INFANS Baby Bassinet Bedside Crib (Model 1009 = BB5682) Instruction Manual

1. Introduction

The INFANS Baby Bassinet Bedside Crib is designed to provide a safe and comfortable sleeping environment for newborns and infants. This manual outlines the necessary steps for assembly, proper usage, and maintenance to ensure the safety and longevity of your product. Please read all instructions carefully before assembly and use.

Figure 1: INFANS Baby Bassinet Bedside Crib in use.

2. Safety Information

Your INFANS Baby Bassinet Bedside Crib is designed with safety as a priority. It is US. CPSIA & ASTM APPROVED, made of non-toxic materials without any odor, and is FREE from BPA, PVC, Phthalates, Lead, Latex, and Formaldehyde. It features no sharp points or edges and has passed tests for stability, asphyxiation, load, and shear.

General Safety Guidelines:

• Always use the bassinet on a firm, flat, and level surface.
• Do not use the bassinet if any parts are missing, damaged, or broken. Contact customer service for replacement parts.
• Ensure all assembly fasteners are securely tightened before use.
• Never leave an infant unattended in the bassinet.
• Discontinue use when the infant begins to push up on hands and knees, or reaches the maximum weight/age limit, whichever comes first.
• Keep small parts and packaging materials away from children.

3. Package Contents

Before beginning assembly, ensure all components are present and undamaged. The package should include:

• Legs (Frame)
• Storage Basket
• Bassinet Fabric Assembly
• Webbing Straps (for securing to adult bed)
• Bottom Connecting Pipe
• Sleeping Mat

Figure 2: All components included in the package.

4. Setup Instructions

Follow these steps to assemble your INFANS Baby Bassinet Bedside Crib:

1. Open the Legs: Press the button on each leg to fully extend and lock them into position.
2. Install the Storage Basket: Secure the storage basket to the designated attachment points on the leg frame. Ensure all clips are fastened.
3. Attach the Bassinet: Align the bassinet fabric assembly with the rails of the assembled legs. Press the buttons on the bassinet frame and slide it down onto the leg posts until it clicks securely into place.
4. Assemble the Bottom Connecting Pipe: Insert the bottom connecting pipe into the designated slots at the base of the bassinet legs. This provides additional stability.
5. Insert the Sleeping Mat: Place the sleeping mat firmly into the bottom of the bassinet. Ensure it lies flat and covers the entire surface.

5. Operating Instructions

5.1 Adjustable Heights

The bassinet features 6 adjustable height levels to match the height of most adult beds. To adjust the height, press the buttons on both sides of the bassinet frame simultaneously and raise or lower the bassinet to the desired position until it locks securely.

Figure 3: Adjustable height settings and product dimensions.

5.2 Bedside Mode

For co-sleeping, the bassinet can be converted to bedside mode. Unzip the side panel and unlatch the side rail to lower it. Use the provided webbing straps to securely attach the bassinet to your adult bed frame, ensuring there is no gap between the bassinet and the adult mattress.

Figure 4: Bassinet in bedside mode, secured to an adult bed.

5.3 Storage Basket

The large storage basket located beneath the bassinet provides convenient space for baby essentials such as diapers, wipes, and burp cloths. This feature helps keep necessities within easy reach.

Figure 5: Detachable storage basket for baby essentials.

5.4 Mobility

The bassinet is equipped with built-in wheels on the support frame, allowing for easy movement between rooms. Simply lift one side slightly to engage the wheels and move the bassinet. The support frame also includes slip pads to prevent sliding when stationary.

5.5 Mattress and Spinal Support

The bassinet includes a comfortable sleeping mat with a 100% cotton mattress cover, designed to be skin-friendly. The support board within the mattress is a hollow board, providing firm support for the baby's spine. The design promotes a naturally curved spine when lying flat and a straight spine when sleeping sideways.

Figure 6: Spinal protection features of the sleeping mat.

6. Maintenance

Regular cleaning and maintenance will help keep your bassinet hygienic and in good condition.

• Mattress Cover: The mattress cover is detachable and made of 100% cotton. It can be removed for cleaning. Follow the care instructions: Hand Wash Only.
• Fabric: All fabrics on the bassinet are easy to remove and clean. Refer to the care label for specific washing instructions.
• Frame: Wipe the aluminum frame with a damp cloth and mild soap. Dry thoroughly.

7. Troubleshooting

If you encounter any issues with your INFANS Baby Bassinet, please review the assembly instructions to ensure all steps were followed correctly. Check that all connections are secure and that the bassinet is on a stable surface. If problems persist, contact customer support.

8. Specifications

9. Warranty and Support

For warranty information, product support, or to order replacement parts, please contact INFANS customer service. Keep your purchase receipt and model number handy for faster service.

Manufacturer: INFANS

UPC: 798470202900
