating its IPX5 waterproof rating and ease of cleaning.
Troubleshooting
If you encounter issues with your VGR V-393 shaver, refer to the table below for common problems and solutions.
| Problem | Possible Cause | Solution |
|---|---|---|
| Shaver does not turn on. | Battery is depleted. | Charge the shaver for 1.5 hours. |
| Poor shaving performance. | Blades are dirty or dull. | Clean the blades thoroughly. Apply a drop of oil. Consider blade replacement if performance does not improve. |
| Shaver pulls hair. | Battery is low; blades are dirty or dull. | Charge the shaver. Clean and oil the blades. |
| Shaver makes unusual noise. | Hair trapped in the mechanism; lack of lubrication. | Clean the shaver thoroughly. Apply oil to the blades. |
If the problem persists after trying these solutions, please contact customer support.
Specifications
| Feature | Detail |
|---|---|
| Model Number | V-393 |
| Brand | VGR |
| Power Source | Battery Operated |
| Battery Type | Lithium-ion |
| Battery Capacity | 500 mAh |
| Voltage | 5V |
| Power | 5W |
| Charging Time | 1.5 hours |
| Operating Time | 90 minutes |
| Blade Material | Stainless Steel |
| Special Features | Washable (IPX5) |
| Recommended Use | Personal Care, Facial Hair Shaving |
| Dimensions (approx.) | 16 x 3.7 cm |
| Weight (approx.) | 400 grams |
| Color | Green |
| Country of Origin | China |
Warranty and Support
This product is covered by a manufacturer's warranty. Please refer to the warranty card included in your package for specific terms and conditions. For technical support, replacement parts, or any inquiries not covered in this manual, please contact your retailer or the VGR customer service department.
